Field Controls 46371700 Manual page 4

CAS-6 OIL CAS-6 GAS
(gph) (BTU/hr)
3 420,000
3.25 455,000
3.5 490,000
3.75 525,000
4 560,000
4.25 595,000
4.5 630,000
4.75 665,000
5 700,000
5.25 735,000
5.75 805,000
6 840,000
6.5 910,000
CAS-7 OIL CAS-7 GAS
(gph) (BTU/hr)
6 840,000
6.5 910,000
7 980,000
7.5 1,050,000
8.25 1,155,000
9 1,260,000
9.75 1,365,000
10.5 1,470,000
11.25 1,575,000
12 1,680,000
12.75 1,785,000
12.88 1,803,000
Max. Equivalent Length of Pipe, Including StarKap
8" duct
10" duct
Page 4
10" duct
410 1253
344 1051
291
249
214
185
160
139
121
105
79
58
49
12"duct
469 1167
381
311
256
191
142
104
74
51
31
15
13
©
12" duct
3119
2616
890 2217
760 1893
653 1627
584 1405
489 1217
424 1057
369 919
321 800
241 601
176 519
151 377
14" duct
2523
948 2050
776 1678
637 1378
476 1029
354 766
260 563
186 403
127 274
78 207
39 114
33 72
