Managed Stackable Layer 3 Switches GSM7328S and GSM7352S Hardware Installation Guide

Install the Switch

You can install the switch on a flat surface or in a standard 19-inch rack.
Installing the Switch on a Flat Surface
The switch ships with four self-adhesive rubber footpads. Stick one rubber
footpad on each of the four concave spaces on the bottom of the switch. The
rubber footpads cushion the switch against shock and vibrations.
Installing the Switch in a Rack
To install the switch in a rack, you will need the 19-inch rack-mount kit supplied
with your switch.
1. Attach the supplied mounting brackets to the side of the switch.
2. Use the provided Phillips head screws to fasten the brackets to the sides of the
switch.
Figure 3-1
3. Tighten the screws with a No. 1 Phillips screwdriver to secure each bracket.
Hardware Installation
v1.0, March 2006
mounting
bracket
3-5
