Program Mode and the Program Editor
The OUTPUT Page
The following page is for a layer with one keymap and a single-path algorithm.
EditProg:OUTPUT||||||||||||<>Layer:1/1||
||||||||||||||||||||||||||||||||||||||||
Pair:KDFX-A|||||||||||||||||||||||||||||
Pan|:L|||||||*|||||||R||||||||||||||||||
Mode:+MIDI||||||||||||||||||||||||||||||
Gain:12dB|||||||||||||||||||||||||||||||
CrossFade|:OFF||||||XFadeSense:Norm|||||
<more||OUTPUT||||||||COMMON|SetRng|more>
Parameter
Pair
Pan
Mode
Gain
Crossfade Control
Crossfade Sense
Pair
This parameter sets the output routing of the current layerÑnot the Þnal audio output, but the
KDFX (effects processor) input to which the layerÕs signal will ßow. Setting a value here is like
connecting an audio output to the effects send on a mixer. The actual audio output of the K2600
is determined by the output settings for KDFX.
In a nutshell, the audio signal gets routed from the K2600Õs sound engine into KDFX using this
parameter. A separate KDFX parameter routes the signal from KDFX to the physical audio
outputs on the K2600Õs rear panel.
Pan
Use this parameter to position the current layerÕs audio signal from left to right. An additional
pan parameter (Pan2) appears if you have the Stereo parameter on the KEYMAP page set to a
value of On.
Mode
When the mode is Fixed the pan position remains as deÞned with the Pan parameter, ignoring
MIDI pan messages. When the mode is +MIDI, MIDI pan messages (MIDI 10) will shift the
sound to the left or right of the Pan parameter setting. Message values below 64 shift it left,
while those above 64 shift it right. A setting of Auto assigns the pan setting of each note based
on its MIDI note number. In this case, Middle C (MIDI note number 60) is equivalent to the Pan
parameterÕs setting. Lower notes shift increasingly left, while higher notes shift increasingly
right. A setting of Reverse shifts low notes right, and high notes left. MIDI pan messages will
also affect the pan position when values of Auto and Reverse are selected.
Note: If youÕre using the PANNER DSP function in the algorithm for any of the layers in a program,
that layer will respond to MIDI pan messages even if the Mode parameter is set to a value of Fixed. In this
case, leave Mode set to Fixed, and set Pan1 fully left, and Pan2 fully right.
6-30
Range of Values
KDFX-A, KDFX-B, KDFX-C, KDFX-D
Left to Right (15 Positions, indicated by *)
Fixed, +MIDI, Auto, Reverse
–12 to 30 Db (6 Db Increments)
Control Source List
Normal, Reversed
Default
KDFX-A
Center
+MIDI
18 Db
OFF
Norm
