Summary of Contents for Novus TEMP-WM
- Page 1 TEMP-WM Transmitter USER GUIDE – V3.0x A...
- Page 2 ELECTRICAL INSTALLATION ..................................4 3.2.1 INSTALLATION RECOMMENDATIONS ............................4 3.2.2 SENSOR REPLACEMENT ................................5 CONFIGURATION......................................6 SIGNOW SOFTWARE AND APP ..................................7 SIGNOW SOFTWARE ....................................7 5.1.1 CONFIGURATION SECTION ................................7 5.1.2 DIAGNOSTIC SECTION ...................................9 SIGNOW APP ......................................10 SPECIFICATIONS ......................................12 CERTIFICATIONS .....................................12 WARRANTY ........................................13 NOVUS AUTOMATION 2/13...
- Page 3 Safety recommendations must be followed to ensure personal safety and prevent damage to the device or system. If the device is used in a manner other than that specified in this manual, the device’s safety protections may not be effective. NOVUS AUTOMATION 3/13...
- Page 4 INSTALLATION MECHANICAL INSTALLATION TEMP-WM (Wall Mount) is designed to be fixed to a wall. By removing the cover, you can access the two fixing holes in the base and the connector, as shown in the figure below (in millimeters): Figure 1 To ensure the specified accuracy and degree of protection, the transmitter must be fixed with the sensor capsule facing downwards.
- Page 5 Avoid handling the sensor by the thin end. Do not touch the sensor. Clean anti-static gloves are recommended for this procedure. Step 4: Replace the protective tip and slowly turn it clockwise to secure it to the device. • NOVUS AUTOMATION 5/13...
- Page 6 To configure the device using the SigNow app, you must use an OTG cable with the TxConfig-USB Configuration Interface. Smartphones with On the Go (OTG) technology can be directly connected to the device via the USB port. Using the TxConfig-USB Configuration Interface, TEMP-WM can be recognized and configured when running the SigNow app.
- Page 7 SIGNOW SOFTWARE AND APP The SigNow software and app are the main tools for configuring and analyzing TEMP-WM data. They allow you to explore all the features of the device, communicating through the TxConfig-USB Configuration Interface. This manual describes the features related to TEMP-WM. For more specific instructions on how to operate SigNow tools, check the specific manual.
- Page 8 In the Output (see above), you can see information and set values for the following parameters: 1. Physical property: Allows you to define the physical property to be measured (in the case of TEMP-WM, temperature) or, by clicking on the Off option, disable this output.
- Page 9 At the bottom of the graph, there are checkboxes that allow you to enable or disable the display of information about the temperature values: The examples below show situations where you are forcing a minimum error value and then a maximum error value: FORCING MINIMUM ERROR VALUES Figure 12 Figure 13 NOVUS AUTOMATION 9/13...
- Page 10 TxConfig-USB. The interface will act as an intermediary for the connection: Figure 16 Just click on the Configuration button to display the main screen After that, the app will recognize the device and show the main screen: of the TEMP-WM Configuration section: This is the first screen section displays information about the device.
- Page 11 To make the integration process more user-friendly, SigNow app and SigNow software have the same screens and the parameters of the respective screens are always the same. In SigNow manual, available on NOVUS website, it is possible to obtain more information about some features, such as the firmware update process and the process of creating and saving a configuration.
- Page 12 SPECIFICATIONS FEATURES TEMP-WM Total accuracy: 0.5 °C @ 25 °C (1.6 °C maximum over the measurement range). Sensor temperature measurement Response time (1/e (63 %)): Up to 30 s (moving air 1 m/s). Measurement range: Configurable between -20 and 70 °C.
- Page 13 WARRANTY Warranty conditions are available on our website www.novusautomation.com/warranty. NOVUS AUTOMATION 13/13...
