Installation, Operation and
Maintenance Instructions
RSR4~6 Series
TO PREVENT POTENTIAL INJURY, DEATH, OR DAMAGE TO PROPERTY, READ THIS MANUAL CAREFULLY AND COMPLETELY.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
1-888-HAY-INDL (1-888-429-4635)
www.haywardflowcontrol.com
RSR456IOM Rev B ECR 043V
Hayward Flow Control
Page i of i
Advertisement
Related Manuals for Hayward RSR4 Series
Summary of Contents for Hayward RSR4 Series
- Page 1 Installation, Operation and Maintenance Instructions RSR4~6 Series TO PREVENT POTENTIAL INJURY, DEATH, OR DAMAGE TO PROPERTY, READ THIS MANUAL CAREFULLY AND COMPLETELY. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) www.haywardflowcontrol.com RSR456IOM Rev B ECR 043V Hayward Flow Control Page i of i...
- Page 2 CAUTION – Potential pinch point. Equipment connected to or driven by this device may start unexpectedly and may cause personal injury or entrapment in linkage systems. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com...
- Page 3 4 . . . . . . . . . . . . . . . . . . .
- Page 4 Geartrain damage and/or personal injury may occur. WARNING – To avoid dangerous or fatal electrical shock, turn OFF power to all electrical equipment before working on electrical connections. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com...
- Page 5 CCW direction, and the spring unloads in a CW direction, and the spring unloads a CW direction (default for Hayward valve in a CCW direction. (non-standard for assemblies). Hayward assemblies).
- Page 6 540”lb/60Nm - 30 sec @ 90 deg Spring: 540”lb/60Nm - 20 sec @ 90 deg * RSR6 is not available in proportional control USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com...
- Page 7 (2) HOLES TOTAL Wire sizing data is provided in the table below to assist in the selection of the proper wire size for Hayward RSR3 actuators using various wire sizes over distance. Please make sure to reference the correct voltage and do not exceed the indicated length of the wire run for each model.
- Page 8 20k ohms (0-10vdc) 250 ohms (4-20mA) Feedback Signal Output: 4-20mA Referenced to the common terminal. heater Max Load: 500 ohms USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com Page 7 of 11...
- Page 9 Ambient Termp (°F/°C) -58°F ~ 140°F / -50°C ~ 60°C screw. Accuracy < 5° 8. Replace the cover. Switch Hysteresis approx 5% Switch Material Au plated Ag Contacts USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com Page 8 of 11...
- Page 10 8. To release, hold the handle and loosen the lock screw, then release the handle. 9. Do NOT rotate the handwheel against a locked spring or beyond fully unloaded position. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com...
- Page 11 Increase power supply voltage. LED indicator flashes irregularly Improper wire size / length based on wire sizing Increase wire gage between actuator and supply. tables. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com...
- Page 12 Notes- USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 1-888-HAY-INDL (1-888-429-4635) Hayward Flow Control RSR456IOM Rev B ECR 043V www.haywardflowcontrol.com Page 11 of 11...
