M092792 RevB

OmniPL Retrofit Kit

Automation and Chlorination

Installation Manual

Contents

Safety Instructions...................1

Before You Begin......................4

Worksheet..............................7

Installation.............................9

Connection Table...................12

Configuration.........................13

Mounting Template................48

Warranty...............................50

HLXPROUPG

Hayward Industries

400 Connell Drive, Suite 6100

Berkeley Heights, NJ 07922

Phone: (908) 355-7995

www.hayward.com

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Need help?

Do you have a question about the OmniPL Retrofit Kit and is the answer not in the manual?

Questions and answers

Summary of Contents for Hayward OmniPL Retrofit Kit

Page 1: Table Of Contents
Automation and Chlorination Installation Manual Contents Safety Instructions....1 Before You Begin......4 Worksheet......7 Installation......9 Connection Table....12 Configuration......13 Mounting Template....48 Warranty.......50 HLXPROUPG Hayward Industries 400 Connell Drive, Suite 6100 Berkeley Heights, NJ 07922 Phone: (908) 355-7995 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 2: Safety Instructions
• Replace damaged, broken, cracked, missing, or unsecured suction outlet compo- nents immediately. • In addition, two or more suction outlets per pump installed in accordance with latest ASME, APSP Standards and CPSC guidelines, follow all applicable National, State, and Local codes. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 3 To reduce the risk of electric shock, do NOT use an extension cord to connect unit to electric supply. Provide USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 4 A permanently-installed pool is constructed in or on the ground in a building such that it cannot be readily disassembled for storage. A storable pool can be readily disassembled for storage and reassembled to its original integrity. SAVE THESE INSTRUCTIONS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 5: Before You Begin
This OmniPL Retrofit Kit is compatible with all “P-4”, “PS-4”, and “PS-8” units. The HLXPROUPG is not compatible with “PS-16” although two kits could be installed (one in PS-16, one in the Expansion unit) to manage one pool.
Page 6 The current control’s configured equipment, timers and settings will be lost after replacing the main printed circuit board (mainboard) with the OmniPL Retrofit Kit mainboard. It’s important to capture all of this information before starting the installation. A worksheet is provided on the following pages to record all current settings.
Page 7 NOTE: The configuration menu automatically “locks” after 2 minutes of no buttons being pressed to prevent unauthorized people from changing the control logic inadvertently and possibly damaging the pool equipment or causing a “call back” to fix the configuration. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 8: Worksheet
(2 speed filter pump) Interlock Enabled Disabled ____________________ Freeze Protection Enabled Disabled name Aux6 Config Function Manual On/Off Timeclock Countdown Timer Solar Low Speed (2 speed filter pump) Interlock Enabled Disabled ____________________ Freeze Protection Enabled Disabled name USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 9 All Days/Weekends _______to_______ Weekdays _______to_______ Aux4 All Days/Weekends _______to_______ Weekdays _______to_______ Aux5 All Days/Weekends _______to_______ Weekdays _______to_______ Aux6 All Days/Weekends _______to_______ Weekdays _______to_______ Valve3 All Days/Weekends _______to_______ Weekdays _______to_______ Valve4 All Days/Weekends _______to_______ Weekdays _______to_______ USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 10: Installation
C C H H E E C C K K M M E E N N U U S S Y Y S S T T E E M M Remove local display keypad ProLogic or AquaPlus Mainboard Local display keypad removed USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 11 Transformer wiring - These blue, purple, white and gray primary transformer wires will be connected to a wiring harness that plugs into the OmniPL mainboard. Relay wiring - this wiring will plug into an identical connector on the OmniPL mainboard. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 12 Wago lever connectors on a wiring harness that plugs into the OmniPL mainboard. Remove old Mainboard and install new OmniPL Retrofit Kit Mainboard With all the wires disconnected from the old mainboard, unscrew the two fasteners located at the bottom of the mainboard and then remove. Position the new OmniPL mainboard in its place. The...
Page 13 Tighten the two screws to secure the OmniPL mainboard. The local display will not be reused. Wiring the OmniPL Mainboard ECOMMAND: Because the ECOMMAND did not require a transformer, a Hayward GLXS3PLXFMR transformer must be purchased separately to power the OmniPL mainboard. Refer to the mounting instructions included with the GLXS3PLXFMR.
Page 14 Ethernet connections, use outdoor rated Cat5e or Cat6 Ethernet cable. Connect one end to the Controller and the other to an available LAN port (not WAN) on the home router or access point as shown. LAN port USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 15: Connection Table
ID. Because the control was previously wired, take this time to go through each connection and fill out the table. Refer to the graphic below for the physical location of these connections. HVR1 HVR2 HVR3 HVR4 HVR5 HVR6 HVR7 HVR8 When using Optional Smart Relays USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 16: Configuration
Wizard at a later time to make changes. Navigation The Configuration Wizard has been designed to be intuitive allowing most users the ability to navi- gate with little instruction. On the following page, a list of commonly used buttons are explained. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 17 Configuration Wizard and select “Edit”. The initial configuration settings will be retained and you’ll have an opportunity to make changes or additions. Be sure to save your configuration when exiting. See page 36 for a Quick Edit Guide. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 18 “Shared Heaters”. If you have dual equipment with shared heaters, this can be configured from the second Body of Water’s configuration menu. See page 31 for more information regarding Shared Equipment in the second Body of Water configuration menu. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 19 Filter Pump Off for Valve Change? When Yes is selected, the pump will shut off for 35 seconds whenever the valve(s) change position. Flow Monitoring Enabled? Requires use of a Hayward flow switch. This fea- ture will help protect the filter pump from damage due to no flow. When Yes is selected, the OmniPL will monitor the state of water flow when the filter pump is on.
Page 20 If VSP is selected: Which Hayward Unique Address? If using a VSP, you’ll be asked what is the Hayward Unique Address (HUA). If a value is already shown in the box, advance to the next screen. If no value is shown, selecting the box will bring you to a table showing all detected devices.
Page 21 OmniLogic remote control capability connected to your OmniLogic and pow- ered on. Select “Yes” if you would like to configure this heater now or “No” if you would like to configure a different heater. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 22 If Yes is selected: Which Hayward Unique Address? Select the HUA of the Smart Heater that you would like to configure. Name Heater Select the box, then type the desired name for your heater. This name will be used when referring to this particular heater.
Page 23 Minimum Operation Speed? For variable speed pumps, select the lowest pump speed that is allowed while heating. Set a speed that will ensure that there will be sufficient flow for the heater to operate properly. For two speed USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 24 Does Solar Requre the Filter Pump to Prime When it First Turns On? If Yes is selected, the filter pump will turn on in high speed for 3 minutes to circulate water to the solar panels when the heater is activated. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 25 Do you have a Sense & Dispense Module? Select Yes if a Hayward HL-CHEM (sold separately) is connected to the OmniPL.
Page 26 Unique Address. If multiple components are detected, the OmniPL will show a table of devices and prompt you to select the proper device. Which Hayward Unique Address? If a Hayward Unique Address (HUA) is already shown in the box, touch the Advance button. If no address is shown, selecting the box will bring you to a table showing all detected Sense and Dispense devices.
Page 27 Do You Have a Salt Water Chlorine Generator? (requires a connected Hay- ward TurboCell). If Yes is selected: Type of Cell? Select the type of Hayward TurboCell that is installed in your system. Where is the Cell Located? If an entry is already shown in the box, touch the Advance button.
Page 28 If VSP is selected: Which Hayward Unique Address? If using a VSP for your cleaner pump, you’ll be asked what is the Hayward Unique Address (HUA). If a value is already shown in the box, advance to the next screen. If...
Page 29 2 water features; one for the pool Body of Water and one for the spa Body of Water, you would answer “1” to this question. If “1”or more is selected: Select and Configure a Water Feature At this screen you can add, delete and configure USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 30 If VSP is selected: Which Hayward Unique Address? If using a VSP for your water feature pump, you’ll be asked what is the Hayward Unique Address (HUA). If a value is already shown in the box, advance to the next screen.
Page 31 The speed will change at the next scheduled interval. Do You Want to Configure Any Lights? Select yes if you are using any type of pool or spa lights. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 32 If so, the OmniPL will turn this pump on when the accessory is scheduled to run. If Yes is selected: What Type? Select the type of pump used. The choices are Single Speed, Two Speed and VSP. If single speed or two speed pump is selected: USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 33 If VSP is selected: Which Hayward Unique Address? If using a VSP for your accesso- ry pump, you’ll be asked what is the Hayward Unique Address (HUA). If a value is already shown in the box, advance to the next screen. If no value is shown, selecting the box will bring you to a table showing all detected devices.
Page 34 Which body of water is heated in the event that both are running? Select the Body of Water that you would like to have heating priority if both Bodies of Water are running. This USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 35 The sensor connection should now be shown in the box and you can advance to the next screen to continue configuration. Select and Configure Sensors At this screen you can add, delete and configure your sensors. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 36 How Many Accessories are in the Backyard? Select the number of accessories that will be used for the backyard. If “1”or more is selected: Select and Configure Accessories At this screen you can add, delete and configure your USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 37 OmniPL. The affected equipment will activate/deactivate depending on the state of the monitored sensor. For flow switch sensors, affected equipment will turn on/off when the flow switch detects flow or no flow. For tem- USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 38 An alternative to this interlock is using a Theme to Sensor interlock. Create a Theme using desired settings when the pool cover is closed, then interlock the Theme to the pool cover sensor. A summary screen will USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 39 This button appears at the end of every configuration pathway. Back - Touch this button to go back to the previous set of configurable items. See page 14 for a full list of buttons that appear during configuration. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 40 Type - Change the type of Filter Pump that is configured (Single Speed, 2-Speed, or VSP) HUA - Match the HUA (Hayward Unique Address) to the configured Filter Pump. This option only appears if the Filter Pump is configured as a Variable Speed Pump.
Page 41 These options are as follows: Name - Rename the heater/chiller to whatever name you desire. HUA - Select the HUA of the Smart Heater. This option only appears if a Smart Heater is configured. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 42 Chemical Type - Select the type of chemical that is being dispensed (acid or pH Dispensers - Configure the pH dispense unit. pH Timeout - Choose the pH timeout time. pH Extend - Select whether you want pH extend enabled for this Body of Water. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 43 Relay - Select the relay that the cleaner is wired to. This option only appears if the cleaner does not have an associated pump configured. Valve - Configure the cleaner valve, if used. Freeze Protect - Select whether you want the cleaner to turn on for Freeze Pro- USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 44 This option is only available if the water feature pump is con- figured as a 2-Speed or Variable Speed Pump. Freeze Protect - Select whether you want the water feature to turn on for Freeze USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 45 Select an Accessory - Once you select an accessory, all of the options for that ac- cessory will appear on the next screen. These options are as follows: Name - Rename the accessory to whatever name you desire. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 46 Select an Existing Group of Lights - Once you select a group of existing lights, all of the options for those lights will appear on the next screen. These options are as follows: Name - Rename the group of lights to whatever name is desired. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 47 Name - Rename the sensor to whatever name is desired. Location - Select the location that the sensor is wired to. Delete a sensor - From this screen, if you wish to delete a sensor that is currently configured, USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 48 “Static” and enter the required network information. Diagnostic - This selection will re-establish a connection to your wireless network and display current network information such as wifi SSID, signal strength, and the local/gateway ip addresses. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 49 Themes. These Themes had to have been defined prior to configuring the Aux buttons. Select the desired Theme that you want to assign to the Aux button Unconfigured - If set to “Unconfigured”, the Aux button will have no function. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 50 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 51: Warranty
Aqua Plus and SwimPure chlorination products to be free of defects in materials and workman- ship, under normal use and service, for a period of three (3) years. Hayward also warrants its Aqua Trol chlorination products to be free of defects in materials and workmanship, under normal use and service for a period of one (1) year.
Page 52 Hayward is a registered trademark and Omni is a trademark of Hayward Industries, Inc. © 2022 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
