Black Under Desk Leg Clamp Hook
Instruction Manual
SKU: MOUNT-HLC1
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-hlc1
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-HLC1
Summary of Contents for Vivo MOUNT-HLC1
- Page 1 Black Under Desk Leg Clamp Hook Instruction Manual SKU: MOUNT-HLC1 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-hlc1 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 ASSEMBLY OPTIONS Bed Rail Desk Leg pg 5 pg 4 Desktop Edge pg 6...
- Page 4 Desk Leg Assembly Attach Hook (B) to the top of the Clamp Remove protective film and apply Pad (C) to Clamp (A). (A), as shown, using M5x8mm Screws (S-A) and a Phillips screwdriver. Hook should be installed on inner hole set Install assembled hook to desk leg and tighten the clamp screw to secure.
- Page 5 Bed Rail Assembly Remove protective film and apply Pad (C) to Clamp (A). Attach Hook (B) to the top of the Clamp (A), as shown, using M5x8mm Screws (S-A) and a Phillips screwdriver. Hook should be installed on outer hole set Install assembled hook to your desired surface and tighten the clamp screw to secure.
- Page 6 Desktop Edge Assembly Remove protective film and apply Pad (C) to Clamp (A). Attach Hook (B) to the side of the Clamp (A), as shown, using M5x8mm Screws (S-A) and a Phillips screwdriver. Install assembled hook to your desired surface and tighten the clamp screw to secure.
- Page 7 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
