- Page 1 Instructional Manual ENGLISH DataView PEL Control ® Panel Event Log Messages Models PEL 102, 103, 105, 52, 112, 113 & 115 PEL 102 PEL 103 PEL 112 PEL 113 PEL 52 PEL 105 PEL 115 POWER & ENERGY LOGGERS...
- Page 2 Copyright Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. © ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.
- Page 3 INTRODUCTION AEMC Instruments Model PEL 52 & PEL 100 series data loggers store a wide ® variety of measurement data. When data from a recording session is downloaded to a computer using the DataView PEL Control Panel, it is stored in an .icp file. Each .icp file includes ®...
- Page 4 RECORDING EVENT MESSAGES ■ Start of recording indicates when the recording session began. ■ Scheduled stop of recording indicates the recording reached its scheduled stop time/date. ■ The recording resumed indicates that a recording that was interrupted before completion was re-started. ■...
- Page 5 ■ SD-Card interface reset indicates the instrument cannot communicate with its SD-Card. Replace the SD-Card; if this condition still persists and/or occurs frequently, contact AEMC Technical Support. ® The following two messages are associated with the rate at which data is recorded to the SD-Card: ■...
- Page 6 DSP EVENT MESSAGES ■ The acquisition of measurements has been interrupted in the instrument indicates the instrument stopped communicating with the DSP. If this condition persists and/or occurs frequently, contact AEMC Technical Support. ® ■ The acquisition of measurements by the instrument has resumed indicates that after an unscheduled interruption, the instrument resumed receiving and recording measurement data.
- Page 7 Support. ® CONTACTING AEMC INSTRUMENTS ® For Instrument Repair and Calibration: Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® 15 Faraday Drive ▪ Dover, NH 03820 USA Phone: (800) 945-2362 (Ext. 360) / (603) 749-6434 (Ext. 360) E-mail: repair@aemc.com...
- Page 8 07/25 99-MAN 100651 v00 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: +1 (603) 749-6434 • +1 (800) 343-1391 www.aemc.com © 2025 Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ® ®...
