Summary of Contents for Walker Edison W32FWABU
- Page 5 Attach cam bolts A) to parts (3) and (4). Insert wooden dowels (C) into parts (1) and (2) as shown in the diagram.
- Page 6 Insert wooden dowels (D) into legs (5) as shown. Secure legs (5) to part (3) using bolts (L) .
- Page 7 Insert cam locks (B) to parts (1) and (2) and connect to part (3) as shown in the diagram. Secure part (4) to frame assembly using cam locks (B) as shown...
- Page 8 Attach back panel (6) to frame assembly using screws (G). Attach back panel (7) to frame assembly using screws (G).
- Page 9 Place stickers (M) in designated areas as shown in the diagram. Insert shelf supports (K) as shown in the diagram.
- Page 10 Insert shelf supports (K) as shown in the diagram. Carefully place shelf (10) unto the shelf supports.
- Page 11 Secure hinges (H) to doors (8) and (9) using screws (J). Attach handles (E) with screws (F). Attach door (9) to assembled frame using screws (J) as shown in the diagram.
- Page 12 Attach doors (8,9) to assembled frame using screws (J) as shown in the diagram.
