- Page 1 Item # : W70ARSMD Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, Walker Edison or request parts. www.walkeredison.com Revised 15/07/2019 ® © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
-
Page 2: General Assembly Guidelines
. Wipe away excess glue immediately. A Phillips head screwdriver is required for the assembly of this product . Power tools should not be used to assemble this product . © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. -
Page 3: Parts List
Parts List © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. -
Page 4: Hardware List
Ø3x12mm Screw Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. - Page 5 Step 1 Insert wooden dowel (A) into part (2), using cam bolt (B) into part (1) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 6 Step 2 Insert wooden dowel (A) into parts (3,9,10) as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 7 Step 3 Insert wooden dowel (A) into parts (5,6,7,8), using cam bolt (B) secure parts (5,6,7,8) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 8 Step 4 Using cam lock secure parts (5,6,7,8) into part (3) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 9 Step 5 Using bolt (F) attach part (2) into part (16) with hex key (G) as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 10 Step 6 Using cam lock (C) secure part (2) into parts (7,8) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.10...
- Page 11 Step 7 Using cam lock (C) secure part (2) into parts (5,6) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.11...
- Page 12 Step 8 Using bolt (F) secure part (2) into parts (9,10) with hex key (G) as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.12...
- Page 13 Step 9 Put part (15) into parts (2,5,7) as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.13...
- Page 14 Step 10 Using cam lock (C) secure part (1) into parts (3,9,10) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.14...
- Page 15 Step 11 Using screw (L) secure plastic wedge (J) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.15...
- Page 16 Step 12 Place sticker cover the holes as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.16...
- Page 17 Step 13 Insert shelf support pin into parts (3,9,10) as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.17...
- Page 18 Step 14 Put parts (11,12,13) into cabinet as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.18...
- Page 19 Step 15 Using screw (P) secure pulley (K,H) into part (14) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.19...
- Page 20 Step 16 Using screw (P) secure pulley (K,H) into part (4) with Philips head screwdriver as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.20...
- Page 21 Pick up the doors (4,14), and fit the pulley (K) over the slider rails on the bottom panel (2) ,then place the doors (4,14) into top panel (1) , till it click into pulley (H) as per diagram. © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.21...
- Page 22 Step 18 If necessary adjust the pre-attached floor levelers to level the unit . © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.22...
-
Page 23: Final Assembly
Step 19 Final Assembly © Copyright 2019 by Walker Edison Furniture Co., LLC. All rights reserved. P.23...
