ASSEMBLY & OPERATING INSTRUCTIONS
WARNING:
Read this Owner's manual carefully and be sure
your gas grill is properly assembled, installed and
maintained. Failure to follow these instructions
could result in serious injury and/or property
damage. This gas grill is intended for outdoor use
only and is not intended to be installed in or on
recreational vehicles or boats.
Note to Installer
Leave this Owner's Manual with the customer
after delivery and/or installation.
Liquid Propane Gas Grill
Model No：M305
Model No：M325
Model No：M325S
Note to Consumer
Leave this Owner's Manual in a convenient place
for future reference.
Customer Service Helpline:
For parts ordering, call:
1-800-530-9133
Please make sure the cylinder valve connection
device shall properly and safely mate with the
connection device attached to the inlet of the
pressure regulator.
1
• Parts
• Assembly
• Safety Rules
• Use and Care
• Troubleshooting
C1110800067A-A0
Advertisement
Related Manuals for Monument Grills Mesa305
Summary of Contents for Monument Grills Mesa305
- Page 1 ASSEMBLY & OPERATING INSTRUCTIONS Liquid Propane Gas Grill Model No：M305 Model No：M325 Model No：M325S • Parts • Assembly • Safety Rules • Use and Care • Troubleshooting WARNING: Note to Consumer Read this Owner’s manual carefully and be sure Leave this Owner’s Manual in a convenient place your gas grill is properly assembled, installed and for future reference.
- Page 2 B149.2, or the standard for Recreational vehicles, ANSI A 119.2, and CSA Z240 RV series retailer from any entity other than Monument Grills is not recreational vehicle code, as applicable. an original purchase and will not qualify for a warranty LP gas grill models are designed for use with a standard 20 lb.
- Page 3 Safety Precautions A tank of approximately 12 inches in diameter by 18- • Have your LP gas tank filled by a reputable 1/2 inches high is the maximum size LP gas tank to propane gas dealer and visually inspected and use.
- Page 4 WARNING Burner Flame Check A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.
- Page 5 Contents for Hardware Pack The following table illustrates a breakdown of the hardware pack. It highlights what components are used in the various stages of assembly. Tools required for assembly Philips Head Screwdriver (not included). Note: The left and right sides of the grill are on your left and right as you face the front of the grill. Philips Head Screwdriver...
- Page 6 Model M305 / M325 / M325S Assembly Diagram...
- Page 7 Model M305 / M325 / M325S Assembly List seq. NO. appellation seq. NO. appellation Lid Kit Gas Tank Holding Wire Firebox Assembly Triangle Joint Parts Side Burner Nazzle Seat Locking Caster Sider Burner Regulator Cart Bottom Board Side Burner Lamp Panel Wire Spindle Below Door Panel Side Burner Igniter Wire Cabinet Door,Right...
- Page 8 Assembly Instructions Figure 1 Please insert Locking Caster(No.21) into the Cart Bottom Board(No.22). Half screw out the screws in the bottom plate, then put Cart Right Side Panel(No.17)and Cart Left Side Panel(No. Figure 2 28)onto the relevant screw holes and screw tightly.
- Page 9 4 × A Install Cart Back Panel(No.16) onto the Figure 3 relevant place with four A screws. Half screw out the screws in the bottom and side plates, then put Triangle Joint Parts(No.20) Figure 4 onto the relevant screw holes and screw tightly.
- Page 10 4 × F Install Cart Front Bar(No.11) onto the relevant place with four F screws. Attention: magnet downward. Figure 5 Figure 6...
- Page 11 4 × A Figure 7 Screw the grill body and the cart tightly with four A screws. Half screw out the screw in the grill body, then put Side Shelf, Figure 8 Left(No.33) onto the relevant screw holes and screw tightly.
- Page 12 2 × A 2 × D Install Side Shelf, Left(No.33) onto grill body Figure 9 with A screw and D spacer. Half screw out the two big screws outside the grill body, then put Side Shelf, Right(No.13) Figure 10 onto the relevant screw holes and screw tightly.
- Page 13 2 × A 2 × D Screw Side Shelf,Right(No.13) tightly with Figure 11 A screw and D spacer inside the grill body. 1. Insert Side Shelf,Right(No.13), LED Lamp Panel(No.14) and Control Knob(No.15) as the figure shows. Figure 12 2. Insert the wire as the figure shows.
- Page 14 Half screw out the screw in Side Shelf,Right(No.13), then put it into the hole and screw tightly. Figure 13 Connect the Side Burner Igniter Wire(No.6). 1× F cut of two white plastic tie. Figure 14 Fixed Regulator connecting piece onto the Right plate with one F crew.
- Page 15 2 × C Put the Spindle Below Door Panel(No.23) into Figure 15 the relevant hole in the bottom plate. Figure 17 Install the Door Handle(No.26) onto the Cabinet Door(No.24/25).
- Page 16 Figure 19 Install the Cabinet Door (No.24/25) onto the Cart Bottom Board (No.22). Figure 20 Door gap adjustment method.
- Page 17 2× F 1. Install Grease Tray(No.29) onto Grease Pan Bracket(No.31) with two F screws. 2. Put Grease Pan(No.30) into Grease Pan Bracket(No.31). Figure 21 3. Put the grease tray into the grill body. Connect the Battery Wire. Figure 22 Paste the Battery Box(No.18) onto the side panel.
- Page 18 Put Warming Rack(No.8), Cooking Grid(No.9), Flame Tamer(No.10) into the relevant place. Figure 23 Install Gas Tank Holding Wire (No.19) onto the bottom plate. Pass Bottle Opener (No.34) through Cart Left Side Panel (No.28) Figure 24 and fix it on Bottle Opener Retainer (No.35).
- Page 19 Connecting LP Gas Tank to LP Grill 1. Place foot ring of 20 lb tank into the hole in bottom panel. Make sure the tank valve is in OFF Regulator Connection position.(Fig.21). 2. Check the tank valve to ensure it has proper external mating threads to fit the hose and regulator assembly provided.
- Page 20 Checking for LP gas leaks Never test for leaks with a flame. Prior to first use, at the beginning of each season, or every time your LP gas tank is changed, you must check for gas leaks. 1. Make a 50/50 (soap/water) mild soap solution. 2.
- Page 21 WARNING If Grill Still Fails To Light Never lean over the grill cooking area while 1. Check gas supply and connections for leaks. Check lighting your gas grill. Keep your face and body that all wire connections are secure. a safe distance (at least 18 inches) from the cooking grid surface when lighting your grill by 2.
- Page 22 Cleaning and Maintenance Cleaning Exterior Stainless Steel Surfaces •Weathering and extreme heat can cause exterior To ensure a proper working unit the following proper care stainless steel surfaces to turn tan in color. and maintenance is suggested. Machine oils used in manufacturing process of stainless steel can also cause this tanning color.
- Page 23 3. Inspect each burner for damage (cracks or holes) Regardless of which burner cleaning procedure you and if such damage is found, order and install a new use, we recommend you also complete the following burner. After installation check to ensure that gas steps to help prolong burner life.
- Page 24 Cooking Instructions Indirect Cooking WARNING To cook indirectly, the food should be placed on the Do not leave the grill unattended. left or right side of your grill with the burner lit on the Your grill will get very hot. opposite side.
- Page 25 Grill Cooking Chart WARNING: To ensure that it is safe to eat,food must be cooked to the minimun internal temperatures listed in the table below. *United States Department of Agriculture...
- Page 28 WWW.MONUMENTGRILLS.COM Scan the QR code on Facebook Join our 'Monumentgrills Lifestyle' group and receive 15% off for accessories purchase, along with access to exclusive benefits such as coupons, recipes, and giveaways shared within the group. Customer Service Helpline: 1-800-530-9133...
