ASSEMBLY & OPERATING INSTRUCTIONS
WARNING:
Read this Owner's manual carefully and be sure
your gas grill is properly assembled, installed and
maintained. Failure to follow these instructions
could result in serious injury and/or property
damage. This gas grill is intended for outdoor use
only and is not intended to be installed in or on
recreational vehicles or boats.
Note to Installer
Leave this Owner's Manual with the customer
after delivery and/or installation.
Liquid Propane Gas Grill
Model No：M405
Model No：M425
Model No：M400S
Model No：M415BZ
Note to Consumer
Leave this Owner's Manual in a convenient place
for future reference.
Customer Service Helpline:
For parts ordering, call:
1-800-530-9133
Please make sure the cylinder valve connection
device shall properly and safely mate with the
connection device attached to the inlet of the
pressure regulator.
1
• Parts
• Assembly
• Safety Rules
• Use and Care
• Troubleshooting
C1110800072A-A0
Advertisement
Related Manuals for Monument Grills M405
Summary of Contents for Monument Grills M405
- Page 1 ASSEMBLY & OPERATING INSTRUCTIONS Liquid Propane Gas Grill Model No：M405 Model No：M425 Model No：M400S Model No：M415BZ • Parts • Assembly • Safety Rules • Use and Care • Troubleshooting WARNING: Note to Consumer Read this Owner’s manual carefully and be sure Leave this Owner’s Manual in a convenient place...
- Page 2 Amazon or other marketplace internet handling code, B149.2, or the standard for Recreational retailer from any entity other than Monument Grills is not vehicles, ANSI A 119.2, and CSA Z240 RV series an original purchase and will not qualify for a warranty recreational vehicle code, as applicable.
- Page 3 Safety Precautions A tank of approximately 12 inches in diameter by 18- • Have your LP gas tank filled by a reputable 1/2 inches high is the maximum size LP gas tank to propane gas dealer and visually inspected and use.
- Page 4 WARNING Burner Flame Check A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.
- Page 5 Contents for Hardware Pack The following table illustrates a breakdown of the hardware pack. It highlights what components are used in the various stages of assembly. Tools required for assembly Philips Head Screwdriver (not included). Note: The left and right sides of the grill are on your left and right as you face the front of the grill. Philips Head Screwdriver...
- Page 6 Model M405 / M425 / M400S Assembly Diagram...
- Page 7 Model M415BZ Assembly Diagram...
- Page 8 Model M405 / M425 / M400S / M415BZ Assembly Diagram To make sure you obtain the correct replacement Important: Use only parts listed above. When parts for your gas grill, please refer to the part ordering parts, providing the following information: numbers on this page.
- Page 9 Assembly Instructions Figure 1 Please insert Locking Caster(No.22) into the Cart Bottom Board (No.23). Half screw out the screws in the bottom plate, then put Cart Right Side Panel (No.18)and Cart Left Side Panel(No. 29) onto Figure 2 the relevant screw holes and screw tightly.
- Page 10 4 × A Install Cart Back Panel (No.17) onto the Figure 3 relevant place with four A screws. Half screw out the screws in the bottom and side plates, then put Triangle Joint Parts(No.21) Figure 4 onto the relevant screw holes and screw tightly.
- Page 11 4 × F Install Cart Front Bar(No.12) onto the relevant place with four F screws. Attention: magnet downward. Figure 5 Figure 6...
- Page 12 4 × A Figure 7 Screw the grill body and the cart tightly with four A screws. Half screw out the screw in the grill body, then put Side Shelf, Figure 8 Left(No.34) onto the relevant screw holes and screw tightly.
- Page 13 2 × A 2 × D Install Side Shelf, Left(No.34) onto grill body Figure 9 with A screw and D spacer. Half screw out the two big screws outside the grill body, then put Side Shelf, Right(No.14) Figure 10 onto the relevant screw holes and screw tightly.
- Page 14 2 × A 2 × D Screw Side Shelf,Right(No.14) tightly with Figure 11 A screw and D spacer inside the grill body. 1. Insert Side Shelf,Right(No.14), LED Lamp Panel(No.15) and Control Knob(No.16) as the figure shows. Figure 12 2. Insert the wire as the figure shows.
- Page 15 Half screw out the screw in Side Shelf,Right(No.14), then put it into the hole and screw tightly. Figure 13 Connect the Side Burner Igniter Wire(No.6). 1× F cut of two white plastic tie. Figure 14 Fixed Regulator connecting piece onto the Right plate with one F crew.
- Page 16 2 × C Put the Spindle Below Door Panel(No.24) into Figure 15 the relevant hole in the bottom plate. Figure 17 Install the Door Handle(No.27) onto the Cabinet Door(No.25/26).
- Page 17 Figure 19 Install the Cabinet Door (No.25/26) onto the Cart Bottom Board (No.23). Figure 20 Door gap adjustment method.
- Page 18 2× F 1. Install Grease Tray(No.30) onto Grease Pan Bracket(No.32) with two F screws. 2. Put Grease Pan (No.31) into Grease Pan Bracket(No.32). Figure 21 3. Put the grease tray into the grill body. Connect the Battery Wire. Figure 22 Paste the Battery Box(No.19) onto the side panel.
- Page 19 Put Warming Rack(No.8), Cooking Grid(No.9/10), Figure 23 Flame Tamer(No.11/37) into the relevant place. Install Gas Tank Holding Wire（No.20) onto the bottom plate. Pass Bottle Opener (No.35) through Cart Left Side Panel (No.29) Figure 24 and fix it on Bottle Opener Retainer (No.36).
- Page 20 Connecting LP Gas Tank to LP Grill Regulator Connection 1. Place foot ring of 20 lb tank into the hole in bottom panel. Make sure the tank valve is in OFF position.(Fig.21). 2. Check the tank valve to ensure it has proper external mating threads to fit the hose and regulator assembly provided.
- Page 21 Checking for LP gas leaks Never test for leaks with a flame. Prior to first use, at the beginning of each season, or every time your LP gas tank is changed, you must check for gas leaks. 1. Make a 50/50 (soap/water) mild soap solution. 2.
- Page 22 WARNING If Grill Still Fails To Light 1. Check gas supply and connections for leaks. Check Never lean over the grill cooking area while that all wire connections are secure. lighting your gas grill. Keep your face and body a safe distance (at least 18 inches) from the 2.
- Page 23 Cleaning and Maintenance Cleaning Exterior Stainless Steel Surfaces To ensure a proper working unit the following proper care and maintenance is suggested. •Weathering and extreme heat can cause exterior stainless steel surfaces to turn tan in color. Cleaning Cooking Grids Machine oils used in manufacturing process of We suggest you wash your cooking grids in a mild soap stainless steel can also cause this tanning color.
- Page 24 3. Inspect each burner for damage (cracks or Regardless of which burner cleaning procedure you holes) and if such damage is found, order and use, we recommend you also complete the following install a new burner. After installation check to steps to help prolong burner life.
- Page 25 Cooking Instructions Indirect Cooking WARNING To cook indirectly, the food should be placed on the Do not leave the grill unattended. left or right side of your grill with the burner lit on the Your grill will get very hot. opposite side.
- Page 26 Grill Cooking Chart WARNING: To ensure that it is safe to eat,food must be cooked to the minimun internal temperatures listed in the table below. *United States Department of Agriculture...
- Page 28 WWW.MONUMENTGRILLS.COM Scan the QR code on Facebook Join our 'Monumentgrills Lifestyle' group and receive 15% off for accessories purchase, along with access to exclusive benefits such as coupons, recipes, and giveaways shared within the group. Customer Service Helpline: 1-800-530-9133...
