- Page 1 VB400 Body Camera Quick Start Guide ED-006-021-AB © 2025 Motorola Solutions, Inc. All Rights Reserved.
- Page 2 English VB400 Body Camera Overview Familiarise yourself with the buttons and functions on your body camera. Function Lens Button A Function Button B Dual Microphone Slider Front Function Button Buzzer Speaker Function Button C...
- Page 3 For more information, see the VideoManager Admin Guide . NOTE: If you try to use your VB400 before it has been assigned, the bottom LED on the front face 4. To ascertain whether your VB400 has been of the camera flashes red and the VB400 emits an successfully configured, view the top LED on your alarm tone.
- Page 4 English RFID-Card (RF-CARD-10) RFID Reader (RF-220) Having presented your RFID card, your docked, assigned VB400 identifies itself with a solid red LED as shown in the following figure. RFID Assigned Camera...
- Page 5 English Charging Your VB400 With a Dock 1. Insert the VB400 into the slots as shown in the following figure, ensuring that the camera clicks securely in place. 2. Perform one of the following actions: Slide down to click into place If you are charging your VB400 using a 14-Port ●...
- Page 6 English to either a supported USB power supply or DockController. IMPORTANT: You must ensure that any power supply used with the 1-Port Dock is limited to no more than 20W. For optimal charging, a standard 5V USB charger with a minimum wattage of 10W should be used.
- Page 7 (USB-400-EXT-CHARGE = AC-USB-MICROB-100 + VB-400- damage the camera. EXT-ADAPT). 1. Insert the VB400 into the adaptor as shown in the following figure. 2. Connect your VB400 to a standard 5V USB power supply or DockController.
- Page 8 Charging: Flashing green When fully charged, the top LED turns solid green. If the LED is not lit, the device is not charging. Your VB400 will be fully charged within 8 hours from a flat battery. Fully charged: Solid green...
- Page 9 English Battery Status LED To understand the current battery status of your VB400, press the bottom button on the front face of the VB400, and refer to the bottom LED. Colour Key: Green LED: OK Orange/Yellow LED: Low LED: Critical Battery Status Button (Configurable)
- Page 10 In case of any issues, consult your Single-press the front button. administrator. Start Recording initiated is indicated by a short The VB400 starts recording as soon as it is powered up. bleep. The two upper LEDs should be solid red. Power Down Button (Configurable)
- Page 11 VB400 Accessories Designed for optimum performance and comfort in a wide range of situations, the VB400 comes with a variety of fixing types to suit every uniform and body shape. For more information on our range of body worn cameras, visit http:// www.motorolasolutions.com/bwc.
- Page 12 English Enabling the Power Saving Mode After Charging NOTE: This feature is disabled by default. 1. Navigate to the Admin tab. 2. Select the Devices pane. 3. Click the Device Settings section. 4. In the section, set Reduced Power Device properties Consumption Mode to On.
- Page 13 English Maintenance and Care Tips ALWAYS NEVER Use compressed air to Always take a few minutes to ensure your camera is clean the camera. Com‐ working correctly before you begin any assignments. pressed air can dam‐ Performing the following basic tasks ensures that your age the camera’s micro‐...
- Page 14 This device must accept any interference received, ● including interference that may cause undesired operation. Changes or modifications made to this device, not ● expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment.
- Page 15 1. This device may not cause harmful interference, and Per FCC CRF 47 Part 2 Section 2.1077(a) Responsible party Name: Motorola Solutions, Inc. Address: 2000 Progress Pkway, Schaumburg, Il. 60196 Phone Number: 1-800-927-2744 Hereby declares that the product:...
- Page 16 English 2. This device must accept any interference received, NOTE: including interference that may cause undesired This equipment has been tested and found to comply operation. with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 17 English For Country Code Selection Usage (WLAN Devices) NOTE: The product does not have a country code selection feature. Per FCC regulations, all Wi-Fi products marketed in US must be fixed to US operation channels only.
- Page 18 English ISED WLAN Statement CAUTION: (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment complies with the e.i.r.p.
- Page 19 Federal Communications Commission of the U.S. Government. For body worn operation, this device has been tested and meets the FCC RF exposure guideline for use with a Motorola Solutions,Inc. approved accessories sold with this device. For information on product details, brochures, user manuals, and approved accessories, refer to motorolasolutions.com.
