VB400
QUICKSTART GUIDE

Advertisement

loading

  Summary of Contents for Motorola VB400

  • Page 1 VB400 QUICKSTART GUIDE...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION HOW TO CHARGE YOUR VB400 CHARGING WITH A 1-PORT DOCK CHARGING WITH A 14-PORT DOCK BATTERY STATUS LED CONFIGURING YOUR VB400 IDENTIFYING AN RFID ASSIGNED VB400 USING YOUR VB400 TO START / STOP RECORDING WEARING YOUR VB400...
  • Page 3: Introduction

    INTRODUCTION Thank you for choosing the VB400 Body-worn camera. This simple guide will lead you through the set up and use of your VB400. Function Lens Button A Function Button B Dual Microphone Slider Front Function Button Buzzer Speaker Function...
  • Page 4: How To Charge Your Vb400

    HOW TO CHARGE YOUR VB400 Upon receiving your VB400, it is recommended that you fully charge the device before usage. When charging using a 1-Port Dock or 14-Port Dock, insert the camera into the slots as shown below, ensuring the camera clicks securely in place. Check that the top LED blinks green to indicate charging.
  • Page 5: Charging With A 1-Port Dock

    Once fully charged, the same LED will turn solid green. If the LED is not lit, the device is not charging. Your VB400 will be fully charged within 8 hours from a flat battery. QUICKSTART GUIDE | VB400...
  • Page 6: Charging With A 14-Port Dock

    Once fully charged, the same LED will turn solid green. If the LED is not lit, the device is not charging. Your VB400 will be fully charged within 8 hours from a flat battery. QUICKSTART GUIDE | VB400...
  • Page 7: Battery Status Led

    BATTERY STATUS LED To quickly understand the current battery status of your VB400, press the bottom button on the front face of the camera and refer to the bottom LED. Colour Key: LED: OK Green LED: Low Orange/Yellow LED: Critical...
  • Page 8: Configuring Your Vb400

    LEDs shown are both solid green. Please Note: If you try to use your VB400 before it has been assigned, the bottom LED on the front face of the camera will start to flash red and you will hear an alarm tone. You will not be able to use your camera until it has been assigned.
  • Page 9: Identifying An Rfid Assigned Vb400

    For further information on assigning VB400s using an RFID reader, please refer to the VideoManager User Guide. Having presented your RFID card, your docked, assigned VB400 will identify itself with a solid red LED as shown. RFID...
  • Page 10: Using Your Vb400

    USING YOUR VB400 The VB400 series of cameras are intuitive and simple to use. TO START / STOP RECORDING (CONFIGURABLE) Users can activate recording by pressing on the single front button located in the centre of the badge as shown.
  • Page 11 Stop Recording initiated is indicated by the two upper LEDs turning from red to off, accompanied by a longer, high pitched bleep. Please Note: All buttons are configurable. Please consult with your administrator if you have any issues. Power Down Button (Configurable) No LED QUICKSTART GUIDE | VB400...
  • Page 12: Wearing Your Vb400

    WEARING YOUR VB400 The VB400 body-worn camera should always remain upright when capturing footage. QUICKSTART GUIDE | VB400...
  • Page 13: Accessories

    ACCESSORIES Designed for optimum performance and comfort in a wide range of situations, the VB400 comes with a variety of fixing types to suit every uniform and body shape. For more information on our range of body-worn cameras, please visit: www.motorolasolutions.com/bwc...
  • Page 14: Regulatory Information

    WARNING: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. The device must not be co-located or operating in conjunction with any other antenna or transmitter. QUICKSTART GUIDE | VB400...
  • Page 15 4.1 du document CNR-102, version 5. Tests DAS sont effectués en utilisant les positions recommandées par la CNR avec le téléphone émet à la puissance certifiée maximale dans toutes les bandes de fréquences testées sans distance attacher loin du corps. QUICKSTART GUIDE | VB400...
  • Page 16 MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners.
