Summary of Contents for HomeMatic HmIPW-DRS4
- Page 1 Wired Switching Actuator – 4 channels HmIPW-DRS4 Installation and Operating Manual...
- Page 2 Table of contents Table of contents 1 Package contents....................3 2 Information about this manual................. 3 3 Hazard information....................3 4 General system information................5 5 Function and device overview................5 6 Start-up........................6 6.1 Installation instructions....................6 6.2 Selecting the supply voltage..................7 6.3 Assembly and installation...................7 6.4 Pairing with a control unit..................9 7 Operation......................
- Page 3 Clean the device using a soft and Read this manual carefully before begin- clean lint-free cloth. Do not use any ning operation with your Homematic IP detergents containing solvents for Wired device. Keep the manual for later cleaning purposes.
- Page 4 The device is suitable for use only in planning and installation. residential environments. The device is intended for operation on the Homematic IP Wired Bus on- ly. The Homematic IP Wired Bus is a SELV power circuit. The mains voltage for the building installation and the Homematic IP Wired Bus must be routed separately.
- Page 5 General system information 4 General system information This device is part of the Homematic IP Smart Home System and communicates via the Homematic IP. Operation re- quires connection to a Homematic IP Wired Access Point. Further informa- tion on the system requirements and in-...
- Page 6 (available as an ac- cessory) may be used for connect- – Check for absence of voltage ing the Homematic IP Wired Bus. d. – Earth and short circuit – Cover or cordon off neighbouring Rigid cables can be plugged direct-...
- Page 7 • Place the device on the DIN rail. Selecting the supply voltage The voltage supply to the device is made only via the Homematic IP Wired Bus. The bus is fed by the Homematic IP Wired Access Point (HmIPW-DRAP) erating manual HmIPW-DRAP.
- Page 8 • Fit the cover of the power distribu- tion panel again. • Switch the fuse of the power circuit on . • Switch the Homematic IP wired bus on to activate the pairing mode of the device. The network terminals may be used...
- Page 9 The type of system button depends app so that you can use Wired de- on your device. Further informa- vices in the system. Homematic IP tion is to be found in the device Further information on this is to be overview.
- Page 10 Homematic IP Wired Access channel. On each button press, you Point to the (existing) Homematic IP can switch to the next channel. The Central Control Unit as described selected channel is indicated by the in the operating manual.
- Page 11 Troubleshooting • Receiver cannot be reached. • Receiver is unable to execute the command (load failure, mechanical blockage, etc.) or • Receiver is faulty.
- Page 12 Troubleshooting Flash codes and displays Flash code/display Meaning Solution 1x orange and 1x green Test display You can continue once light (after switching on the test display has the Wired Bus) stopped. Short orange flashes Pairing mode active Enter the last four dig- (every 10 s) its of the device number (SGTIN) in your app or...
- Page 13 Restoring factory settings 9 Restoring factory settings Clean the device using a soft, clean, dry The factory settings of the device and lint-free cloth. The cloth can be can be restored. If the device is slightly dampened with lukewarm water paired with a Central Control Unit, to remove more stubborn marks.
- Page 14 Technical specifications 12 Technical specifications Short description HmIPW-DRS4 Supply voltage 24 VDC, ±5 %, SELV Protection class Degree of protection IP20 Ambient temperature -5 - +40°C Weight 200 g Dimensions (W x H x D) (4HP) 72 x 90 x 69 mm Max.
- Page 15 Technical specifications Load type Relay Resistive load 16 A Light bulb test 1500 W Self-ballasted lamps (LED/compact fluorescent 200 W lamp) HV halogen lamps 1500 W Electronic transformers for LV halogen lamps 1500 W Iron core transformers for LV halogen lamps 1500 W Fluorescent lamps (uncompensated) 1500 W...
- Page 16 Free download of the Homematic IP app! Bevollmächtigter des Herstellers: Manufacturer’s authorised representative: eQ-3 AG Maiburger Straße 29 26789 Leer / GERMANY www.eQ-3.de...
