General Safety Instructions:
READ SAFETY INSTRUCTIONS
Servicing:
These products are not customer serviceable. TDK-Lambda and their authorised agents only are permitted to carry
out repairs.
Critical Components:
These products are not authorised for use as critical components in nuclear control systems, life support systems
or equipment for use in hazardous environments without the express written approval of the Managing Director
of TDK-Lambda EMEA.
Product Usage:
These products are designed for use within a host equipment which restricts access to authorised competent personnel.
This product is a component power supply and is only to be installed by qualified persons within other equipment
and must not be operated as a stand-alone product.
This product is for sale to business to business customers and can be obtained via distribution channels. It is not
intended for sale to end users.
This product is a component power supply and complies with the EMC directive. The EMC performance of a component
power supply will be affected by the final installation, compliance to the stated EMC standards and conformance to
the EMC Directive must be confirmed after installation by the final equipment manufacturer.
For guidance with respect to test conditions please visit our website at https://emea.tdk-lambda.com/EMC_guidance
or contact your local TDK-Lambda sales office.
Environmental:
These products are IPX0, and therefore chemicals/solvents, cleaning agents and other liquids must not be used.
Environment:
This power supply is a switch mode power supply for use in applications within a Pollution Degree 2, overvoltage
category II environment. Material Group IIIb PCB's are used within it.
Output Loading:
The output power taken from the power supply must not exceed the rating stated on the power supply label, except
as stated in the product limitations in this handbook.
Input Parameters:
This product must be operated within the input parameters stated in the product limitations in this handbook.
End of Life Disposal:
The unit contains components that require special disposal. Make sure that the unit is properly disposed of at the
end of its service life and in accordance with local regulations.
RISK OF ELECTRIC SHOCK
High Voltage Warning:
Dangerous voltages are present within the power supply. The professional installer must protect service personnel
from inadvertent contact with these dangerous voltages in the end equipment.
WARNING: When installed in a Class I end equipment, this product must be reliably earthed and professionally
installed.
The (+) or (-) output(s) can be earthed or left floating. The unit cover(s)/chassis must not be made user accessible.
The mains input connector is not acceptable for use as field wiring terminals. Do not use mounting screws, which
penetrate the unit more than 3mm (FPS/RFE1000), 6mm (HFE/RFE1600/2500 & racks). Special earthing screws are
used on these products which connect the cover to the chassis. They must not be removed. If they are removed by
mistake, they must be replaced with new ones and the product tested for earth bonding.
This unit must be securely mounted and its earth terminal/baseplate properly boned to the main protective earth
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HFE2500-12 and is the answer not in the manual?

Questions and answers

Summary of Contents for TDK-Lambda HFE2500-12

  • Page 1 General Safety Instructions: READ SAFETY INSTRUCTIONS Servicing: These products are not customer serviceable. TDK-Lambda and their authorised agents only are permitted to carry out repairs. Critical Components: These products are not authorised for use as critical components in nuclear control systems, life support systems or equipment for use in hazardous environments without the express written approval of the Managing Director of TDK-Lambda EMEA.
  • Page 2 MAINS supply is made. An internal fuse protects the unit and must not be replaced by the user. In case of internal defect, the unit must be returned to TDK-Lambda or one of their authorised agents.
  • Page 3 *2 For cases where conformance to various safety standards (UL, EN etc.) is required, Input Voltage to be described as 100- 240Vac (50/60Hz). *3 Maximum voltage drop on load wires: HFE2500-12: 0.25V/wire, HFE2500-24: 0.5V/wire, HFE2500-48: 1V/wire. *4 From 85~132Vac or 170~265Vac, constant load.
  • Page 4 TDK-Lambda UK Limited, Kingsley Avenue, Ilfracombe, Devon EX34 8ES. Both “Declaration of Conformity” may be accessed via company website www.emea.tdk-lambda.com/manual. All Models of HFE and RFE series are professional equipment and are not intended for sale to the general public.
  • Page 5 CAUTION: HFE2500-S1U rack is not authorized for use as critical component in nuclear control systems, life support systems or equipment for use in hazardous environments without the express written approval of the managing director of TDK-Lambda. INSTALLATION (OVERVOLTAGE) CATEGORY& ENVIRONMENTAL CONDITIONS The HFE2500-S1U has been evaluated to Overvoltage category II.
  • Page 6 OVERCURRENT PROTECTION: A readily accessible branch circuit over current protective device rated 30A max. per each input must be incorporated in the building wiring. The protective device must disconnect both supply line simultaneously. FUSES There are no fuses in the HFE2500-S1U rack. Multiple power source: Caution Shock hazard- all power sources shall be disconnected before servicing to avoid shock hazard.
  • Page 7 1. REAR PANEL CONNECTIONS AND CONTROLS Fig 1.1 Rear view of HFE2500-S1U series AC Line Inputs HFE2500-S1U Address Selection Adjustment trimmer Output Bus Bars Output Bus Bars HFE2500-S1U/TB AC Line Inputs 1.1. J1 Connector for Control and Monitoring Mating for J1 Control Plug (provided) or custom made plug/ cable should be inserted to J1 for proper operation of HFE2500 rack. Refer to Chapter 3 for connection diagrams.
  • Page 8 Table 1.1 J1 Connector Pin Allocation Chart Control Pin # Name Description Pos. # Referenced to plug J1 1,10 -SENSE Negative sense Connected to –LS for local sensing, or –V on Load side. Short Connected to Negative Output bus bar through 3 Ohm resistor. +SENSE Positive sense Connected to +LS for local sensing, or +V on Load side.
  • Page 9 Fig 1.3a Output Bus-Bars. Protection Cover Fig 1.3b Installation of Output Bus-Bars Protection Cover. 1.4. Output Voltage adjustment Trimmer Output Voltage may be adjusted by the Rear Panel Trimmer. Model HFE2500-12 HFE2500-24 HFE2500-48 Output voltage range (V) 9.6~13.2 19.2~29.0 38.4~58 “NOTE - manual trim setup not to be used with /S PMBus versions.
  • Page 10 1.5. PMBus address Each slot in the Rack (see fig-2.2) has its own address for PMBus communication. Valid only if /S option power supply is being used. In case parallel connection of two racks is used, SW1 located at the rear panel is used to differentiate between addresses for the same slots. see Table 1.5.
  • Page 11 2.3 Keying Option to define the Rack’s Voltage Keying Option can be installed to ensure that only the correct Power Supply can be inserted into the Rack. The Key Option consists of two parts: Power Supply Key (one per unit Fig 2.3a) and Rack Keys (5 per Rack Fig 2.3b). Power Supply Key and Rack Keys should be fixed (by Flat head screws M3x6) in position corresponding to Output Voltage.
  • Page 12 2.5 Rack mounting options Rack can be mounted into 19” Rack Cabinet which suits both USA and European Standards: OPTION BRACKET IA706-32-07_ SEMS SCREW M5x10 2 PLACES MARKED "A" FIX OPTION BRACKET IA706-32-07_ TO THE RACK ASSEMBLY IA706-32-01-00_ OPTION BRACKET IA706-32-06_ SEMS SCREW M5x10 2 PLACES MARKED "A"...
  • Page 13 Fig 3.1 Basic connection diagram. 3.2 Remote sensing ATTENTION: 1. Maximum voltage drop on load wires: HFE2500-12: 0.25V/wire, HFE2500-24: 0.5V/wire, 48: 1V/wire. 2. Twisted wires should be used for Remote Sense connection. 3. If Remote Sensing is used, do not break Main Output connection.
  • Page 14 3.4 Individual On/Off control for each PS Switch closed: Output OFF Switch open: Output ON Fig 3.4 individual units On/Off diagram. 3.5 Supervisory signals. Following signals are accessible from each power supply at J1: DC OK AC FAIL PS EXIST TEMP ALARM These signals are Open Collector type (Max 15V, 10mA), isolated from Output and referenced to SIGNAL RETURN.
  • Page 15 3.6.1 Output Current programming by External Voltage. Fig 3.6.1 Output Current programming by External Voltage. 3.7 Output Voltage programming by PMBus. Fig 3.7 Output Voltage programming by PMBus 3.7.1 Output Current programming by PMBus. Fig 3.7.1 Output Current programming by PMBus 3.8 PMBus Host connection To connect the rack to the Host computer, connect communication cable (refer to table 3.8 for cable connection) between J2 and computer:...
  • Page 16 3.9 Parallel connection of two Racks To connect two Racks in parallel for higher Output Current: • Connect Main Output (Bus-Bars) in parallel. Make the connections as short as possible and with equal length. • Connect Sense (twisted pairs) to Load point. •...
  • Page 17 3.10 Series Rack connection Up to 2 racks with the same number of power supplies and rating (voltage and current) can be used to increase the output voltage. To connect two Racks in series: • Connect Main Output (bus bars) in series; •...
  • Page 18 HFE2500 - S1U Outline Drawing...
  • Page 19 HFE2500 - S1U-TB Outline Drawing...
