HFE1600/S (Optional PMBus) Series Instruction Manual.
HFE1600 SERIES SPECIFICATIONS:
1
Rated output voltage
2
Output voltage set point
3
Output voltage range
4
Rated Output Current at Vin ≥ 170Vac
5
Rated Output Current at 100 ≤ Vin ≤ 132Vac
6
Rated Output Current at 85V ≤Vin < 100Vac
7
Rated output power Vin ≥ 170Vac
8
Rated output power 100 ≤ Vin ≤ 132Vac
9
Rated output power 85Vac ≤ Vin < 100Vac
10 Input voltage / frequency range
11 Maximum input current (115/230Vac)
12 Power Factor (Typ) (100/230Vac) at full load
13 Efficiency at 75% rated load (Typ)
14 Efficiency at 100% rated load (Typ)
15 Inrush current
16 Hold-up time
17 Maximum line regulation
18 Max load regulation
Output Ripple and noise P-P
19
20 Temperature stability
21 Temperature coefficient of output voltage
22 Remote sensing
23 Parallel operation
24 Series operation
25 Over current protection 85 ≤ Vin ≤ 132Vac
170 ≤ Vin ≤ 265Vac
26 Over voltage protection
27 Over temperature protection
28 Remote On/Off control
29 "DC OK" signal
30 Over-Temperature warning
31 "AC FAIL" signal
32 Auxiliary power supply output
33 Vout programming by external voltage
34 Vout programming by external resistor
35 Front panel indicators
36 I²C Interface
37 Operating temperature
38 Storage temperature
39 Operating humidity
40 Storage humidity
41 Cooling
42 Vibration
43 Shock
44 Conducted emission
45 Radiated emission
46 Immunity
47 Applicable safety standards
Input-Output:
48 Withstand voltage
Input-Ground:
Output - Ground:
49 Insulation resistance
50 Leakage current
51 Weight (Typ)
52 Size (W*H*D)
HFE1600-12/S HFE1600-24/S HFE1600-32/S HFE1600-48/S
V
V
V
9.6~13.2
(*1)
A
(*1)
A
(*1)
A
Linear derating 1% per 1VAC from output current at 100VAC:
W
W
W
(*2)
---
A
---
(*3)
%
87/90%
(*3)
%
87/90%
(*4)
A
mS
(*5)
%
(*6)
%
(*7) 0~+70°C
mV
-10~0°C
mV
%
PPM/°C
(*8)
---
Single wire current share, 5% accuracy of rated Iout, up to 10 units.
(*9)
---
---
(with external diodes), 2 units. Refer to instruction manual.
%
(*10)
V
---
Two complementary inputs. By electrical signal or dry contact.
---
(*13)
---
(*13)
---
(*13)
---
(*11)
---
---
By 0~5V, equal to Vout min ~ Vout max . Refer to Instruction Manual.
---
---
---
Optional, PMBus compatible. Refer to Instruction Manual.
(*14)
---
---
---
---
---
---
---
---
Built to meet EN55022 Class B, FCC part 15 Class-B, VCCI Class-B
---
Built to meet EN55022 Class A, FCC part 15 Class-A, VCCI Class-A
Built to meet IEC61000-4-2 (Level 2,3), -3 (Level 2), -4 (Level 2),
---
---
---
---
500VAC 1min. 500VAC 1min. 500VAC 1min. 2250VDC 1min (POE)
---
---
More than 100MΩ at 25°C and 70% RH. Output-Ground: 500Vdc
(*12)
mA
Kg
---
1
12
24
32
12±1%
24±1%
32±1%
19.2~29.0
25.6~38.4
133
67
47
100
50
37.5
1596
1608
1500
1200
1200
1200
Linear derating 1% per V
85~265Vac continuous, 47~63Hz, Single phase
12.4/8.1
>0.99/0.98
88/90%
88/90%
87/90%
87/90%
Less than 35A
≥ 10mS typical at 115/230Vac input,
rated output voltage and less than 80% of rated load.
0.25%
0.50%
240
240
320
360
360
580
0.05% of rated Vout for 8hrs after 30min warm-up.
Constant line, load and temperature.
±200
Refer to instruction manual.
of the same voltage and the same current rating.
Minimum 105% of rated output current.
105~120% of rated output current.
Tracking OVP, range: 1.1xVout ,Accuracy:±3%,
Refer to Instruction Manual.
Inverter shut down, automatic restart.
Refer to instruction manual.
Tracking, On when Vout>90±5% of set output voltage.
Open collector signal. Max sink current: 10 mA.
Refer to instruction manual.
Open collector signal. Max sink current: 10 mA.
On when 85Vac<Vin<270Vac.
Open collector signal. Max sink current: 10 mA.
11.2~12.5V, 0.5A. 240mVp-p ripple and noise
By 1Kohm potentiometer . Refer to Instruction Manual.
AC OK, DC OK/FAIL
-10~+50°C. 100% load.
+50°C to +60°C Derate Output by 2%/°C.
+60°C to +70°C Derate Output by 2.5%/°C.
-30~85°C
10~90% RH, no condensation.
10~95% RH, no condensation.
By internal Fans. Variable speed control
based on ambient temperature and power level.
Built to meet IEC60068-2-64 (Basic Transportation)
Built to meet IEC60068-2-27 (Basic Transportation)
-5 (Level 3,4), -6 (Level 2), -8 (Level 4), -11
UL60950-1 Second Edition, EN60950-1 Second Edition
3000Vrms, 1min.
2000Vrms, 1min.
Less Than 0.75/1.5mA at 115/230Vac range
Max. 1.55
85x41x300mm. Refer to Outline Drawing.
48
48±1%
38.4~58
33
25
1584
1200
89/92%
88/91%
480
780
