BEFORE USING THE POWER SUPPLY UNIT
Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before using
this product. Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
DANGER
·
Never use this product in locations where flammable gas or ignitable substances are present.
INSTALLATION WARNING
·
When installing, ensure that work is done in accordance with the instruction manual.
When installation is improper, there is risk of electric shock and fire.
·
Installation shall be done by Service personnel with necessary and appropriate technical training and experience.
There is a risk of electric shock and fire.
·
Do not cover the product with cloth or paper etc. Do not place anything flammable around.
This might cause damage, electric shock or fire.
WARNING on USE
·
Do not touch this product or its internal components while circuit in operation, or shortly after shutdown. You may receive a burn.
·
While this product is operating, keep your hands and face away from it as you may be injured by an unexpected situation.
·
For products with no cover, do not touch them as there are high-voltage and high temperature parts inside.
Touching them might cause injury such as electric shock or burn.
·
There are cases where high voltage charge remains inside the product immediately after the input is cut off.
Therefore, do not touch even if they are not in operation as you might get injured due to high voltage and high temperature.
You might also get electric shock or burn.
·
Do not make unauthorized changes to this product nor remove the cover as you might get an electric shock or might damage the
product. We will not be held responsible after the product has been modified, changed or dis-assembled.
·
Do not use this product under unusual condition such as emission of smoke or abnormal smell and sound etc.
Please stop using it immediately and shut off the product. It might lead to fire and electric shock. In such cases, please contact us.
Do not attempt repair by yourself, as it is dangerous for the user.
·
Do not operate and store these products in environments where condensation occurs due to moisture and humidity.
It might lead fire and electric shock.
·
Do not drop or apply shock to this product. It might cause failure. Do not operate these products mechanical stress is applied.
·
When necessary, this products is to be repaired only by us or our authorized agents. It is important that this product cannot be used
in hazardous environments (facilities such as nuclear power control system or life support equipment) without our written consent.
·
Do not drop or insert anything into unit. It might cause failure and fire, when using the unit under such condition.
·
The outputs of these products must be earthed in the end use equipment to maintain SELV.
If the outputs are not earthed, they must be considered hazardous and must not be made user accessible.
CAUTION on MOUNTING
·
Confirm connections to input/output terminals are correct as indicated in the instruction manual before switching on.
·
Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications,
otherwise the product will be damaged.
·
Input line, please use the wires as short and thick as possible.
·
Do not use this product in special environment with strong electromagnetic field, corrosive gas or conductive substances and
direct sunlight, or places where product is exposed to water or rain.
·
Mount this product properly in accordance with the instruction manual, mounting direction and shall be properly ventilated.
·
Please shut down the input when connecting input and output of the product.
·
When installing in environment where conductive foreign, dust and liquid may be present, please consider penetration of above
foreign material in the power supply by installing filter, to prevent trouble or malfunction.
·
This power supply is primarily designed and manufactured to use and enclose in other equipment.
·
This power supply unit has a built-in fan for air-cooling. Do not block air intake and exhaust. It might cause fire.
·
Do not operate and store this unit at the condition of condensation. In such case, waterproof treatment is necessary.
HWS 1000/ME Series
Instruction Manual
-1-
TDK-Lambda
HWS1000/ME Series
INSTRUCTION MANUAL
DA032-04-80/ME-E

Advertisement

Table of Contents
loading

Summary of Contents for TDK-Lambda HWS 1000/ME Series

  • Page 1 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL HWS 1000/ME Series Instruction Manual BEFORE USING THE POWER SUPPLY UNIT Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before using this product. Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
  • Page 2: Caution On Use

    These products are not authorized for use as critical components in nuclear control systems, life support systems, vehicle, ship, aerospace or equipment for use in hazardous environments without the express written approval of the Managing Director of TDK-Lambda Corp.. GENERAL INSTALLATION INSTRUCTIONS ·...
  • Page 3 When using it as a patient care equipment, all outer surfaces of the equipment shall be constructed of nonconductive material. See Clause 19.5DV.2 of UL60601-1. · These products have not been assessed to IEC/EN60601-1-2 (EMC) but EMC test data is available from TDK-Lambda Corp.. Note ·...
  • Page 4 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 1. Model name identification method HWS1000-24 /ME Option Rated Output Voltage Output Power type Series name 2. Terminal Explanation Please pay extra attention to the wiring. Incorrect connection will damage the power supply. · When connecting input and output wiring, input AC-Line should be off.
  • Page 5 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 2-2. CN01, CN02 Connector pin configuration and Function CN01, CN02 pin configuration and function are the same. They are connected to each other in this power supply unit. When the pin of CN01 side is shorted the same function pins of CN02 side are shorted.
  • Page 6 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 2-3. Basic Connection (Local sensing) 2-4. Remote sensing required ①Connect “+S” terminal to “+V” terminal and ①Connect “+S” terminal to “+” terminal of load with “-S” terminal to “-V” terminal with sensing sensing wire wires.
  • Page 7 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 2-5. Remote ON/OFF control required 2-6. PF signal output required ①Remove standard attached connector, and use the harness ①PF signal is an open collector output, therefore made by the customer and connect external signal to between PF signal outputs is shown in circuit below.
  • Page 8: Block Diagram

    TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 3. Block Diagram Input Output 85~265VAC Photo- Circuit coupler Sensing Circuit Circuit output Photo- Delay Voltage Circuit coupler Circuit Detection Output Photo- Sensing coupler Output Current Balance Standby Reference supply Voltage Photo- coupler Remote ON/OFF...
  • Page 9: Sequence Time Chart

    TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 4. Sequence time chart Input Voltage PF Si gnal Point OVP Poi nt OVP Point OCP Poi nt OCP Poi nt (80% or les s) (※2) (Shut down) (※2) (Shut down) (105% or more) (105% or more) (※3)
  • Page 10 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5. Functions and Precautions 5-1. Input Voltage Range Input voltage range is single phase 85 - 265VAC (47 - 63Hz). Input voltage, which is out of specification, may cause unit damage. Rated input voltage range fix during safety standard application is from100V to 240VAC (50/60Hz).
  • Page 11 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-7. Remote Sensing (+S, -S terminal) Remote sensing function is provided to compensate for voltage drop across the wiring from the power supply output terminals to the load input terminals. Connect “+S” terminal to “+” terminal of the load and “-S” terminal to “-” terminal of the load with sensing wires.
  • Page 12 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-9. Output Ripple & Noise Maximum ripple & noise value in specifications is measured according to measurement circuit specified by JEITA-RC9131A. When Load lines are longer, ripple & noise becomes larger. In this case, electrolytic capacitor, film capacitor, etc.
  • Page 13 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-11. Parallel Operation Current balancing function is provided. Either of operations mode (A) or (B) is possible. (A)To Increase the Output Current Current balancing function activates by connecting PC-to-PC terminal and COM-to-COM terminal, and output current of each power supply is equivalently supplied to load.
  • Page 14 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-12. Isolation Test Isolation resistance between output and E (chassis) shall be more than 100MW at 500VDC and between output and CNT・PF shall be more than 10MW at 100VDC. For safety operation, voltage setting of DC isolation tester must be done before the test.
  • Page 15 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-13. Withstand Voltage This series is designed to withstand 3.0kVAC between input and output, 2.0kVAC between input and E (chassis), 500VAC between output and E (chassis), and 100VAC between output and CNT・PF terminal each for 1 minute. When testing withstand voltage, set current limit of withstand voltage test equipment at 20mA.
  • Page 16: Connection Method

    TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-14. Output Voltage External Control (PV) (A) Control by External Voltage Output voltage external control function is provided. Output voltage can be varied by applying an external voltage (1 - 6V DC) to “PV” terminal and “COM” terminal. Note if an external voltage is not applied, there will be no output.
  • Page 17: Power Supply

    TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL (B) Control by External Variable Resistor “PV” terminal and “COM” terminal usage is the same as explained in section 「control by external voltage」. But in this method voltage for control is supplied through REF terminal. Variable resistor is connected between REF terminal and COM terminal and the middle point of variable resistor is connected to PV terminal.
  • Page 18 TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 5-15. Output peak Current For model with output peak current, please meet the following condition. Reduce peak current value according to output derating as section 6-1. The output is shut down by protection circuit when rated current and continuous peak output time (τ) exceeds rated value during usage.
  • Page 19: Mounting Directions

    TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL 6.Mounting Directions 6-1. Output Derating Mounting directions are as follows. Standard mounting method is (A). Methods (B), (C), (D), (G) and (H) are also possible. Mounting methods besides (A),(B),(C),(D),(G) and (H) (example : (E) and (F)) are inhibit.
  • Page 20: Wiring Method

    Output terminal (M8 Bolt & Nut) : 10.8N・m (7) Recommended wiring Noise Filter HWS1000 Circuit Protector AC(L) + AC(L) AC(L) AC(L) Load ~ AC(N) - AC(N) AC(N) AC(N) Chassis of the equipment Recommended circuit protector : AC250V20A Recommended noise filter : RSEN-2020 (TDK-Lambda Corp.) -20-...
  • Page 21: Troubleshooting

    TDK-Lambda HWS1000/ME Series INSTRUCTION MANUAL (8) M4 screw for output terminal might damage the terminal’s inner thread. This is mainly cause by the M4 screw’s unthread section. Therefore, please select a washer, spring washer, etc. to avoid unthread screw section from penetrating into output terminal inner section.
  • Page 22: Warranty Period

    UKCA Marking, when applied to a product or packing material for a product covered by this handbook, indicates compliance with the Electrical Equipment (Safety) Regulations, Electromagnetic Compatibility Regulations and Restriction of the Use of Certain Hazardous Substances in Electrical & Electronic Equipment Regulations. TDK-Lambda Corp. OFFICE : 2704-1 SETTAYA-MACHI, NAGAOKA-SHI, NIIGATA JAPAN TEL +81-258-22-1234...

This manual is also suitable for:

Hws1000-24Hws1000-36Hws1000-48
