BEDIENUNGSANLEITUNG
KBS Gastrotechnik GmbH – Schoßbergstraße 26 – 65201 Wiesbaden
www.kbs-gastrotechnik.de
Stand März 2025
*Für Druckfehler keine Haftung

Advertisement

loading
Need help?

Need help?

Do you have a question about the KPRO COMPACT and is the answer not in the manual?

Questions and answers

Summary of Contents for Kinetico KPRO COMPACT

  • Page 1 BEDIENUNGSANLEITUNG KBS Gastrotechnik GmbH – Schoßbergstraße 26 – 65201 Wiesbaden www.kbs-gastrotechnik.de Stand März 2025 *Für Druckfehler keine Haftung...
  • Page 2 KPRO COMPACT DIRECT FLOW MANUAL English Version...
  • Page 3 INDEX User manual Technical manual Technical data sheet 9-15 Spare Parts list...
  • Page 4 USER MANUAL 1. INTRODUCTION the functionality and status indications, as well as the different security systems. Congratulations. You have acquired excellent equip- The equipment’s technical data sheet describes the ment for commercial HORECA Use. states in which the system can be found and the infor- mation provided by it.
  • Page 5 5. TROUBLESHOOTING TROUBLE POSIBLE CAUSE SOLUTION • Several possible causes. • Call for service. 1. Leak to the outside the equipment. • There is no water supply. • Wait for the supply to return. 2. Zero production. • There is no power supply. •...
  • Page 6 TECHNICAL MANUAL 1. MAIN FEATURES Water treatment Reverse osmosis for Commercial Use (HORECA) Modifications for reduction or contribution -Water treatment by reverse osmosis is capable of reducing concentrations of salts and other substances in high percentages. -Minimal reduction * of certain compounds and parameters: Sodium: 85%.
  • Page 7 In case the water to be treated contains: ATTENTION: The equipment must not be installed • High concentrations of iron and manganese (Greater next to a heat source or directly receiving a flow of than 1ppm measured in the rejection of the machine). • hotairover it .
  • Page 8 an adjoining piece of furniture. Install the production outlet, drain collar and inlet adapter and connect them to the respective equipment connectors (6 and 7). 6 mm 6. START-UP 6.1. FILTER RINSING • It is necessary to eliminate the dust of the carbon filter that is generated during the transport and handling of the equip- ment.
  • Page 9 the equipment are accessed or no water has been consu- med for more than a month. * Depending on the intended use and characteristics of the water to be treated. ATTENTION: All consumables are supplied in indivi- dual packaging specially designed to guarantee hygie- nicstorageandtransportconditions.
  • Page 10 TECHNICAL DATA SHEET 1. MAIN FEATURES 4 bar - 1 bar (400kPa-100kPa). Pressure (max/min): 1500ppm. TDS (max): 38 ºC - 5 ºC. Temperature (max/min): 150 ppm Hardness (max): 1. Filter/Bypass Connection Maximum pressure switch. Inlet control Control type: 2. Outlet Connection solenoid valve.
  • Page 11 CF pre-filter 1 x sediment / carbon combined. RO Membrane 1 x 1000 GPD membrane. (RO+CB) OUT/PURE WASTE Power Supply: 36 VDC Adapter: 230 VAC 50/60Hz: 36VDC 5A Production: 2,6 l/min (inlet water Conditions: 450µS, 15°HF, 17°C and 3 bar Automatic Flushing (See Section 3.3) HYDRAULIC SCHEME Manual Bypass External...
  • Page 12 * For salinities higher than 1500ppm consult with your dealer. * Higher hardnesses may reduce the life and perfor- mance operation of certain components. ** Maximum accumulation as a function of the pres- sure entry. **** Flow rates may vary by 20% depending on of the temperature, pressure and specific composition of the water to be treated.
  • Page 13 3.3. FUNCTIONALITIES FUNCTION ACTION STATUS OF THE LIGHTS 1. Functional flushing The machine will flush the RO membra- During washing, the water quality light is ne for 5 minutes. flashing at 1Hz. for the first use or after reset. 2. Flushing when tur- Whenever the system is started it will When flushing is in progress, the water flush the RO membrane for 20 seconds.
  • Page 14 3.4. BUG IDENTIFICATION AND RESOLUTION TYPE TIMER SOLUTION DISPLAY ACOUSTIC 1. Leak inside the Water quality indicator, Beeps for 3 When the leak is eliminated, the alarm CF and MRO flashing minutes. is deactivated and it returns to the nor- machine.
  • Page 15 3.7. 3.6. SMART DEVICE STATUS INDICATORS The smart device replicates on its outer ring the status of the filters that are seen on the equipment display (CF, MRO). The droplet symbol replicates the status of the water quality indicator LED. CODE CHANGE IN INTERFACE (Code Table see next Ring: Life Status of the page):...
  • Page 16 3.7. CODE TABLE FOR THE EXTERNAL DEVICE PROGRAM PRETREATMENT LED QUALITY FILTER NUMBER DESCRIPTION INDICATOR LIFETIME Blue: TDS ≤200ppm No pre-treatment with TDS Prefilter CF: 6 month or 8000lts Lilac: 200ppm < TDS ≤300ppm inlet water 0-750ppm Membrane RO: 36 month or Red: TDS >...
  • Page 17 Spare parts list...
  • Page 20 KPRO COMPACT HANDBUCH Deutsche Version...
  • Page 21 INDEX Seite Bedienungsanleitung Technisches Handbuch Technisches Datenblatt 9-15 Ersatzteilliste...
  • Page 22 BEDIENUNGS- ANLEITUNG 1. EINLEITUNG Glückwunsch. Sie haben ein hervorragendes Gerät für SCHNITTSTELLE MIT DEM den gewerblichen HORECA-Einsatz erworben. BENUTZER 2. HINWEISE ACHTUNG: Dieses Gerät verfügt über eine elektronische Steuerung, die die Funktionalität ACHTUNG: Bitte lesen sorgfältig und Statusanzeigen sowie die verschiedenen Warnhinweise im entsprechenden Abschnitt des Sicherheitssysteme effizient kontrolliert.
  • Page 23 5. FEHLERBEHEBUNG FEHLER MÖGLICHE URSACHE LÖSUNG 1. Leakage zur • Mehrere mögliche Ursachen. •Rufen Sie den Service an. Außenseite des Geräts • Es gibt keine 2. Keine Produktion. • Warten Sie, bis die Versorgung wie derhergestellt ist. Wasserversorgung • Überprüfen Sie die Stromversorgung im Raum. Wenn das •...
  • Page 24 TECHNICHES HANDBUCH 1. HAUPTMERKMALE Wasseraufbereitung Umkehrosmose für gewerbliche Nutzung (HORECA). Bei Anschluss an eine gewerbliche Spülmaschine ist darauf zu achten das die Spülmaschine eine integrierte Druckerhöhungspumpe besitzt. - Die Wasseraufbereitung durch Umkehrosmose ist in der Lage, die Konzentration von Salzen und anderen Substanzen in hohen Prozentsätzen zu reduzieren.
  • Page 25 • Eine Nitratkonzentration von mehr als 100 ppm. · verwenden Sie die neuen, mit dem Gerät gelieferten • Eine Sulfatkonzentration von mehr als 250 ppm. Schlauchsätze. Die alte Schlauchsätze dürfen nicht Wenden Sie sich an Ihren Händler, um die am wiederverwendet werden.
  • Page 26 angrenzenden Möbelstück. Installieren Produktionsauslass, Ablaufkragen Einlassadapter schließen diese jeweiligen Geräteanschlüsse (6 und 7) an. 6 mm 6. INBETRIEBNAHME 6.1. FILTERSPÜLEN • Es ist notwendig, den Staub des Kohlefilters zu entfernen, der beim Transport und bei der Handhabung des Geräts entsteht. Dieser Staub muss entfernt werden, da er die Membran teilweise oder vollständig verstopfen und zu einer Fehlfunktion des Geräts führen kann.
  • Page 27 zugegriffen wird oder wenn seit mehr als einem Monat kein Wasser verbraucht wurde. * Abhängig vom Verwendungszweck und den Eigenschaften des aufzubereitenden Wassers. ACHTUNG: Alle Verbrauchsmaterialien werden in Einzelverpackungen geliefert, speziell darauf ausgelegt sind, hygienische Lager- Transportbedingungen zu gewährleisten. Treffen Sie Hygienevorkehrungen, nachdem Verbrauchsmaterialien aus der Verpackung genommen...
  • Page 28 TECHNISCHES DATENBLATT 1. HAUPTMERKMALE 4 bar - 1 bar (400kPa-100kPa). Druck (max/min): TDS 1500ppm. (max): 38 ºC - 5 ºC. Temperatur (max/min): 150 ppm Härte (max): 1. Filter-/Bypass-Verbindung Maximaldruckschalter. Steuerungsart: 2. Auslassanschluss Einlasssteuermagnetventil. 3. Einlassanschluss 4. Abflussanschluss Spülmagnetventil. Sicherheitssystem Elektronischer Lecksensor. Kontrolle der Wasserqualität.
  • Page 29 CF Vorfilter 1 x Sediment / Kohlenstoff kombiniert. RO Membrane 1 x 1000 Gallonen pro Tag membrane. (RO+CB) Eingang Ausgang/RE Stromversorgung: 36 VDC Adapter: 230 VAC 50/60Hz: 36VDC 5A Produktion: 2,6 l/min (Zulaufwasserbedingungen: 450µS, 15°HF, 17°C und Automatische Spülung mit 3 bar (siehe Abschnitt 3.3) HYDRAULIKSCHEMA Manueller Bypass extern...
  • Page 30 * Bei Salzgehalten über 1500 ppm wenden Sie sich * For salinities higher than 1500ppm consult with your HYDRAULISCHER ANSCHLUSSPLAN an Ihren Händler. dealer. * Höhere Härten können die Lebensdauer und * Higher hardnesses may reduce the life and perfor- Leistung bestimmter Komponenten verringern.
  • Page 31 3.3. FUNKTIONALITÄTEN FUNKTION HANDLUNG STATUS DER LICHTER 1. Funktionelle Spülung Die Maschine spült die RO-Membran Während des Waschens leuchtet die für 5 Minuten. Wasserqualitätsanzeige mit 1 Hz. für den ersten after reset. Gebrauch bzw 2. Spülung beim Bei jedem Systemstart wird die RO- Während der Spülung zeigt die Wasser- Membran 20 Sekunden lang gespült.
  • Page 32 3.4. FEHLERIDENTIFIZIERUNG UND -BEHEBUNG HINWEIS LÖSUNG ANZEIGE AKUSTISCH 1. Leck im Inneren der Wasserqualitätsanzeige, Wenn das Leck beseitigt ist, wird der Piept 3 Minuten CF und MRO blinken rot Alarm deaktiviert und es kehrt in den lang. Gerät Normalzustand zurück. Die Pumpe hat zwischen 30 und 33 2.
  • Page 33 3.7. SMART-GERÄTESTATUSANZEIGEN Das Smart-Gerät reproduziert auf seinem Außenring den Status der Filter, die auf dem Gerätedisplay (CF, MRO) angezeigt werden. Das Tropfensymbol gibt den Status der Wasserqualitätsanzeige-LED wieder. CODEÄNDERUNG IN DER SCHNITTSTELLE (für Ring: Lebensstatus des Codetabelle siehe nächste Seite): Filters und der Membran Um das Programm des Geräts zu ändern, gehen Sie wie folgt vor:...
  • Page 34 3.7. CODETABELLE FÜR DAS EXTERNE GERÄT PROGRAMM- BESCHREIBUNG DER LED-QUALITÄTS- LEBENSDAUER NUMMER VORBEHANDLUNG ANZEIGE DES FILTERS Blau: TDS ≤200ppm Keine Vorbehandlung mit Vorfilter CF: 6 Monate oder 8000 ltr Lila: 200ppm < TDS ≤300ppm TDS-Einlasswasser 0–750 RO Membran: 36 Monate oder Rot: TDS >...
  • Page 35 Ersatzteilliste...
  • Page 36 Zeichen. Artikelnummer Teilname POSITIONIERUNGSPAD 100-2511 KARTUSCHENSITZ 100-2512 EINLASS-MAGNETVENTIL 100-2513 HYDRAULIK-SET 100-2514 ELEKTRONISCHE KARTE 100-2515 "T" ADAPTER 100-2516 SMARTES DISPLAY 100-2517 100-0009 MEMBRANE 100-0008 RO KOMBI SEDIMENT CARBON BLOCK 100-2518 ROHR 1/4 ROHR 1/4 WEISS 100-2519 100-2521 ROHR WEISS 100-2522 OBERDECK 100-2523 DRUCKERHÖHUNGSPUMPE 100-2524...
