WELCOME Thank you for buying Segway Powersports vehicle. Segway off-road vehicles will bring you a new driving experience. For your driving safety, please read this manual before riding. This manual contains safety and operation instructions, maintenance procedures and safety warnings.
INCORPORATED. Unless noted, trademarks are the property of Segway Powersports Inc. Copyright 2025 Segway Powersports Inc. All information contained within this publication is based on the latest product information at the time of publication. Due to constant improvements in the design and...
Failure to follow warnings and safety precautions contained in this manual will result in severe injury or death. your SEGWAY vehicle is not toy and it can be hazardous to operate. This vehicle handles differently than cars, trucks or on-road vehicles. A collision or rollover can occur quickly, even during routine maneuvers like turning, driving on hills or over obstacles if you fail to take proper precautions.
Page 6
• Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants and over-the-ankle boots. • Never operate this vehicle under the influence of drugs or alcohol, as these impair judgement and reduce the operator's ability to react. • Complete the new operator driving procedures outlined this manual.
Page 7
Meaning of signs : WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
SAFETY INTRODUCTION SAFETY WARNING LABELS ............3 SEVERE INJURY OR DEATH ..........8 IMPORTANT SAFETY INFORMATION ........11 READING THE MANUAL ............11 SAFE DRIVING AGE ............... 12 RIDING EQUIPMENT .............. 13 USING ALCOHOL OR DRUGS ..........15 VEHICLE MODIFICATIONS ............. 16 CARRYING PASSENGERS .............
Page 9
SAFETY Failure to follow the warnings and safety precautions in this manual may result in serious injury or death. It can be dangerous to operate off-road vehicles. UTV vehicles behave differently from other vehicles, such as motorcycles or automobiles. If proper precautions are not taken, a collision or rolled-over may occur even during normal maneuvers such as turning, climbing, or riding over obstacles.
Read and follow the instructions on the labels carefully. If any of the labels depicted in this manual differ from the labels on your vehicle, always read and follow the instructions on the vehicle. If any label becomes illegible or comes off, contact Segway Powersports dealer for a replacement.
Page 12
SAFETY WARNING Rollovers have caused severe injuries and death, even on flat, open areas. Improper Use of this Vehicle Can Cause Severe Injury or Death Be Sure Riders Pay Attention and Plan Ahead Require Proper Use of your Vehicle Drive Responsibly Be Prepared Do your part to prevent injuries: •Do not allow careless or If you think or feel the vehicle may tip or roll, reduce your risk...
Page 13
SAFETY This roll over protective structure meets the performance requirements of (EU) No 1322/2014 Annex VIII . WARNING WARNING WARNING U06-L110003-LEN-00...
Page 14
SAFETY CAUTION of the Segway Owner’s Manual , otherwise it may seriously damage Your engine. U06-L100015-000-00 WARNING...
SAFETY SEVERE INJURY OR DEATH Can result if you do not follow these instructions: • Minimum recommended age for driving this vehicle is 16 years. • Never operate this vehicle without wearing an approved motorcycle helmet that fits properly. • Wear eye protection (goggles or a face shield), gloves, over- the-ankle boots, long-sleeved shirt or jacket, and long pants.
Page 16
SAFETY • Always keep both hands on the steering wheel when driving. • Always go slowly and be careful when operating on unfamiliar terrain. Always be alert to changing terrain conditions when driving the vehicle. • Never wrap your thumbs and fingers around the steering wheel.
Page 17
SAFETY • Do not brake abruptly when carrying loads in the cargo bed. • Always use the size and type of tires specified in this manual. • Always maintain proper tire pressure as described in this manual. • Never exceed the stated cargo load capacity. Cargo should be as far forward in the bed as possible, and distributed evenly from side to side.
SAFETY IMPORTANT SAFETY INFORMATION READING THE MANUAL WARNING Driving this vehicle improperly increases the risk of accidents. The driver must know how to drive the vehicle correctly in different situations and on different terrains. Before driving the vehicle, all drivers must complete the required driving safety training.
SAFETY SAFE DRIVING AGE WARNING The minimum recommended driving age for this vehicle is 16 years. Children under the age of 16 must not drive this vehicle. Not to drive the vehicle without proper driving training. Training courses are required. Please ensure that each driver has read this manual and all product labels and has completed a safety training course.
SAFETY RIDING EQUIPMENT WARNING For your safety, we strongly recommend that you always wear an approved motorcycle, eye protection, boots, gloves, long pants and a long-sleeved shirt or jacket whenever you ride. Although complete protection is not possible, wearing proper gear can reduce the chance of injury when you ride.
Page 21
SAFETY WARNING Always wear an approved motorcycle helmet, eye protection, gloves, a long-sleeved shirt or jacket, long pants and over- the-ankle boots. Appropriate clothing reduces the possibility of injury. Approved helmet Eye protection Long sleeves shirt Gloves Long pants Boots...
SAFETY USING ALCOHOL OR DRUGS WARNING Operating this vehicle after consuming alcohol or drugs could adversely affect operator judgment, reaction time, balance and perception. Never consume alcohol or drugs before or while operating this vehicle.
SAFETY VEHICLE MODIFICATIONS WARNING Do not attempt to increase vehicle speed or use any equipment that increases the power of the vehicle. If any equipment is added to the vehicle, or if any modifications are made to the vehicle to increase vehicle speed or power, the vehicle warranty is terminated.
Page 24
SAFETY PASSENGERS WARNING Do not carry passengers unless you have operated the vehicle for at least 2 hours and have completed the new operator driving instructions outlined on page 64. Passengers must always sit in the passenger seat with the seat belts fastened. Carrying more than one passenger in a two-seater vehicle affects the operator's ability to control the vehicle, which increases the risk of accident or rollover.
SAFETY CONTACT WITH EXHAUST WARNING Engine exhaust is toxic and can cause loss of consciousness or death in a short time. Do not start or run a motor in a closed areas. The engine exhaust of this vehicle contains chemicals that cause cancer, birth defects or other reproductive damage, and you can only drive it outside the room or in a well-ventilated place.
SAFETY SEAT BELTS Riding in this vehicle without wearing the seat belt may increase the risk of serious injury in the event of rollover, loss of control, other accidents, or sudden stop. Seat belts may reduce the severity of injury in these circumstances.
SAFETY LOADING THE VEHICLE The weight of cargo and passengers affects the handling and stability of the vehicle. For your own safety and the safety of others, think carefully about how to safely operate the vehicle when loaded with passengers and cargo. Follow the instructions in this manual for loading, tire pressure, gear change and speed.
SAFETY NO PASSENGERS IN THE CARGO BOX Passengers in the cargo box may fall over or get hit. Passengers in the cargo box may also cause the vehicle to overturn or collide, which may cause injury or more serious accidents. Never carry passengers in the cargo box.
SAFETY OPERATING AT EXCESSIVE SPEED Operating this vehicle at excessive speeds increases the operator’s risk of losing control. Always operate at a speed that’s appropriate for terrain, the visibility, operating conditions and your skills and experience. TURNING IMPROPERLY Turning improperly could cause loss of traction, loss of control, accidents or rollover.
SAFETY DESCENDING HILLS IMPROPERLY Improper descending a hill could cause loss of control or rollover. Always follow proper procedures for traveling down hills as described in this owner’s manual. CROSSING HILLSIDES Driving on a sidehill is not recommended. Improper operation could cause the loss of control or rollover.
NOTICE If equipped with T-BOX, before the first use, new vehicle can be activated only through the Segway Powersports application. If the T-Box is not activated, vehicle speed will be limited to 30 km/h. Download the Segway Powersports application from “Apple Store®”...
YOUR VEHICLE FIRST ACTIVATION There are three ways to activate your vehicle: Mechanical key (preferred) APP remote unlock vehicle Remote unlocking via the APP is based on the mobile data network. As long as the area is covered by the mobile data network, you can use remote unlock function in the APP to activate the vehicle.
YOUR VEHICLE SEGWAY POWERSPORTS APPLICATION “Segway Powersports” application is designed for users of Segway Powersports vehicles. Main Features: Driving control analysis, vehicle data analysis, etc. For further information see the APP User manual.
YOUR VEHICLE IGNITION SWITCH / START BUTTON VARIANT 1: Ignition Switch Turn the key to the "ON" position: the vehicle is activated and all electrical systems can be used. Turn the key to the “OFF” position: All electrical circuits are off and the engine stops.
Page 38
YOUR VEHICLE VARIANT 2: Turn the key to the "ON" position: the vehicle is activated and all electrical systems can be used. Turn the key to the "Start" position without loosening it. Start for 1.5 - 2 seconds to start the engine. After engine starts, release the key. After releasing, the key will automatically return to "ON"...
YOUR VEHICLE SWITCHES ! Engine On/Off Warning flashers Override Switch Engine OnOff Switch “ ”:Engine Stop “ ”:Engine Run/Start Starting the engine Step on the brake pedal and select "P" or "N" gear. Turn the ignition key into "ON" position. Press the Engine On/Off Switch to “...
Page 40
YOUR VEHICLE Stopping the engine Put the shift lever in the "P" position and apply parking brake. Press the Engine switch to “ ” position, and the engine will stop. Hazard switch Press the switch to " " position to activate hazard warning lights in ●...
YOUR VEHICLE COMBINED SWITCH Push the lever up to activate the right turn signals; the right turn indicator flashes on the display. Push the lever up to activate the left turn signals; the left turn indicator flashes on the display. Press to sound horn.
YOUR VEHICLE HEADLIGHTS SWITCH As shown in the picture, turn the end of the switch to activate the lights: “ ”:Front position lights, tail lights, license plate lights and dashboard controls are on. “ ”:Turn the switch to this position to select low beam. “...
YOUR VEHICLE 2WD / 4WD DRIVE SWITCH NOTICE The vehicle must be stopped to engage or disengage 2WD/4WD drive. Mechanical damage may occur if switch is engaged or disengaged while driving. 2 x 4 Mode When the switch is turned to " "...
Page 44
YOUR VEHICLE 4x4 Front differential lock mode When the switch is turned to " " position, the 4WD Lock symbol “ “ is displayed on the LCD screen. With locked front differential, power is supplied to the rear and front wheels, and the left and right front wheels have the same speed and power.
YOUR VEHICLE GEAR SHIFT LEVER The shift lever is located on the right side of steering wheel. After selecting the gear, check the symbol on the LCD screen ensuring that selected gear has been properly shifted. Low speed High speed Neutral Reverse Parking...
YOUR VEHICLE BRAKE AND ACCELERATOR PEDAL Brake pedal Accelerator pedal Brake pedal Press the brake pedal to select gear, reduce speed, or stop the vehicle. Use the brake pedal when you start the engine. To slow down or to stop, press the brake pedal with your right foot. The brake pedal is spring loaded and should return back to the rest position after releasing.
YOUR VEHICLE CAUTION If the accelerator pedal and the brake pedal are applied simultaneously at the same time, the engine power may be limited. PARKING BRAKE Whenever you are leaving the vehicle, be sure to set the parking brake. Parking brake handle Parking brake release button To set the parking brake: When parking, park the vehicle on a suitable place, step on the brake...
Page 48
YOUR VEHICLE To release the parking brake: Press the parking brake release button with your index finger, rotate the T-shaped handle 90 degrees clockwise, and push the parking brake handle fully in to its initial position. WARNING When leaving the vehicle, the parking brake must be on.
YOUR VEHICLE FEATURES LOCATION OF COMPONENTS Front bumper Instrument panel Passenger handrails ROPS cage Cargo Box Muffler Tailgate Cargo box release lever Fuel tank cap Cab Net/Side doors...
YOUR VEHICLE INSTRUMENT PANEL / LCD DISPLAY The instrument panel provides the operator with the vehicle information, and the driver should understand the meaning of the various indicators, warning lights and display content information on the instrument table, to understand the vehicle status. NOTICE Using high-pressure water cleaner may damage the instrument panel.
YOUR VEHICLE INDICATOR LIGHTS / WARNING LIGHTS The vehicle may be equipped with different instrument panels with slightly different displays, depending on vehicle model. When the ignition lock switch is turned to "ON", the instrument panel will be illuminated and all warning lights will illuminate briefly as self-check.
Page 52
C: Engine temperature is low H: Engine temperature is high Clock After connecting the vehicle to the "Segway Powersports" APP, the clock will automatically synchronize to the local time. Trip meter Shows mileage since last time the trip meter was reset.
Page 53
YOUR VEHICLE Battery Voltage Displays the actual voltage of the vehicle battery. Total Mileage Displays the total mileage ridden by the vehicle. 4x4 Switch & Differential Lock 2x4 mode 4x4 mode 4x4 front axle lock mode 2x4 mode 4x4 mode (with rear differential lock) (with rear differential lock) 4x4 lock mode...
Page 54
YOUR VEHICLE Light System Status Parking brake This light comes on when the parking brake is indicator applied. This light is on, when there is a problem in Engine Emission control system or in the Engine Failure electronic control system. This light goes on when the engine coolant temperature is too high.
YOUR VEHICLE DISPLAY SETTING Left button (MODE) Right button (SELECT) Function Left button Right button Display Adjust backlight brightness Display brightness Short press (default: brightest) adjustment Trip meter clear Long press Resets the trip meter EPS level. Selected mode EPS assistance Short press is displayed (M, H, L) setting...
YOUR VEHICLE 12V SOCKET / USB PORT This vehicle is equipped with two 12V power sockets, 12V power outlet and a USB port, located in the central panel. 12V Accessory outlet USB port 12V socket is used to supply 12V devices rated maximum 10A. Maximum output power: 120W These power sockets are on when the ignition lock is in "ON"...
YOUR VEHICLE DRIVER SEAT ADJUSTMENT The driver's seat can be adjusted forward and backward. Before starting the vehicle, the driver can adjust the seat according to his preferences. The seat should be adjusted so that the driver's back will comfortably fit with the seat back, and the driver's foot can reach the brake and accelerator pedals.
YOUR VEHICLE DRIVER'S SEAT REMOVAL /INSTALLATION Driver seat removal Seat lock lever Move the seat lock lever to the right. Gently pull the seat forward, and disconnect the OPC cable connector under the seat. Remove the seat from the vehicle. Driver seat installation Reconnect the OPC cable connector under the seat.
YOUR VEHICLE PASSENGER SEAT REMOVAL Passenger seat removal Lift forcefully the front of the passenger's seat upwards, and then remove the M8 nuts on the left and right sides behind the passenger seat. Remove the seat. STEERING WHEEL ADJUSTMENT The steering wheel can be tilted up or down to meet the driver's preferences.
Page 60
YOUR VEHICLE Steering wheel adjustment: Raise the steering column adjustment lever toward the steering wheel, but do not release it. Use the other hand to move the steering wheel up or down to the preferred position, hold the steering wheel in this position, and release the adjustment lever.
Pull out each seat belt and check for any damage, including cutting, grinding, damage, wear or stiffness. If any damage is found, contact Segway Powersports dealer for replacement. Clean the dirt or debris from the seat belt, wipe the belt with mild...
Replace any worn or damaged parts immediately. New parts can be obtained from your authorized Segway Powersports dealer. Safety Nets Before each use, be sure to check the wear and damage of the side doors, door latches, safety nets, and locking buckles.
YOUR VEHICLE STORAGE BOX Front storage box The tool kit is stored in this box. Central storage box / or central LCD screen (according to your model). WARNING Keep the storage box closed during the ride. You can be possibly hurt by the objects in the storage box, or if you open it when emergency braking or turning, resulting in accident.
Page 64
YOUR VEHICLE TILTING THE CARGO BOX The cargo box is tiltable. Engine, spark plugs and air filter are located under the cargo box. The cargo box release levers are on both sides of the vehicle. Lift any release lever up (turn it upwards) to dump the cargo box. The cargo box will slowly tilt backwards and will stop automatically when it reaches the limit.
Page 65
YOUR VEHICLE FRONT MAINTENANCE COVER Hold the front maintenance cover with both hands and pull it up forcefully to open it. The fuse box and coolant filling cap are located under the front maintenance cover. CARGO BOX TAILGATE To open: Move the handle in the tailgate panel upwards and open the tailgate.
(EU) No 1322/2014 Annex VIII. If there is any damage to the vehicle's rollover protection cage, contact your Segway Powersports dealer. The dealer thoroughly inspects the ROPS or replaces it. No device can assure occupant protection in the event of a rollover.
OPERATIO OPERATION BASIC DRIVING GUIDE ..............62 TRAIL ETIQUETTE ..............62 KNOW YOUR RIDING AREA ............63 VEHICLE BREAK-IN PERIOD ..........63 BRAKE SYSTEM BREAK-IN PERIOD ........63 DRIVE BELT BREAK-IN PERIOD ........... 63 NEW OPERATOR DRIVING PROCEDURES ......64 DRIVING WITH PASSENGERS ..........
OPERATION This section provides basic operating instructions, including how to start and stop the vehicle, driving skills and precautions when driving on different roadways. Even if you've ridden other on-road vehicles, you must take time to familiarize yourself with how the vehicle operates. Practice in flat and wide areas until you are familiar with this all-terrain vehicle.
OPERATION KNOW YOUR RIDING AREA Familiarize yourself with all laws and regulations concerning the operation of this vehicle in your area. Respect the environment in which you ride your vehicle. Find out where the designated riding areas are by contacting your dealer, a local riding club, or local officials.
OPERATION NEW OPERATOR DRIVING PROCEDURES Before operating this vehicle, read and understand the owner's manual and all warning and instruction labels. Perform a pre-ride check. Do not carry goods during this period. Do not carry passengers until you have two hours experience with driving this vehicle.
OPERATION • Avoid sharp turns • Don’t turn when stepping on the accelerator pedal. • Don’t swerve when driving the vehicle. • Drive according to your skills, conditions and terrain. • Do not jump with the vehicle or perform any driving stunts. DRIVING WITH PASSENGERS Finish the New operator driving procedures on page 64.
OPERATION STARTING THE VEHICLE Step on the brake pedal and do not release it. Turn ignition switch ON. Press the “Start" button for 1.5 - 2 seconds (no more than 4 seconds). The engine will start. Before starting the engine, be sure your wear the helmet and other safety equipment, ensure the side doors / safety nets are closed and that driver and passenger(s) have fastened seat belts.
OPERATION PARKING THE VEHICLE Stop the vehicle on a level surface. When parking inside a garage or other structure, be sure that the structure is well ventilated and that the vehicle is not close to any source of flame or sparks, including any appliance with pilot lights.
If the vehicle tips over or overturns in water, or if the engine stops during or after operating in water, service is required before starting the engine. Your Segway Powersports dealer can provide this service. If it's impossible to bring the vehicle in before starting the engine, perform the service outlined in the “Drying the CVT”...
OPERATION DRIVING IN REVERSE Follow these precautions when operating in reverse: Always check for obstacles or people behind the vehicle. Apply the throttle lightly. Never open the throttle suddenly. Ride slowly. Apply the brakes lightly for stopping. Avoid sharp turns. DRIVING OVER OBSTACLES Follow these precautions when operating over obstacles: Before operating in a new area, check for obstacles.
OPERATION DRIVING UPHILL Braking and handling are greatly affected when operating in hilly terrain. Improper procedure could cause loss of control or rollover. Whenever traveling uphill, follow these precautions: Always move the 4x4 switch (if equipped) to 4x4WD position before ascending or descending a hill. Always travel straight uphill.
OPERATION DRIVING ON A SIDEHILL (SIDEHILLING) Driving on a sidehill is not recommended. Improper procedure could cause loss of control or overturn. Avoid crossing the side of any hill unless absolutely necessary. If crossing a sidehill is unavoidable, follow these precautions: Slow down.
OPERATION ENGINE BREAK-IN GUIDELINES Engine break-in period is the 300 km of operation. During break-in: • Avoid full throttle operation. • Avoid pressing the accelerator pedal past ¾ down. • Avoid continuous acceleration. The brakes need a 200 km break-in period. New brakes will not reach their maximum efficiency until they are fully broken-in.
OPERATION PRE-RIDE INSPECTION Perform a pre-ride inspection before each ride to detect any potential problem that could occur during operation. The pre-ride inspection will help you monitor component wear and deterioration before they become a problem. Correct any problems that you discover to reduce the risk of a breakdown or accident.
OPERATION HAULING CARGO Your vehicle has been designed to carry or tow specific capacity. Reduce speed and allow a greater distance for braking when carrying cargo. Loads should be centered and carried as low as possible in the cargo box. For stability on rough or hilly terrain, reduce both speed and cargo weight.
Page 82
OPERATION WARNING SECURE LOAD BEFORE RIDE. Unsecured load can create unstable operating conditions, which could result in loss of control of the vehicle. OPERATE ONLY WITH STABLE AND SAFELYARRANGED LOADS. When handling off-centered loads that cannot be centered, securely fasten the load and operate with extra caution. HEAVY LOADS CAN CAUSE BRAKING AND CONTROL PROBLEMS.
OPERATION Always read and understand the load distribution warnings on warning labels on your vehicle and in this manual. Never exceed the maximum capacities specified for your vehicle. DRIVE BELT LIFE To extend belt life, use low gear when hauling or towing heavy cargo. TOWING LOADS WARNING Towing improperly can alter vehicle handling and may cause loss of...
OPERATION MAXIMUM LOADING CAPACITY Don’t over the maximum loading capacity: SGW570F- U3 Maximum weight capacity 497 kg capacity includes weight of operator, passengers, cargo, accessories and tongue weight) Maximum cargo box load 272 kg Maximum unbraked towing weight 550 kg Maximum unbraked tongue weight 100 kg Maximum towing weight WITH inertia braked trailer...
OPERATION Release the tailgate latch and lower the tailgate. Stand clear and pull up on the cargo box release lever. Lift the front of the cargo box to dump the cargo. Lower the cargo box and push down securely to latch. Close the tailgate and secure both tailgate latches.
OPERATION TRAILER When towing a load, bear in mind that the towing weight does not include the towing device (towbar). The total load (weight on the operator, passenger(s), accessories, cargo and trailer) shall not exceed the maximum capacity of the vehicle.
OPERATION WINCH OPERATION GUIDE If your vehicle is equipped with a winch, please read this manual before winch use to understand and familiar yourself with important safety precautions and operating instructions. WARNING The user must read and understand the operating instructions and warnings of this owner's manual.
Page 88
OPERATION • Avoid pulling from extreme angles, as this will cause the rope to be rolled to one end of the drum and may damage the rope or winch. • Note that maximum winch pulling capacity is the capacity on the first layer of the rope on the drum.
Page 89
OPERATION • Never disconnect the winch power supply when there is a load on the winch. • After the operation, release the load immediately. • Always stay away from rope, hook and winch when winching or under load. • Check winch, rope, hook and broken strands of worn rope regularly.
Page 90
OPERATION WARNING When releasing or retrieving the winch rope, both ends of the rope must be left with sufficient length to prevent the rope from being over-rolled in or out. When the rope is retrieving, please maintain a certain tension so that the rope can be retracted smoothly and can be wound tightly during retrieving.
OPERATION WINCH OPERATION Manual release of the rope Manual rope release switch When you turn the manual release knob clockwise, the rope can be pulled out manually. When you turn the manual release knob counterclockwise, the winch release will be controlled by Control switch. Operation of Control switch OUT: Release the rope IN: Rewind the rope...
Page 92
OPERATION Remove the control switch from the passenger armrest storage and connect the control switch to the winch receptacle located on the left side of the driver. 1. Open the waterproof cover. 2. Insert the Control switch connector into the receptacle. Remote control operation Release the rope Recoil the rope...
Inspect, clean, lubricate, adjust and replace parts as necessary. When in the need for replacement parts, use genuine Segway Powersports parts available from your authorized Segway Powersports dealer. Service and adjustments are important for proper vehicle operation. If you're not familiar with the service and adjustment procedures, have a qualified Segway Powersports dealer perform these jobs.
Page 96
Improperly performing the procedures marked with a D could result in component failure and lead to serious injury or death. Have an authorized Segway Powersports dealer or other qualified person perform these services. Perform all services at whichever maintenance interval is reached...
Page 97
MAINTENANCE AND STORAGE PRE-RIDE MAINTENANCE MAINTENANCE ITEM REMARKS INTERVAL Steering Pre-Ride Front suspension Pre-Ride Rear suspension Pre-Ride Visually inspect, test, or check Tires/ wheels/ Pre-Ride components. fasteners Adjust and repair when required. Brake fluid level Pre-Ride Brake system Pre-Ride Accelerator pedal Pre-Ride Engine oil level Pre-Ride...
Page 98
MAINTENANCE AND STORAGE MAINTENANCE AFTER BREAK-IN MAINTENANCE INTERVAL ITEM REMARKS Break-in check: cycle key to pressurize Fuel system fuel pump; check lines and fittings for leaks and abrasion Break-in oil check, oil filter change Engine oil change Front gearcase oil Break-in oil level check Rear gearcase oil Break-in oil level check...
Page 99
MAINTENANCE AND STORAGE PERIODIC MAINTENANCE MAINTENANCE INTERVAL WHICHEVER COMES FIRST) ITEM REMARKS HOURS CALENDAR Inspect for leaks and loose ► Oil lines and 100 H 12 M 1600 fasteners fittings ► Front gearcase oil 100 H 12 M 1600 Change oil; ►...
MAINTENANCE AND STORAGE LIFTING AND SUPPORTING THE VEHICLE Place the vehicle on a flat non-slippery ground. Engage the 4WD mode. Ensure vehicle shift lever is in PARK (“P”) position. When lifting the front or rear of the vehicle, place the jack in the left and right center of the front or rear of the vehicle, as shown in the figure below:...
MAINTENANCE AND STORAGE LUBRICATING OIL Check and lubricate all components at the intervals listed in the periodic maintenance chart. Items not listed in the chart should be lubricated in the general lubrication interval. The rocker arm is lubricated at the factory and does not require additional lubrication. However, if these components are heavily used, the user may perform additional lubrication as required.
If the oil level begins to rise, change the oil immediately. Monitor the oil level, if it continues to rise, stop using your vehicle and determine the cause. Contact your Segway Powersports dealer for service. WARNING...
MAINTENANCE AND STORAGE OIL LEVEL INSPECTION NOTICE Running the engine with an improper oil level can cause serious engine damage. The oil dipstick is located on the right side of the engine, below the air filter. Park the vehicle on a level surface and stop the engine. Oil dipstick Upper mark Lower mark...
MAINTENANCE AND STORAGE CHANGING ENGINE OIL AND OIL FILTER Have the engine oil replaced by an authorized Segway Powersports dealer. As a part of oil exchange, the service will also change and clean your two-stage oil filter. NOTICE Change the oil filter every time the oil is changed.
MAINTENANCE AND STORAGE ADDING ENGINE OIL The engine oil filling port is located under the cargo box. Flip the cargo box: Open the oil filler cap by turning it counterclockwise. Add an appropriate amount of recommended engine oil. Do not overfill.
Check and replace the front and rear transmission oil at the intervals specified in the Periodic Maintenance Table. If any leaks are found, contact a Segway Powersports dealer to inspect and repair the vehicle. If the four-wheel drive mode is used extremely often, or is in severe use, the front differential oil should be replaced every 25 engine hours.
Page 107
MAINTENANCE AND STORAGE ADDING FRONT/REAR DIFFERENTIAL/FINAL GEAR OIL Front Axle Oil filler plug O-ring Drain plug If there is too low oil in front / rear differential, check for leaks and add gear oil: Position the vehicle on a level surface. Remove the oil filler plug.
MAINTENANCE AND STORAGE CVT DRIVE BELT Check and replace the CVT drive belt in intervals specified in the vehicle maintenance schedule. If the CVT belt is damaged, it should be replaced immediately. When replacing the drive belt, clean the CVT clutch and the engine compartment, as well as CVT intake and outlet ducts for debris.
MAINTENANCE AND STORAGE Remove the CVT cover bolts, CVT cover and cover sealing ring. Insert the pulley spreader rod into the hole in the driven clutch as shown in the picture, and screw the tool clockwise to open the sheaves of the driven clutch. Take out the drive belt to be replaced and clean up all debris in the CVT compartment and intake and outlet ducts.
CVT system. DO NOT APPLY FULL THROTTLE DURING THIS OPERATION. Shift the Low range and test ride slowly for belt slippage. If the belt still slips, repeat the process. Visit your Segway Powersports dealer if your vehicle needs service. CVT clutch drain plug...
MAINTENANCE AND STORAGE SPARK PLUG Refer to the specifications below for the recommended spark plug type and gap. CAUTION Using unrecommended spark plug can cause serious engine damage. Always use only the recommended spark plug. Spark Plug NGK CPR7EA Type Spark Plug Gap 0.6-0.8 mm Spark Plug Torque...
Page 112
MAINTENANCE AND STORAGE Bolt Ignition coil Spark plug Spark plug wrench The spark plug is located under the cargo box. Remove the ignition coil fixing bolt. Take out the ignition coil, the spark plug is located below the ignition coil. Using the spark plug wrench, provided in the tool kit, remove the plug by rotating it counterclockwise.
MAINTENANCE AND STORAGE COOLANT The coolant circulates in the engine cooling system, taking away the excess heat generated during the engine operation and making the engine operate at normal operating temperature. Maintaining the coolant allows the cooling system to work properly and prevents freezing, overheating, and corrosion.
MAINTENANCE AND STORAGE COOLANT RECOVERY BOTTLE The recovery bottle is located under the front service cover. Check the coolant level in the recovery bottle from the left side of the vehicle. If the coolant level is low, add the appropriate amount of coolant. Coolant should be between the MIN and MAX marks on the recovery bottle (when the coolant is cool).
MAINTENANCE AND STORAGE RADIATOR COOLANT To ensure that the coolant maintains its ability to protect the engine, Segway Powersports recommends to completely drain the coolant and replace with new recommended antifreeze every five (5) years. CAUTION Hot steam can cause severe burns. Do not open the radiator pressure cap when the engine is hot.
Check the surface and condition of the brake discs. Use the brake cleaner to clean up any grease and adhering dirt. Do not use spray lubricants or other petroleum-based products. If any damage (crack, excessive corrosion, warping) is found, visit Segway Powersports dealer before further operation.
MAINTENANCE AND STORAGE BRAKE FLUID Use the recommended brake fluid: Brake Fluid Maxima DOT 4 Brake Fluid Hydraulic brake system of your vehicle requires no adjustment. Check the brake fluid level frequently. If the level is low, add brake fluid. Brake fluid reservoir is located under the front service cover.
Page 119
MAINTENANCE AND STORAGE NOTICE Brake fluid can damage plastic and painted surfaces and should be added with caution. If the brake fluid comes into contact with the skin or eyes, flush with plenty of water immediately. If you feel sick, seek medical attention immediately.
MAINTENANCE AND STORAGE TIRES TIRE PRESSURE Driving a vehicle with the incorrect tire pressure may result in: • Reduced fuel efficiency. • Reduced driving comfort and shortened tire life. • Reduced ride safety. When checking tire pressure, use following table: Tire size Tire pressure 27×9.00-14...
• If the tire has air leak which cannot be normally repaired due to the size or position of puncture, or has other damage. If you are not sure, consult your Segway Powersports dealer.
MAINTENANCE AND STORAGE WHEEL REMOVAL Stop the engine. Put the transmission in "P" position. Lock the parking brake. Loosen the wheel nuts slightly, but do not remove them yet. Lift the side of the vehicle by placing a suitable jack or stand under the frame.
Do not use wheels of other sizes than recommended in this manual or in vehicle documents, as this can cause the vehicle to lose control. Tire size Front wheel Rear wheel 27×9.00-14 27×11.00-14 Segway UT6 27×9.00 R14 27×11.00 R14 30×10.00 R14 30×10.00 R14...
MAINTENANCE AND STORAGE SUSPENSION ADJUSTMENT There are 5 spring preload adjustment positions, which can be used according to different terrain and loading conditions. If you feel the suspension is too soft and too stiff, you can adjust the springs according this table. Position Spring Suspension Load Terrain...
MAINTENANCE AND STORAGE SUSPENSION LUBRICATION Front and rear suspension, transmission shafts, and balance shaft are equipped with grease fittings. These parts need to be thoroughly lubricated. Use suitable grease and lubricate them in intervals specified in periodic maintenance chart. Sufficient lubrication can reduce wear and increase service life of these components.
Page 126
MAINTENANCE AND STORAGE FRONT/REAR AXLE BOOTS Check for cuts, damage or grease leakage from the front and rear drive axle dust boots. If you find any damage or grease leakage, contact your Segway Powersports dealer for service.
MAINTENANCE AND STORAGE AIR FILTER The air filter element in this vehicle is of a paper type. The air filter element should be cleaned and replaced in intervals specified Periodic maintenance chart. REPLACING AIR FILTER ELEMENT Air filter is located under the cargo box. Air filter drain plug Air filter element The air filter is located on the right side, under the cargo box.
MAINTENANCE AND STORAGE WARNING When assembling the air filter element, make sure that the buckles of the filter element and the cover are in place; otherwise it will cause the engine to malfunction or reduce service life. When the vehicle is operated in a dusty environment, please shorten the time interval for checking the filter element.
MAINTENANCE AND STORAGE LIGHTS CAUTION Poor lighting can result in reduced visibility when driving. Clean the headlights frequently and replace non-functioning lights promptly. To ensure optimum visibility and safety, make sure the headlights are properly adjusted. REPLACING THE HEADLIGHT BULB If the bulb is damaged, replace it with a bulb of the same type.
MAINTENANCE AND STORAGE To replace the headlamp bulb: Unscrew the headlamp cover expansion screw and remove the headlamp cover. Remove the wire harness connector and take out the broken bulb. Install the new bulb and turn the headlights on to test whether headlight is working properly.
CAUTION Following pictures are for reference only. Your model may be different. It is best to let Segway Powersports dealer to adjust the headlights, if conditions permit. Place the vehicle on a level surface, with the headlights approximately 10 m from a wall.
Page 132
MAINTENANCE AND STORAGE 3. Apply the brakes, start the engine and turn the headlights on. 4. Observe the headlight beam on the wall. The most intense part of the headlight beam should be aimed 24 cm below the mark marked on the wall.
MAINTENANCE AND STORAGE SPARK ARRESTOR Spark arrestor prevents random sparks from entering other parts of the vehicle. Regular maintenance can prevent carbon accumulation, lack of maintenance will reduce engine performance. WARNING Make sure the exhaust pipes are cool. Ensure that there are no combustible materials in the area when maintaining the vehicle.
Reinstall the spark arrestor, all washers and bolts. NOTICE If damaged, replacement exhaust gasket should be readily available from Segway Powersports parts and service dept. ELECTRIC POWER STEERING (EPS) The power steering is active when the engine is running. NOTICE When the key is turned to the "ON"...
MAINTENANCE AND STORAGE BATTERY This vehicle is equipped with a sealed MF battery, which requires little maintenance. It is not required to check the electrolyte or to add distilled water to the battery. Due to natural discharge and power consumption of some electrical equipment, battery will discharge gradually even when the vehicle is not in use.
MAINTENANCE AND STORAGE BATTERY REMOVAL To remove the battery first remove the seat and perform the following procedure. Turn the vehicle power Off before removing battery. NOTICE If the electrolyte spills, immediately wash it off with a dedicated a contact cleaner to prevent damage to the vehicle. The battery is located under the passenger seat in standard cab vehicles, and in the middle of the rear seat in Crew cab vehicles.
MAINTENANCE AND STORAGE Power off the vehicle. Lift the battery positive and negative terminal protection rubber covers. Remove the battery negative bolt and disconnect the black (negative) battery cable. Remove the battery positive bolt and disconnect the red (positive) battery cable. Remove the battery strap.
MAINTENANCE AND STORAGE BATTERY CHARGING NOTICE When charging, the hydrogen, combustible and explosive gas, is produced by the 12V battery. Therefore, follow these precautions : If charging the 12V battery that is installed in the vehicle, be sure to disconnect the negative (grounding) cable from the battery. Make sure the battery charger is off when connecting and disconnecting the charger to the battery.
Page 139
MAINTENANCE AND STORAGE Jump-starting the vehicle 1. Connect positive clamp of the jumper cable to the positive (+) terminal of the flat battery in your vehicle. 2. Connect the other clamp of the positive jumper cable to the positive (+) terminal in another vehicle. 3.
MAINTENANCE AND STORAGE FUSE All circuits in this vehicle are protected with fuses to protect electrical equipment from damage caused by high current, short circuit or overload. If any of the electrical systems do not work, the fuse may be blown. If this happens, check the fuse first.
MAINTENANCE AND STORAGE FUSE BOX The fuse box is located at the front of the vehicle under the front service panel. To remove the front service panel, see page 58. After the front service panel has been removed, the fuse box is located at the bottom.
MAINTENANCE AND STORAGE FUSE / RELAY RATINGS AND LOCATION On the top of the fuse box cover, there is a label with location of the fuses/relays. Refer to this scheme when searching a fuse to be replaced. REMOTE AUXILIA L R P R R P POWER- EPS-IG...
Page 143
MAINTENANCE AND STORAGE Fuse/Relay Power Ignition lock constant power fuse Headlamp fuse Instrument cluster/OBD/ECU/Central Display/TBOX Fuel pump fuse 12V Outlet/Trailer Power Supply Lamp/Brake/2-4WD switch fuse ECU fuse Ignition lock-instrument cluster/Central display/ TBOX/Vehicle speed Ignition lock-EPS fuse L R P Light R R P Light Main fuse ECU Non-Constant Fuse...
MAINTENANCE AND STORAGE FUSE REPLACEMENT To prevent an accidental short circuit, turn the ignition switch to (OFF) before checking / replacing the fuse. To check or replace the fuse, pull out the blown fuse with a fuse puller in the box cover. This tool will help you take out the fuse. Fuse box cover is fitted with a spare fuse which can be replaced.
MAINTENANCE AND STORAGE APPEARANCE AND CARE VEHICLE WASHING Note: High pressure water can damage parts, and remove paint and decals. 1. Cover or plug the exhaust before washing your vehicle. 2. Fill a bucket with water. Mix in a mild, neutral detergent, such as dish washing liquid or a product made especially for washing motorcycles or automobiles.
MAINTENANCE AND STORAGE VEHICLE STORAGE If the vehicle will not be used for a longer time, it should be appropriately stored. The vehicle should be serviced and thoroughly cleaned prior storing. If you do not have indoor storage, covered outdoor storage is recommended.
SPECIFICATIONS SPECIFICATIONS TECHNICAL PARAMETERS OF THE VEHICLE ......142 VEHICLE IDENTIFICATION NUMBER ........146 IDENTIFICATION PLATE ...........147...
Page 149
SPECIFICATIONS TECHNICAL PARAMETERS OF THE VEHICLE ITEM SPECIFICATIONS Segway UT6 Length x width x height 3050 x 1600 x 1950 mm Wheelbase 2110 mm Front axle track width 1350 mm Rear axle track width 1320 mm Curb weight 772 kg...
Page 150
SPECIFICATIONS ITEM SPECIFICATIONS ENGINE Engine type Four stroke, one-cylinder, DOHC Engine model 199MS-1 Displacement 567 cm Compression ratio 10.7 ± 0.5:1 Bore × Stroke 99 x 73.6 mm Rated Power (kW) 30 kW @ 7000 r/min Rated Torque 50 Nm @ 4500 r/min Idle speed 1350±100 r/min Starting system...
Page 151
SPECIFICATIONS ITEM SPECIFICATIONS TIRES / WHEELS Front 27×9.00-14 27×9.00R14 30×10.00R14 Tires Rear 27×11.00-14 27×11.00R14 30×10.00R14 70 KPa Front Tire pressure 110 KPa Rear 14×6.5 AT Aluminum rim, or Front 14×6.0 AT Steel rim Wheels 14×7.0 AT Aluminum rim, or Rear 14×7.5 AT Steel rim BRAKES Type...
Page 152
SPECIFICATIONS ELECTRIC SYSTEM ITEM SPECIFICATIONS 55W×2(H4) Headlight LED 0.5W Fr. Position light Headlights LED 4.2W Daytime Running Lights LED 4.8W Front turn signal light 21W (P21/5W) Rear brake light Rear position light Red 5W(P21/5W) Tail light Rear turn signal light Amber 10W(RY10W)...
SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER Record the vehicle identification number and engine serial number in the spaces provided for assistance when ordering spare parts from a dealer, or for reference in case the vehicle is stolen. XXX XXX XXX XXXXXXX XXX XXX XXX XXXXXXX Vehicle identification number Engine serial number ENGINE SERIAL NUMBER...
SPECIFICATIONS IDENTIFICATION PLATE Identification plate contains basic vehicle information including VIN number. VIN number is required when the vehicle is activated for the first time.
TROUBLESHOOTING With all the challenges you can encounter off-road, there's chance that sometimes something may go wrong. This section gives you practical advice to help you deal with a wide range of problems. Take time to read this section before you ride. DRIVE BELT WEAR / BURN Possible Cause Solution...
TROUBLESHOOTING Possible Cause Solution Shift to the Low range (“L”), and use fast, aggressive throttle to engage Stuck in mud or snow clutch. WARNING: Excessive throttle may cause loss of control and vehicle overturn Shift to the Low range (“L”), and use fast, aggressive throttle to engage Climbing over large clutch.
Possible Cause Solution Poor quality or low Replace with recommended fuel octane fuel Incorrect ignition Visit Segway Powersports dealer timing Incorrect spark plug Set gap to specifications or replace spark plug gap or heat range ENGINE STOPS OR LOSES POWER...
Fouled or defective spark Inspect plug, replace if necessary plug No spark from spark plug Inspect plug, verify the Stop switch is on Visit Segway Powersports dealer Crankcase filled with immediately water or fuel Clogged fuel injector Clean or replace the fuel injector...
Possible Cause Solution Fouled or defective spark Inspect, clean and/or replace spark plug plug Worn or defective spark Visit Segway Powersports dealer plug wires Incorrect spark plug gap Set gap to specs or replace plugs or heat range Loose ignition connections...
Replace with new fuel Fouled or defective spark Inspect, clean and/or replace spark plug plug Worn or defective spark Visit Segway Powersports dealer plug cables Incorrect spark plug gap Set gap to specifications or replace plug or heat range Loose ignition connections...
VEHICLE DEVICE DIAGNOSTIC / TROUBLE CODES System Code Failure Description P000262 Cylinder 1 Injector Circuit High P000261 Cylinder 1 Injector Circuit Low P000201 Injector Circuit/Open – Cylinder 1 P000629 Fuel Pump “A” Control Circuit High P000628 Fuel Pump “A” Control Circuit Low P000627 Fuel Pump “A”...
Page 163
VEHICLE DEVICE System Code Failure Description P000031 O2 Sensor Heater Control Circuit Low Bank 1 Sensor 1 P000030 O2 Sensor Heater Control Circuit Bank 1 Sensor 1 P000132 O2 Sensor Circuit High Voltage Bank 1 Sensor 1 P000131 O2 Sensor Circuit Low Voltage Bank 1 Sensor 1 P013000 O2 Sensor Circuit No Activity Detected Bank 1 Sensor 1 P000134...
Page 164
VEHICLE DEVICE System Code Failure Description E0015 The rotor Angle sensor is disconnected E0016 Power module failure E0017 Abnormal A phase electric current E0018 Abnormal C phase electric current E0019 Steering wheel Angle small gear abnormal E0020 Steering wheel Angle middle gear abnormal E0021 Steering wheel Angle jumps E0022...
EMISSION CONTROL SYSTEM EMISSION CONTROL SYSTEM SOURCE OF EXHAUST EMISSIONS ........159 EXHAUST EMISSION CONTROL SYSTEM ........ 159 CRANKCASE EMISSION CONTROL SYSTEM ......159 NOISE CONTROL SYSTEM ..........159...
EMISSION CONTROL SYSTEM SOURCE OF EXHAUST EMISSIONS The combustion process produces carbon monoxide (CO), oxides of nitrogen (NOx) and hydrocarbons (HC). Control of hydrocarbons and oxides of nitrogen is very important, because, under certain conditions, they react to form photochemical smog when subjected to sunlight.
Need help?
Do you have a question about the SGW570F-U3 2025 and is the answer not in the manual?
Questions and answers
