- Page 1 Nexus 4 Pro S USER MANUAL truly driven. vantrue.com...
- Page 3 Contents 1. Quick Start Guide 1.1 What’s in the Box? 1.2 Installation Guide 2. Basic Operation 2.1 Camera Overview 2.2 Button Description 2.3 LED Indicator 2.4 Screen Overview 2.5 Operation Guide 2.6 Menu Introduction 3. Specifications & FAQs 3.1 Specifications 3.2 Safety Warnings 3.3 FAQs 4.
- Page 4 · Please do not disassemble or repair the dash cam without authorization. If the camera malfunctions, please contact VANTRUE official customer service. · Please avoid installing the dash cam in a position that will block the driver's view.
- Page 5 1. Quick Start Guide 1.1 What’s in the Box? A. N4 Pro S Front B. Rear Camera C. GPS Adhesive Camera Mount E. Rear Camera F. Type C Data D. Car Charger Cable (20ft） Cable (3.3ft, for with Built-in Type C Cable transferring (11.5ft) files only)
- Page 6 1.2 Installation Guide Here are some warm tips about installing the N4 Pro S dash cam: · Please use a cleaning tool to clean the mounting position of the front camera and the rear mirror camera on the windshield first. After cleaning it, then install the camera;...
- Page 7 Installation Diagram ① Attach the bracket to ② Insert a memory the front camera card ③ Installation of electrostatic ④ Installation of the sticker to windshield N4 Pro S dash cam ⑤ Installing the Car charger adapter and Wiring - 3 -...
- Page 8 ⑥ Installing the rear camera and wiring Please note that the bracket is a split bracket . If you need to remove the bracket , simply push the bracket away from the bracket base to complete the removal. - 4 -...
- Page 9 2. Basic Operation 2.1 Camera Overview VTE22L1577 - 5 -...
- Page 10 N4 Pro S Front Camera 3.19" IPS screen Cabin Camera Infrared Lights for Cabin Camera TYPE-C Port for Charging (Cannot be used for Rear Camera connection and data transfer) TYPE-C Port for Connecting Rear Camera Cable or Transferring Data Serial Number Memory Card Slot Rear Camera 2.2 Button Description...
- Page 11 • In the recording screen: Short press to start/pause recording, long press to turn off the screen; • In the menu settings: short press to confirm the option; • In the playback video: short press to play the video or pause the video. •...
- Page 12 2.3 LED Indicator LED Status Description Steady green light In standby Blinking green light Camera is recording 2.4 Screen Overview Voice Assistant ON 2.4G WiFi ON Voice Assistant OFF 5G WiFi ON IR LED AUTO ON/OFF 2.4G WiFi is connected IR LED ON 5G WiFi is connected IR LED OFF Collision Detection...
- Page 13 Please scan the QR code for the relevant version below to download the app and install it. Search for the "Vantrue" app in App Store or Google Play Store to find the app and then download and install it on your phone.
- Page 14 - 10 -...
- Page 15 Please scan the QR code for the relevant version below to download the app and install it. Search for the "Vantrue" app in App Store or Google Play Store to find the app and then download and install it on your phone.
- Page 16 Camera Setting Mileage Statistics Camera Correction Full Screen Line Microphone ON/OFF Start/Start Recording Camera lcon Displays Switch Album Snapshot After entering the APP real-time preview, you can do the following operations. · Video Preview: After the APP connects to the camera successfully, the camera enters the real-time preview page, click the full screen button or cell phone horizontal playback, the real-time screen automatically...
- Page 17 --APP Upgrade Open "Vantrue" App, connect the camera’s Wi-Fi, go to "Settings>About", click "Detect new version", then the App will automatically detect whether the App version is the latest version.
- Page 18 A. Resolution and PlatePix™ Timer The picture quality mode is standard by default. Users can turn on the PlatePix™ mode on demand and set the automatic on and off time of this mode with the PlatePix™ timer. This function prioritizes the enhancement of license plate clarity, avoiding the blurring of license plates due to lighting problems, which may affect the evidence of accidents.
- Page 19 2160P+1080P+1440P 30FPS 00:00:37 05-05-2025 14:25:35 MP/H Note: · The normal operation of the loop recording function is very dependent on the speed of the memory card, so please format the memory card regularly to avoid problems such as excessive memory card files and card aging that affect the normal loop recording.
- Page 20 be automatically saved in the Event Video Folder and the photo will be saved in the photo folder. 2160P+1080P+1440P 30FPS 00:00:37 05-05-2025 14:25:35 MP/H 2160P+1080P+1440P 30FPS 00:00:37 05-05-2025 14:25:35 MP/H Note: · The sensitivity of the automatic locking video trigger is determined by the sensitivity of the collision.
- Page 21 ① To ensure that the dash camera can use the parking mode function normally, please use the VANTRUE hardwire kit cable or other stable and continuous power supply for the camera. ② It is recommended to use VANTRUE ACC hardwire kit cable.
- Page 22 The parking mode function will be improved with the firmware upgrade of the N4 Pro S dash camera. Please pay attention to the firmware description announcement on VANTRUE website for specific changes, or consult with customer service staff. Parking Mode Introduction...
- Page 23 2160P+1080P+1440P 30FPS 00:00:37 05-05-2025 14:25:35 MP/H When the G-sensor detects that the vehicle has been stationary for 5 minutes (entering collision detection mode), the camera will display the appropriate icon in the center of the screen and automatically shut down. After shutting down, if the vehicle vibrates or moves, the camera will automatically turn on and record a 1-minute video, and then turn off again to ensure that...
- Page 24 Parking Mode 2: Motion Detection When the Motion Detection setting is on, the Motion Detection icon will be displayed in the recording interface, indicating that the camera is currently using the Motion Detection mode. The process of triggering recording: N4 Pro S Dash Cam supports pre-recording function, which can better restore the whole process of the event.
- Page 25 Motion Detection Area Front Area Detection Rear Area Detection Parking Mode 3: Low Bitrate Recording When low bitrate recording is turned on, the screen displays the low bitrate icon and records according to the set resolution (1080P 15FPS or 720P 15FPS). 2160P+1080P+1440P 30FPS 00:00:37 05-05-2025...
- Page 26 2160P+1080P+1440P 30FPS 00:00:37 05-05-2025 14:25:35 MP/H How to enter the low framerate recording mode: After parking the car and turning off the engine, it will automatically enter the low frame rate mode, which can effectively retain the video integrity and save storage space.
- Page 27 In the APP real-time preview interface, you can select the start time and end time, click OK, then you can download the mileage statistics file in PDF or JPG format and save it in the APP local folder. - 23 -...
- Page 28 GPS Function GPS is enabled by default. The N4 Pro S dash camera receives GPS signals via a GPS mount. It automatically corrects the time and date in your area, records the location where the video was taken and the speed of the vehicle at the time.
- Page 29 ② GPS information is recorded along with the video. To view it, please download and install the VANTRUE App and VANTRUE GPS Player (available for download at www.vantrue.net). LTE Setup (need to use with LTE module, sold separately) For users to remotely view their vehicle's parking situation, Vantrue introduces the LTE module.
- Page 30 Wi-Fi of the camera, and turn on the automatic time correction function in Vantrue APP, so the camera will correct the time zone of the camera according to the time zone of your phone.
- Page 31 Automatic switching between Winter Time and Summer Saving Time is available for North America only. For users to watch clearer videos, Vantrue provides an exclusive PC player: -Mac users can search for “Vantrue Player” in Apple APP Store and download it.
- Page 32 N4 Pro S Dash Cam Firmware Update Upgrade method 1: Updates via files Go to VANTRUE website to download the latest N4 Pro S dashcam firmware, copy the firmware file to the root directory of the memory card, then insert the memory...
- Page 33 - 29 -...
- Page 34 · To upgrade firmware via file or OTA upgrade, N4 Pro S camera needs to keep power on. · To upgrade via OTA, internet data traffic is required to download the upgrade file. · If you upgrade the firmware by file, you need to format the memory card on the N4 Pro S dash camera , and then copy the upgrade file to the memory card to upgrade the firmware.
- Page 35 2.6 Menu Introduction The N4 Pro S dash camera function setup has three sections, Record Setup, System Setup, and File Browsing. You can set your dash cam according to your requirements with these function setting. 2.6.1 Record Setup -Resolution: The N4 Pro S camera has 3 recording modes: Recording Mode Resolution...
- Page 36 1080P+720P Front+Cabin 30FPS 2160P+1440P √ 30FPS 2160P+1080P 30FPS 1440P+1440P Front+Rear 30FPS 1440P+1080P 30FPS 1080P+1080P 30FPS 3840x2160P √ 30FPS 2560x1440P 30FPS Front 1920x1080P 30FPS 1280x720P 30FPS -Picture Quality: There are 2 options available, Standard and PlatePix™. The default setting is Standard. -Loop Recording: Default setting is 1 min.
- Page 37 -Stamp: Enable or disable the watermark stamp on video and photos. The watermark stamp includes time and date label, VANTRUE label, license plate number, GPS location information, and speed label. All enabled by default. -Time Lapse: The default value is disabled. You can choose to enable 1FPS/5FPS/10FPS/15FPS.
- Page 38 Vantrue APP. -GPS Settings: GPS is enabled by default. GPS ON/OFF settings, speed unit settings, and GPS information are all set here.
- Page 39 -Format SD Card: Format all data on the memory card. -Format Reminder Setup: Select the reminder options: 15 Days, 1 Month, and Off. Default is off. To prevent you from forgetting to format the memory card regularly, we have added a format reminder time setting.
- Page 40 50Hz or 60Hz frequency according to different regions. -System Info: Check the current model, firmware version, and the VANTRUE official website. -Certification Info: You can view the certification information of N4 Pro S dash cam. -Default Settings: Reset the device back to factory settings.
- Page 41 -Files in Parking Mode: It contains parking mode videos including video recorded in motion detection, low framerate recording, and low bitrate recording modes. -Normal: This folder saves loop recording video and time-lapse video, and private files.. -Photo: Photos files. -All Files: All the videos and photos recorded. Note: The suffix A represents the files recorded by the Front camera, the suffix B represents the files recorded by the Cabin camera.
- Page 42 3. Specifications & FAQs 3.1 Specifications Model N4 Pro S Chips Novatek high-performance processor Image Sensor Sony Sensor G-sensor 3-Axis G-sensor WiFi Built-in 2.4GHz&5GHz Screen 3.19” IPS Screen Camera Angle Front: 155° wide viewing angle; Cabin: 160° wide viewing angle Rear: 160°...
- Page 43 · Firmware upgrade will be carried out from time to time to further improve the product, please pay attention to the official notice of VANTRUE according to the specific upgrade. · This product can record and save images of vehicle accidents, but it does not guarantee that all accident images can be recorded.
- Page 44 · Generally, memory cards have a life span, and long-term use of memory cards may result in data not being saved. In this case, it is recommended to purchase a new memory card for use. If the data is destroyed due to the long-term use of the memory card, the company will not be held responsible.
- Page 45 Wi-Fi band (5GHz/2.4GHz) of the car camera and reconnect. ⑦ Button malfunction: Please check the firmware version of the device and reset the camera. If the problem is still not solved after troubleshooting, please contact VANTRUE official customer service for further assistance. - 41 -...
- Page 46 4. Warranty & Support Warranty The VANTRUE® N4 Pro S Dash Cam comes with a full 12 months warranty. If you register your product on our official site (www.vantrue.net/register), you can extend the warranty to 18 months. Support new If you have any questions about the product, please feel free to contact us at support@vantrue.net, or...
- Page 47 Made in China...
