JETWAY 601CFR1C Manual page 35

¡ ü ¡ ý ¡ ú ¡ û :Move Enter:Select
F5:Previous Values
Resource Controlled By
The Award Plug and Play BIOS has the capacity to automatically configure all of the
boot and Plug and Play compatible devices. However, this capability means absolutely
nothing unless you are using a Plug and Play operating system such as
Windows  95/98. If you set this field to "manual" choose specific resources by going
into each of the sub menu that follows this field (a sub menu is preceded by a ">").
The settings are: Auto (ESCD), Manual.
IRQ Resources
When resources are controlled manually, assign each system interrupt a type,
depending on the type of device using the interrupt.
PCI/VGA Palette Snoop
Leave this field at Disabled. The settings are Enabled, Disabled.
3-10 PC Health Status
This section shows the Status of you CPU, Fan, Warning for overall system status.
This is only available if there is Hardware Monitor onboard.
CMOS Setup Utility – Copyright(C) 1984-2001 Award Software
Show PC Health in Post
Vcore
2.5V
3.3V
5V
12V
Current CPU Temp.
Current System Temp.
Current FAN1 Speed
Current CPUFAN2 Speed
¡ ü ¡ ý ¡ ú ¡ û :Move Enter:Select
F5:Previous Values
Show PC Health in Post
During Enabled, it displays information list below. The choice is either Enabled or
Disabled
Current CPU Temperature/Current System Temp/Current FAN1,FAN2 Speed/
+/-/PU/PD:Value F10:Save
F6:Optimized Defaults
PC Health Status
[Enabled]
1.91V
2.50V
3.40V
5.10V
11.95V
33 ° C/91 ° F
21 ° C/69 ° F
5100 RPM
0
+/-/PU/PD:Value F10:Save
F6:Optimized Defaults
32
ESC:Exit F1:General Help
F7:Standard Defaults
Item Help
Menu Level >
ESC:Exit F1:General Help
F7:Standard Defaults
