IQ Battery 5P

Quick install guide

Scan the QR code for the latest

quick install guide

Scanner le code QR pour obtenir le

dernier guide d'installation rapide

Escanee el código QR para obtener la

última guía de instalación rápida

MOD E L

I QB AT TE RY-5P-1P-NA

V E R SI O N 10

MA R C H 2025

IQ Battery 5P quick install guide

Need help?

Do you have a question about the IQ Battery 5P and is the answer not in the manual?

Questions and answers

Summary of Contents for enphase IQ Battery 5P

Page 1 Escanee el código QR para obtener la última guía de instalación rápida MOD E L I QB AT TE RY-5P-1P-NA V E R SI O N 10 MA R C H 2025 IQ Battery 5P quick install guide...
Page 2 To install the Enphase IQ Battery 5P and the wall-mount bracket, read and follow all warnings and instructions in this guide. Safety warnings are listed at the end of this guide. These instructions are not meant to be a complete explanation of how to design and install an energy storage system. All installations must comply with national and local codes and standards.
Page 3 Installation of Anchor Clip Section C Wiring Install conduit and field wiring Control (CTRL) wiring between system components Cable routing and closing the wiring cover IQ Battery 5P Metering IQ Battery 5P quick install guide...
Page 4 M4 Grounding screw — M5 ID cover Grounding screw — Anchor Clip — Quick install guide — PCS disclaimer label — Wall drill template — Cable tie — CTRL connector — CTRL connector with resistor — IQ Battery 5P quick install guide...
Page 5 (head thickness <5mm) (Min. 6) (Min. 6) Washers As required Provided by the installer IQ Battery 5P lifting handles. Includes one left-side and one Enphase Store/Provided right-side lifting handle (IQBATTERY-HNDL-5) by the installer IQ Battery 5P quick install guide...
Page 6 The IQ Battery 5P and IQ System Controller are both connected to the IQ Gateway and communicate using communication control cables. The Enphase PV system communicates to the IQ Gateway using powerline communication. Verify that the main service is either 240 V /120 V...
Page 7 IQ Battery(ies) if it has been dropped or damaged in any two people to lift it. way. If it is damaged, contact your distributor for replacement. WARNING: Do not lift the packaging with the battery inside after the plastic strips are cut. IQ Battery 5P quick install guide...
Page 8 Choose a location for the IQ Battery array • The IQ Battery 5P housing is a NEMA Type 3R enclosure. The terminal blocks on the IQ Battery 5P accept a maximum conductor size of 3 AWG for L1/L2 terminals and 8 AWG for the Ground terminal.
Page 9 Minimum clearance The mounting instructions are for the included wall-mount bracket WARNING: If mounted in the path of a motor vehicle, Enphase only. If you wish to install IQ Battery 5P in a floor-mount configuration, recommends a minimum mounting height of 91 cm (36 order the pedestal accessory (B05-PI-0550-O) and refer to the floor- above the floor.
Page 10 6.6 in NOTE: IQ Battery 5P must be installed at least 6 inches above the ground. IQ System Controller 3/3G must be installed at least 6 inches above floor for indoor installation and 36 inches above the ground for outdoor installation. IQ Combiner 5/5C must be installed at least 36 inches above ground for installation.
Page 11 NOTE: If the variation of the flatness is more than 2 mm, the battery might not properly sit on the bottom mounting bracket through keyholes. Use spacers if the variation is more than 2 mm. IQ Battery 5P quick install guide...
Page 12 Inclined slots for pedestal assembly The keyholes are to mount the base unit of IQ Battery 5P to the bottom mounting bracket and should not be used to mount the bottom mounting bracket 534 mm (21 in) IQ Battery 5P quick install guide...
Page 13 Depending on the type of installation wall, choose the instructions stated on the template. WARNING: Multiple risks. Ensure not to drill into or attach to electric wiring or pipes in the wall. IQ Battery 5P quick install guide...
Page 14 The bottom mounting bracket can accommodate a slight offset in stud positioning with respect to the battery unit with pre-drilled holes/ slots, as shown in the image. IQ Battery 5P quick install guide...
Page 15 Partially tighten the top shield to the bottom mounting bracket at always need to be mounted to the studs. It can be fastened the ground contact flange. to the supporting wall with the pre-drilled holes if the studs are not aligned. IQ Battery 5P quick install guide...
Page 16 Use standard screws only (head thickness <5 mm). Finally, fully tighten the grounding screws (torque to 1.5 N m/ 13.28 lb-in). NOTE: Use an electric drive; do not use impact drives/impact drills while tightening grounding screws. IQ Battery 5P quick install guide...
Page 17 WARNING: Lift IQ Battery 5P from the packaging using the handles and ensure the battery’s front side is facing toward you. WARNING: Do not lift the IQ Battery 5P using microinverters or the plastic behind the microinverters. This may damage the unit permanently.
Page 18 Only left back conduit* Only right back conduit* * One-side conduit configuration is supported only if the system has one IQ Battery 5P or for the unit last in the daisy chain farthest from the IQ System Controller. IQ Battery 5P quick install guide...
Page 19 GND, and cutout diameter based on the conduit selected. NOTE: Before mounting the unit on the wall, drill the appropriate cutout. Drilling after mounting the unit to the wall can lead to internal component damage, which is not covered by the warranty. IQ Battery 5P quick install guide...
Page 20 NOTE: Use lift assist to avoid any mishap during lifting. To remove the installation handles, pull the plunger outward to unlock them. Then, slide the handle down and pull it away from the unit to remove it. IQ Battery 5P quick install guide...
Page 21 WARNING: The vent or drain holes provided at the back of the unit serve the dual purpose of natural ventilation and condensation drainage. Blocking these holes can affect the functionality of the product. IQ Battery 5P quick install guide...
Page 22 IQ Battery 5P to the wall. Slide the anchor clip downwards until the top surface of the clip coincides with the top surface of the IQ Battery 5P backplate. This ensures no obstructions during the IQ Battery 5P cover installation. IQ Battery 5P quick install guide...
Page 23 When installing a single IQ Battery 5P unit, insert the conduit in the cutouts drilled in the previous step. NOTE: When upgrading an IQ Battery 5P site with a new unit, disconnect B1 and B2 (DC connectors) on the adjacent IQ Battery 5P (units).
Page 24 Ground terminal to 1.5 N m (13.2 lb-in). NOTE: Do not disturb the factory termination connections on terminal blocks during field wiring. IQ Battery 5P unit or From IQ System Controller 3/3G IQ System Controller 3/3G or IQ Battery 5P unit CTRL (shown in a different color for distinction) Ground IQ Battery 5P quick install guide...
Page 25 Section C - Wiring Follow the jacket stripping length and connect the control NOTE: The control cable required for IQ Battery 5P, communication wires to the 4-pin connectors as per the color IQ Combiner 5/5C, and IQ System Controller 3/3G must be compliant with UL 3003, UL 1277, and UL 83 standards.
Page 26 The same conduits can be used for power and control wire control wiring between system components. Connecting drain routing only when using an Enphase Control Cable, i.e., CTRL- wires at both ends of the section can result in communication SC3-NA-01.
Page 27 WARNING: The drain wire should only be terminated on one NOTE: The total length of CTRL wiring across the system end of the control wiring between the system components. cannot exceed 250 ft to ensure the system operates as per specifications. IQ Battery 5P quick install guide...
Page 28 WARNING: The drain wire should only be terminated NOTE: The total length of CTRL wiring across the system cannot exceed 250 ft to ensure the system operates as per on one end of the control wiring between the system specifications. components. IQ Battery 5P quick install guide...
Page 29 IQ Combiner 5/5C > IQ System Controller 3 > IQ Battery(s) 5P 2. Last IQ Battery 5P in the daisy chain (this last battery can be on either DER circuit for IQ Battery or generator) 1. IQ Combiner 5/5C IQ Combiner 5/5C > IQ Battery(s) 5P > IQ System Controller 3/3G 2. IQ System Controller 3/3G 1. IQ System Controller 3/3G IQ System Controller 3/3G > IQ Combiner 5/5C > IQ Battery(s) 5P 2. Last IQ Battery 5P in the daisy chain IQ Battery 5P quick install guide...
Page 30 Ensure the IQ Battery 5P unit is farthest from IQ System Controller 3/3G has a cutout only on one side, and all other sides are covered. If the voltage is within the range as required by local codes, turn off the AC power supply. IQ Battery 5P quick install guide...
Page 31 NOTE: There are two variants of the control switch available in IQ Battery 5P. The control switch cable is secured to the wiring cover using cable ties. Select the control switch available at the site based on the images below and cut the cable ties on the wiring cover to access the control switch cable. IQ Battery 5P quick install guide...
Page 32 Section C - Wiring Fasten the 11 captive screws at the wiring cover as shown. Use an electric drive; do not use impact drives/impact drills. Refer to the red caution label on unit for torque value IQ Battery 5P quick install guide...
Page 33 Blue White WARNING: Risk of electrocution and equipment damage! Do not install CTs when current is flowing in the sensed circuit. Always install CT wires in the terminal blocks before energizing the sensed circuit. IQ Battery 5P quick install guide...
Page 34 Blue White WARNING: Risk of electrocution and equipment damage! Do not install CTs when current is flowing in the sensed circuit. Always install CT wires in the terminal blocks before energizing the sensed circuit. IQ Battery 5P quick install guide...
Page 35 NOTE: Paste the PCS disclaimer label on the wiring cover as shown above for all PCS-enabled IQ Battery 5P units. NOTE: Ensure the serial number label on the ID cover matches that on the heatsink before assembling the ID cover. IQ Battery 5P quick install guide...
Page 36 To fasten the cover to the backplate when two IQ Battery 5P units Fasten the cover to the backplate. are placed close to each other, refer to the table. NOTE: Use an electric drive; do not use impact drives/impact drills. IQ Battery 5P quick install guide...
Page 37 WARNING: Do not leave the DC control switch in the ON position without an AC power supply available. This will deplete the battery and may lead to a condition where the battery cannot be turned ON and cannot be commissioned. IQ Battery 5P quick install guide...
Page 38 Enphase Installer App help topics for more information. Paste the additional nameplate label provided in the After the IQ Gateway has detected the accessories bag on the IQ Battery 5P cover as shown. IQ Battery(ies), the IQ Battery 5P LEDs operate as described in the following section.
Page 39 Remove the conduit covers from both sides of the Remove the two M5 ID cover grounding screws that are IQ Battery 5P cover. used to affix the cover to the backplate. NOTE: Use electric drive; do not use impact drives/impact drills. IQ Battery 5P quick install guide...
Page 40 Unlock the top plastic cover from the ribs, as shown in step 4. Ensure the cover is slightly inclined after this step. Pull the cover off in the indicated direction. IQ Battery 5P quick install guide...
Page 41 WARNING: Ensure not to touch or damage the EMI metal gaskets while removing the clips. EMI metal gaskets are delicate and need to be handled carefully. IQ Battery 5P quick install guide...
Page 42 (up to 30 minutes). After IQ Battery 5P is booted up, the LED becomes blue or green, depending on the charge level. If the LED flashes yellow after one hour or changes to a flashing red state, contact Enphase Support at enphase.com/contact/support. S TAT E...
Page 43 Operation Operating mode and set points IQ Battery 5P supports multiple storage interactive system modes based on usage. Using the Enphase App, select Menu > Settings > Battery Storage. Select one of three battery modes: • Self-Consumption (default, no setting change required) •...
Page 44 NOTE: During a brownout or blackout, IQ Battery 5P powers down automatically. This is normal. When power is restored, it automatically starts up again. If you do not see IQ Battery 5P information in the Enphase App, check that the IQ Gateway and the internet connection are working.
Page 45 DANGER: Risk of fire. If the IQ Battery(ies) generate smoke, remove AC electrolyte is toxic and highly flammable. The leaked electrolyte is colorless and power from the Enphase system and turn the DC control switch to the off has a sweet odor. Electrolyte fluid tends to evaporate quickly, leaving behind a position so that charging/discharging stops.
Page 46 • If the IQ Battery(ies) has already been installed, it must be turned OFF at NOTE: All Enphase IQ Batteries are constructed with sealed lithium iron around 30% state of charge prior to uninstalling. A battery can be stored cells and utilize lithium iron phosphate (LiFePO4) chemistry. This chemistry for a maximum of two months if the last known State of Charge was 30%.
Page 47 R E V I S I O N D AT E D E S C R I P T I O N 140-00279-10 March 2025 Added "IQ Battery 5P metering" section. 140-00279-09 October 2024 Updated voltage information. 140-00279-08 August 2024 Updated safety section based on UL recommendations.
Page 48 Installer notes IQ Battery 5P quick install guide...
Page 49 Installer notes IQ Battery 5P quick install guide...
Page 50 IQ Battery-5P-QIG-140-00279-10-EN-US-2025-03-21 © 2025 Enphase Energy. All rights reserved. Enphase, the e and CC logos, IQ, and certain other marks listed at https:/ /enphase.com/trademark-usage-guidelines are trademarks of Enphase Energy, Inc. in the U.S. and other countries. Data subject to change.
