Page 2 An Important Message From EMMO Thank you for choosing EMMO. Congratulations on your purchase of a new ZONE II GTS/ ZONE II MAX. This document is intended as a short introduction to your new e-bike. It contains essential safety, performance and service information.
Page 3: Table Of Contents
Content About This Manual �� 6 About EMMO �� 7 Rules and Regulations �� 8 Safety Disclaimer �� 11 Description �� 14 Schematic Diagram �� 14 Geometry ......................................14 Specifications ......................................15 Side View ......................................16 Handlebar Attachments ..................................17 Dashboard ......................................18 Operation Guide �� 20 How to turn on the bike ��...
Page 4 How to Lock the Steering ...................................23 Circuit Breaker .....................................24 CarPlay �� 27 USB-A / USB-C Charging Ports �� 28 Multimedia Controls �� 29 Bluetooth Speaker Control Fob .................................29 Speaker Control Panel ..................................30 Left Switches �� 32 Right Swithces �� 33 Throttle ��...
Page 5 Disposal ........................................53 Storage & Maintenance ..................................54 Kickstand & Kill Switch �� 55 Passenger Footpeg �� 56 Pedal �� 57 Rear View Mirrors �� 58 Light & Signals �� 60 Adjusting the Brake �� 62 Cleaning / Lubricating the Chain �� 63 Tire Pressure ��...
Page 6: About This Manual
About This Manual This document is intended as a short introduction to your new e-bike. It contains important safety, performance and service information. Read and understand it along with the information provided during the on-delivery instructions before using the product. Pay special attention to the safety messages as shown here, and keep the manual handy for future reference.
Page 7: About Emmo
About EMMO Emmo is a leading Canadian manufacturer of electric bikes based in Toronto, Ontario. Since 2009, we have equipped over 500,000 people across Nor th America with eco-friendly transpor tation, emphasizing a zero-emission future. Our diverse range of products caters to commuting and leisure, enhancing every ride with effortless and enjoyable cycling experiences.
Page 8: Rules And Regulations
Rules and Regulations According to Canada’s Motor Vehicle Safety Regulations ( MVSR ). A qualified e-bike (defined as Power Assist Bicycle) must meet the following requirements: • The e-bike must have operational pedals • Upper wattage limit for the motor is 500W •...
Page 9: Useful Links
Rules and Regulations Useful links: E-Bike Regulations in Ontario: https://www.ontario.ca/page/riding-e-bike E-Bike Regulations in British Columbia: https://www2.gov.bc.ca/gov/content/transportation/driving-and-cycling/cycling/e-bike-rules-of-the-road E-Bike Regulations in Alberta: http://www.transportation.alberta.ca/content/doctype45/production/mopedpowerbikes.pdf E-Bike Regulations in Manitoba: https://www.gov.mb.ca/sd/parks/_resources/en/pdf/power-assisted-bicycles.pdf E-Bike Regulations in Saskatchewan: https://www.sgi.sk.ca/motorcycle/-/knowledge_base/motorcycle-handbook/power-assisted-bicycles1 E-Bike Regulations in Quebec: https://saaq.gouv.qc.ca/en/road-safety/modes-transportation/electric-bike E-Bike Regulations in New Brunswick: https://www2.gnb.ca/content/gnb/en/services/services_renderer.200814.Motor_Vehicle_Registration.html...
Page 10 E-Bike Regulations in Nova Scotia: https://novascotia.ca/just/regulations/regs/mv18786.htm E-Bike Regulations in Prince Edward Island: https://www.princeedwardisland.ca/en/information/transportation-and-infrastructure/power-assisted-bicycles Know and obey all relevant local laws It is your responsibility to research and understand relevant laws where you ride your bike. Such laws may cover required helmets and safety gear, required lights and reflectors, required hand signals, where you can legally ride a bike (bikes and ebikes may have different restrictions), how fast you can go, what (if any) cargo or passengers you can carry, rider age, and more.
Page 11: Safety Disclaimer
Safety Disclaimer This manual contains important safety, performance and service information� Read and understand it along with the information provided during the on-delivery instructions before using the product, and keep it for reference� Ensure that you comprehend all instructions and safety notes/ warnings� WARNING: Ensure the bike FITS you properly before use.
Page 12 EMMO. Contact us if you have any question or concern.
Page 13 • Charge the battery only with the charger that was supplied with the e-bike or supplied by an official EMMO dealer. • DO NOT use the battery & charger for other purposes. • Never connect the battery's terminals with each other.
Page 14: Description
Description 1. Schematic Diagram a� Geometry...
Page 15: Specifications
Description 1. Schematic Diagram GEOMETRY b� Specifications Battery Charger MODEL: SSLC300V71 INPUT: AC120V~3.0A 60Hz OUTPUT:71.4V 4.0A Height 44.5” / 113 cm Clearance Height 9.8” / 25 cm Wheel Bass 56” / 143 cm Length 81” / 206 cm Seat Height 30.3”...
Page 16: Schematic Diagram
Description 1. Schematic Diagram c� Side View Headlight Front Turning Signal Light Windshield Primary Controls GasTank Storage Charging Port Driver Footpeg Driver Seat Passenger Footpeg Passenger Seat Taillight Rear Turning Signal Light Bluetooth Speaker Rear Fender Rear Wheel with Motor Front Fender Front Shocks Front Wheel...
Page 17: Handlebar Attachments
Description 1. Schematic Diagram d� Handlebar Attachments Rear View Mirrors Speedometer USB-A / USB-C Charging Ports Brake Fluid Reservoir Rear Brake Lever Left Switch Housing Left Grip Ignition Front Brake Lever Right Switch Housing Throttle...
Page 18: Dashboard
Description 1. Schematic Diagram e� Dashboard km/h SOC% 00 00 000001 00 �0 L 72V 78.8 V...
Page 19 Description 1. Schematic Diagram km/h State of Speed Per Hour Refers to the current speed at which the bike is moving. Speedometer Indicates the real-time speed of the bike. Odometer Total travel distance of the bike (can not be reset). 000001 Speed Mode Indicator Indicates the speed level (this function may not be available for certain models).
Page 20: Operation Guide
Operation Guide 1. How to Turn on the Bike a� Remote Press the button once to activate the an- Lock Button ti-theft alarm system. Press the button once to cancel the alarm Unlock/Cancel Button or to turn off the bike if the bike is turned on with the remote.
Page 21: Key Ignition
Operation Guide 1. How to Turn on the Bike b� Key Ignition Power Off Power On Steering Lock (push) This is a three-position switch that is located on the body: • Power Off • Power On • Steering Lock...
Page 22 Operation Guide 1. How to Turn on the Bike c� Key Ignition POWER POWER To turn on the bike: • Insert the key. • Follow the marking on the ignition, turn the key to the right to turn on the bike.
Page 23: How To Lock The Steering
Operation Guide 1. How to Turn on the Bike c� How to Lock the Steering To lock the steering: • Turn the ignition off. • Turn the handlebar all the way to the left. TURN THE HANDLEBAR TO THE LEFT •...
Page 24: Circuit Breaker
Operation Guide 1. How to Turn on the Bike d� Circuit Breaker To unlock the seat lock: UNLOCK TH E SEAT LOCK II. Inser t the key and unlock the III. W h i l e s l i d i n g t h e p a s s e n g e r I. The passenger seat lock is locat- passenger seat lock by turning seat cushion forward to detach...
Page 25 • Follow the marking on the circuit breaker to turn on/off the circuit breaker. • Close the seat. WARNING: DO NOT The wires inserted into the circuit breaker could have high voltage output. touch any bare wires. If you have any concern, contact your EMMO dealer for assistance.
Page 26 Operation Guide 1. How to turn on the bike e� Circuit Breaker How to close the seat PUSH SEAT LOCK • There are two lock hooks located on the bottom of the seat cushion. • Make sure the two hooks are inserted in the hook catches. •...
Page 27: Carplay
Operation Guide 2. CarPlay CLICK ON CAR APP RETURN TO SPEED METER km/h SOC% 00 00 • On your iPhone: go to Settings > General > CarPlay. 000001 00 �0 • Select Available Devices, and choose your vehicle. • Follow on-screen pairing instructions. L 72V 78.
Page 28: Usb-A / Usb-C Charging Ports
Operation Guide 3. USB-A / USB-C Charging Ports USB-C Charging Port USB-A Charging Port...
Page 29: Multimedia Controls
Operation Guide 4. Multimedia Controls a� Bluetooth Speaker Control Fob (For models equipped with Bluetooth Speaker) Press once to turn on the radio system. 1. The Exhaust mode is set by default. 2. Hold the button to switch to MP3 mode.You can pair Bluetooth Power / Mode Switch device with the built-in MP3 player(Accessory).
Page 30: Speaker Control Panel
Operation Guide 4. Multimedia Controls b� How to Open the Speaker Control Panel II. To access it, twist the cap III. Remove the cap to view the I. The control panel is located on counterclockwise ( ) and pull control panel. the left side of the Bluetooth exhaust speaker.
Page 31 Operation Guide 4. Multimedia Controls c� Speaker Control Panel Tap once to turn on the radio system. 1. The Exhaust mode is set by default. 2. Hold the switch change to MP3 mode.You can pair Bluetooth Power / Mode Switch device with the built-in MP3 player (Accessory).
Page 32: Left Switches
Operation Guide 5. Left Switches High Beam Press the button will flash the high beam. Flasher Slide the switch to the right will turn on the Right Turning right side turning signals. (Push the switch Signal lever in to cancel the turning signal). High Beam Press it down will turn the high beam on.
Page 33: Right Swithces
Operation Guide Operation Guide 6. Right Swithces The switch housing on the handlebar hold these switches that control the lights, signals, horn and etc.. Headlight Slide the switch to turn on the headlight and tail light. Tail light Tail Light Slide the switch to turn on the tail light.
Page 34: Throttle
Operation Guide 7. Throttle The throttle controls the speed of the e-bike. As shown below, twist the throttle towards you to operate. With the help of the speed mode switch, you can also change the speed setting. HIGH SPEED MEDIUM SPEED SPEED WARNING:...
Page 35: Speed Governor
Operation Guide 8. Speed Governor The speed governor restricts the maximum speed of the e-bike. By default, it is enabled. By Law, you must keep it enabled when travelling on public roads. This will limit the e-bike to low-speed mode, capping at 32km/h.
Page 36: Gastank Storage
Operation Guide 9. GasTank Storage a� How to open the tank UNLOCK TH E LOCK II. Inser t the key and unlock the III. Opening the gastank. I. The gastank lock is located on gastank lock by turning the key t h e b i ke 's l e f t s i d e , b e l o w t h e driver's seat.
Page 37 Operation Guide 9. GasTank Storage b� How to close the tank II. Firmly press down on the centre I. Lower the gastank lid back into of the gastank lid until it locks place. securely.
Page 38: Charger
Operation Guide 10. Charger a� Lead Acid Charger Front Label Charging Indicator Charger Specification Label Charging Plug...
Page 39 Operation Guide 10. Charger a� Lead Acid Charger a� Lead Acid Charger A. Front Label The front label contains brief information of the voltage and capacity of the battery that the charger should be used for (more details are included in the specification label on the back of the charger). •...
Page 40 Operation Guide 10. Charger a� Lead Acid Charger B. Charging Indicator Charging Indicator Explanation: • During charging, the red light stays on. • The indicator will turn green when the battery is fully charged. NOTICE: If the charger gets warm during regular use, this is a normal response and is no cause for concern.
Page 41 Operation Guide 10. Charger a� Lead Acid Charger C. Charger Specification Label NOTICE: Charger specifications varies based on the model and battery capacity.
Page 42 Operation Guide 10. Charger a� Lead Acid Charger D. Charging Plug How to charge: • The charging port is located on the left side of the bike, close to the footpeg. (Refer to "side view", on page 16.) • Open the charging port lid and plug in the charger. •...
Page 43: Lithium Charger
Operation Guide 10. Charger a� Lithium Charger Charger Label Charging Indicator Charger Specification Label Power Cord Socket Power Cord Charging Plug...
Page 44 FLASHING GREEN: Lire les instructions 1 acant d'utiliser le chargeur It is your responbility to make sure that you are charging your e-bike with the correct charger. 0-30 °C CHARGING Contact your EMMO dealer if you have any questions or concerns.
Page 45 Operation Guide 10. Charger b� Lithium Charger B. Charging Indicator Charging Indicator Explanation: • During normal charging, the indicator will light up as red. • The indicator will turn green when the battery is fully charged. NOTICE: If the charger gets warm during regular use, this is a normal response and is no cause for concern.
Page 46 Operation Guide 10. Charger b� Lithium Charger C. Power Cord Socket D. Power Cord Connecting the charger: • Plug the device connector E of the power cable into the device socket D on the charger. WARNING: DO NOT plug the power cord directly to the bike/battery. High voltage may damage the bike/ battery and cause severe iniury.
Page 47 Operation Guide 10. Charger b� Lithium Charger E. Charging Plug How to charge: • The charging port is located on the left side of the bike, close to the footpeg. (Refer to "side view", on page 16.) • Open the charging port lid and plug in the charger. •...
Page 48 Always ensure that only the selected battery’s circuit breaker is switched on while the other is off. WARNING: DO NOT The wires inserted into the circuit breaker could have high voltage output. touch any bare wires. If you have any concern, contact your EMMO dealer for assistance.
Page 49 Operation Guide 10. Charger b� Lithium Charger F. How to Charge Dual Lithium Batteries. Primary Secondary Secondary Circuit Circuit Circuit Explanation Breaker Breaker-A Breaker-B The bike still works with both batteries connected. But only one battery should be connected to the bike at a time. Battery A is connnected to the bike.
Page 50 Charging Precaustions WARNING: • You must use the compatible charger (approved by EMMO) to charge the battery. • DO NOT submerge or allow the charger to become submerged in water or any liquid. • DO NOT use the charger if the cord becomes frayed, has exposed solution or wires or shows any damage.
Page 51: Battery
Operation Guide 11. Battery a� Lithium Battery Anderson Connector Charging Port...
Page 52: Battery Safety Precautions
Operation Guide 11. Battery b� Battery Safety Precautions • Be sure to use the original/compatible battery (approved by EMMO). Using batteries from other brands may lead to severe accidents. • Inspect the battery for any damage, leaking, overheating or smoking.
Page 53: Disposal
Used batteries must be treated as hazardous waste. • Batteries must be disposed of in accordance with the the regulations set forth by your local govern- ment/organizations. • service@emmo.ca In case of uncertainty, please contact EMMO customer service department at...
Page 54: Storage & Maintenance
Operation Guide 11. Battery d� Storage & Maintenance • For storage, please disconnect the battery from the bike and charge the battery on a regular basis (at least once a month). • Battery packs and chargers need to be stored in a clean, dry, well ventilated place, avoid contact with corrosive material, and keep them away from heat and fire.
Page 55: Kickstand & Kill Switch
Operation Guide 12. Kickstand & Kill Switch How to use the side kickstand and kill switch: • Kick the side stand down and gently lean the bike on the side kickstand. • Make sure it is stable before you leave your bike. •...
Page 56: Passenger Footpeg
Operation Guide 13. Passenger Footpeg Foldable Passenger Footpegs: • Passenger footpegs are located near the rear wheel. • Unfold the footpegs as shown when needed.
Page 57: Pedal
Operation Guide 14. Pedal PUSH How to fold the pedals: • Push the pedal from the side (as shown). • Fold the pedal up while you continue pushing from the side.
Page 58: Rear View Mirrors
Operation Guide 15. Rear View Mirrors Rear view mirrors make it safer for you to check the traffic condition behind you. Please make sure the rear view mirrors are adjusted and secured properly. Check the rear view mirrors and your blind spots before you make a turn or overtake other vehicles.
Page 59 Operation Guide 15. Rear View Mirrors Loosen Tighten • Loosen the bolt slightly and adjust the holding pole to a preferred position so that you have a good view of the rear. • Hold the mirror firmly in place and tighten the bolt with the allen key. NOTICE: To adjust the mirrors you will need: a 6mm Allen Key (Hex Key).
Page 60: Light & Signals
Operation Guide 16. Light & Signals a� Headlight & Tail Light The headlight assembly features high beam, low beam, and daytime running light modes for varying conditions. The tail light enhances nighttime visibility. The brake light alerts traffic behind you when you’re slowing down. Headlight Tail light...
Page 61 Operation Guide 16. Light & Signals b� Signal Lights & Brake Light The build - in turning signals give the nearby traffic a better insight of your intended route. The brake light alerts traffic behind you when you’re slowing down. Signal Lights Rear Signal Lights &...
Page 62: Adjusting The Brake
Operation Guide 17. Adjusting the Brake INCREASE DECREASE DECREASE INCREASE How to Adjust: • The adjustment nut is located on the brake lever. Use it to adjust the gap between the lever and the hand grip.
Page 63: Cleaning / Lubricating The Chain
Operation Guide 18. Cleaning / Lubricating the Chain How to Clean the Chain: • Put the bike on a service stand or lean the bike on the kick/side stand. Make sure the rear wheel is off the ground. • Locate the chain on the right side of the bike, near the rear wheel hub. •...
Page 64: Tire Pressure
Operation Guide 19. Tire Pressure It is recommended to check the tire pressure on a regular basis to keep things at their best working conditions. 30 PSI I. Locate the valve on the rim. II. Remove the valve cap. III. The recommended tire pres- sure as marked on the side- wall of the tire.
Page 65 Operation Guide 19. Tire Pressure Tire pressure affects the following: • Service life of the tires and other components of the bike • Ride safety • Ride comfortable • Travel Distance WARNING: • You MUST inflate the tire to the recommended tire pressure before the first ride. Failure to do so may damage your bike and void your warranty.
Page 66: Serial Number
Operation Guide 20. Serial Number a� Frame Number Find the Frame Number: • The frame number is located on the neck of frame. • You will find the Frame Number engraved on the frame.
Page 67: Motor Number
Operation Guide 20. Serial Number b� Motor Number Located on the motor. EN140MKM0009 The motor number could be located at the following locations: • Location 1: On the motor cover plate. • Location 2: Behind the sprocket on the motor.
Page 68: Riding Guide
Riding Guide 1. Checking List Before Riding • Whether the handlebar is stable and flexible when turning. • Whether the right and left switches on the handlebar can work properly. • Whether the throttle can work properly. • Make sure the tires are inflated to the recommended tire pressure (30 PSI). •...
Page 69: Warranty Policy
Any warranty is extended to the original owner with the original purchase paperwork. This portion does not cover the purchase of parts or the purchase of products sold by Emmo Inc that is not an electric bike, electric scooter ebike, electric motorcycle style ebike, electric mobility scooter, kick-style electric scooter, or ride-on toy.
Page 70 Please consult your Emmo dealer for more details of the parts policies. • Shipping Damage: Emmo Inc will not be held responsible for any lost, stolen, or damaged items due to any delivery services or courier actions� Report any damage to Emmo Inc within 7 days of receiving the part with...
Page 71 Emmo is not responsible for any damage resulting in using another brand or voltage of charger or using an Emmo item with items that are not sold by Emmo Inc� Within 7 days, any items defective by manufacturer quality and are under warranty can be replaced� After 7 days, any items defective in manufacturer quality and are under warranty can be repaired�...
Page 72 • For repairs that are done on items that are not from Emmo Inc, only a 7-day Parts Warranty will be included� Emmo Inc is not responsible for items modified from its intended use or purpose resulting in damage to the ebike or injury to the customer or third party�...
Page 73: Leave Us A Review
Leave us a review By sharing your experience with EMMO, you can extend your warranty for an extra 3 months for FREE� Your review will help us to continue providing great products and services, and help others understand how EMMO can make their life greener.
Page 74: Contact Us
Contact Us LOCATION EMMO Mississauga EMMO Toronto 1224 Dundas St E, Unit 6 438 Spadina Ave, Unit 2 Mississauga, ON L4Y 2C5 Toronto, ON M5T 2G8 Canada Canada EMMO Vaughan Toronto Service Center 1750 Steeles Avenue West, Unit 15-17 438 Spadina Ave, Unit 5-6...
Page 75 WWW�EMMO�CA...
