- Page 1 www.CookWithKenyon.com REMOTE CONTROL ELECTRIC GRILL OWNERS MANUAL Part # 143735 Revised: 06/26/2025...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safeguards ........................3 How to Use Grill Quick Start Tips ........................4 Product Specifications ........................6 Installation Instructions Package Contents ........................7 Electrical Requirements ......................8 Countertop Installation ......................9 Drain Connection ........................12 Outlet Location ........................12 Final Preparations Prior to Use ...................12 Operation of Grill Touch Control ........................14 Power Cord .........................17... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: 1. Read ALL instructions prior to using product. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electrical shock, do not immerse cord or plugs in water or other liquid. 4. -
Page 4: Quick Start Tips
1. Before using your grill, remove the cooking grate and drip tray from the grill. Wash the grill with warm soapy water using a non-abrasive cloth. USE ONLY HIGH TEMP PLASTIC UTENSILS WHEN GRILLING. Visit our web site to purchase a set of high quality stainless steel/high temp plastic grill utensils, www.cookwithkenyon.com. - Page 5 12. To clean the grill, first be sure the cooking surface has cooled enough to handle. Then remove the grate, lift up the electric element until it locks in the up position, then the drip tray. 13. Wipe the stainless steel surfaces with a damp cloth to remove any residue from previous grilling sessions.
-
Page 6: Product Specifications
PRODUCT SPECIFICATION Frontier Remote Control Model B70300 - 120V AC - 1300 WATTS - 11 AMPS Model B70301 - 240V AC - 1300 WATTS - 6 AMPS Overall dimensions: 18” x 12” x 5” (8 1/2” with lid) 457.2mm x 304.8mm x 127mm (216mm with lid) Cutout dimensions: 17”... -
Page 7: Installation
Portable grill drain fitting comes with a plug. If portable grill owners would like to install elbow fitting and hose instead of plug please contact KENYON. If any components are missing or damaged, call KENYON immediately. Fig. 1... -
Page 8: Electrical Requirements
KENYON Max Load Power Supply Plug Type Cord Dimension Part # B70300 3 prong cord with GFCI 86” (2184mm) 120V AC 11A 60Hz 3 prong cord B70310 1300 Watts 63”... - Page 9 156mm COUNTER FEMALE CONNECTOR TO PORTABLE GRILL POWER CORD CHART CONNECTOR COVER MODEL NUMBER PLUG TYPE DIMENSION A 65in B70300 120V 3-PRONG GFCI CORD 86in [2184mm] [1828mm] B70311 240V 3-WIRE CORD, NO PLUG 67in [1702mm] PORTABLE GRILL ENCLOSURE 7.72in 3.50in...
- Page 10 Please read this section prior to making cutout for the grill and remote control. It is important to plan ahead for installation of the grill, keeping the following dimensions in mind (please refer to Fig. 2 below). A - 13 inches maximum depth of overhead cabinets B - 36 inches is minimum height of counter top above floor...
- Page 11 WARNING: To eliminate the risk of burns from reaching over heated grill, cabinet storage space located above the grill should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a range hood that projects horizontally a minimum of 5 inches beyond the bottom of the cabinets.
-
Page 12: Drain Connection
Drain Connection For your convenience, the grill is equipped with a 1/8” NPT brass pipe fitting and 90º brass elbow which you can attach the 1/4” ID flexible hose that came with your grill. The portable version of the grill comes with a brass pipe plug. -
Page 13: Operation Of Grill
DO NOT COOK ON BROKEN GRILL GRATE OR GRIDDLE If the grate should break, grease and oils may come into direct contact with the electric element and create a risk of electric shock or fire. Contact an authorized service center or KENYON Customer Care immediately at (860) 664-4906. -
Page 14: Touch Control
Touch Control POWER ON INDICATOR (+) POWER This display indicates whether the grill is ON SENSOR or OFF. POWER ON POWER LEVEL POWER LEVEL DISPLAY INDICATOR DISPLAY Digital display indicates heat output of grill. The indicator lamps follow the sweep of the screened graphic. -
Page 15: Heat Settings
BUTTON ON THE GFCI. REFER TO FIG. 5. AUTOMATIC SHUT-OFF The electronic control of your KENYON grill has been programmed with safety in mind and features an automatic shut-off. The grill is programmed to shut down after a predetermined time after being energized (see table below). -
Page 16: Preheat And Auto Shut-Off Time
PREHEAT AND AUTO SHUT-OFF TIME The grill control has a preheat function which applies full power for a set amount of time for each power setting selected. This preheat function brings the grate/griddle to the desired grilling temperature quicker thus allowing you to begin grilling quicker. The table below provides the preheat time and auto shut-off time for each power setting. -
Page 17: Power Cord
Power Cord THIS PERTAINS TO 120V GROUNDED 3-PRONG PLUG GFCI MODELS ONLY GROUND FAULT CIRCUIT INTERRUPTER (GFCI) The GFCI is a safety device designed to protect the user from any electrical shock hazard. INDICATOR LIGHT The indicator light will stay illuminated when electrical power is applied and indicates that the GFCI is working properly. -
Page 18: Grill Parts
BAFFLE in the drip tray before cooking. The TRAY replacement for the disposable drip tray is Kenyon part #B96001. GRATE The grate must be cleaned after every use. HEATING The grate has a nonstick coating for ease of ELEMENT cleaning. -
Page 19: Lid Removal
Lid Removal Fig. 7 LID REMOVAL The grill lid is removable for cleaning. To remove the lid, slide the quick release pin out of the hinge. (see Fig. 7) With the quick release pin removed, QUICK RELEASE grasp the lid, lifting on the left side to clear the hinge and slide it the left until clear of the hinge pin on the right. -
Page 20: Stainless Steel Maintenance Checklist
Every Use (Quick Wipe Down) Outdoor Care After the grill cools, wipe down exterior stain- Use a high-quality, breathable grill cover. Kenyon offers custom-fitted covers for all less steel surfaces with a paper towel to remove any grime. grills made with Sunbrella fabric. -
Page 21: Statement Of Warranty
KENYON Statement of Warranty Kenyon International, Inc (the “Company”) warrants its products in normal usage to be free of defects in materials and workmanship subject to the conditions and limitations below. Any part, which proves to be defective in normal usage during the warranty period will be repaired or replaced by the Company.
