- Page 1 DRP Series Quick Installation Guide Version 2.0, April 2025 Technical Support Contact Information www.moxa.com/support 2025 Moxa Inc. All rights reserved. P/N: 1802001004020 *1802001004020*...
- Page 2 Overview The DRP Series DIN-rail computers are powered by an Intel Atom®, Intel® Celeron®, or Intel® Core™ i5/i7 processor. The computers come with a rich set of interface options including up to 8 software- selectable RS-232/422/485 serial ports and up to 10 gigabit Ethernet ports.
- Page 3 DRP-C100-L-T/C1-8L-T/C5-8L-T/C7-8L-T Models DRP-C100-C-T/C1-6C-T/C5-6C-T/C7-6C-T Models DRP-C100-C1-2L4C-T/C5-2L4C-T/C7-2L4C-T Models - 3 -...
- Page 4 DRP-A100-T/E2-T/E4-T/E2-T-Win10/E4-T-Win10 Models DRP-A100-L-T/DRP-A100-E2-8L-T/E4-8L-T Models DRP-A100-C-T/DRP-A100-E2-6C-T/E4-6C-T Models - 4 -...
- Page 5 DRP-A100-E2-2L4C-T/E4-2L4C-T Models Dimensions DRP-C100-T/C1-T/C5-T/C7-T/C1-T-Win10/C5-T-Win10/C7-T- Win10 Models DRP-A100-T/E2-T/E4-T/E2-T-Win10/E4-T-Win10 Models - 5 -...
- Page 6 DRP-C100-L-T/DRP-C100-C1-8L-T/C5-8L-T/C7-8L-T Models DRP-A100-L-T/DRP-A100-E2-8L-T/ E4-8L-T Models DRP-C100-C-T/C1-6C-T/C5-6C-T/C7-6C-T Models DRP-A100-C-T/DRP-A100-E2-6C-T/E4-6C-T Models - 6 -...
- Page 7 DRP-C100-C1-2L4C-T/C5-2L4C-T/C7-2L4C-T Models DRP-A100-E2-2L4C-T/E4-2L4C-T Models LED Indicators The following table describes the LED indicators located on the front panel of the DRP Series: LED Name Status Function Power Green Power is ON No power input or any other power error Ethernet...
- Page 8 Installing the DRP Computer DIN-rail Mounting The DRP computers come with a DIN-rail bracket attached. To install the computers on to a DIN rail, do the following: STEP 1: Check the DIN-rail bracket that comes preinstalled on the rear panel of the DRP computers.
- Page 9 Connecting the Power The DRP computers are provided with 2-pin power input connectors in a terminal block on the front panel. Insert the power-cord wires into the connectors and tighten them to secure the wires in place. Plug in the power cable to a power source.
- Page 10 NOTE For surge protection, connect the grounding connector located below the power connector with the earth (ground) or a metal surface. A 4 mm conductor must be used when the connection to the external grounding screw is utilized. The heat sink is grounded to the chassis by an internal screw.
- Page 11 – USB Hosts The DRP Series has 3 USB 3.0 Type-A connectors located on the front panel. The ports support keyboard and mouse devices and can also be used to connect a flash disk for storing large amounts of data.
- Page 12 Connecting Displays The DRP computer comes with a VGA and a HDIM display output located on the front panel for connecting to audio or video devices. NOTE Use an HDMI-certified cables for a reliable audio or video connection. Replacing the Battery The DRP computer comes with one slot for a battery on the bottom panel of the computer.
- Page 13 To replace the battery, do the following: 1. Unfasten the two screws on the battery cover. 2. Take off the cover. The battery is attached to the slot cover as indicated in the image. 3. Unplug the connector of the battery-cover assembly from the internal wire of the slot.
- Page 14 Hazardous Location Specifications DRP-A100 Series Trade Mark: Model/Rating: Model Names: DRP-A100-E2-T • DRP-A100-E2-T-Win10 • DRP-A100-E2-8L-T • DRP-A100-E2-6C-T • DRP-A100-E2-2L4C-T • DRP-A100-E4-T • DRP-A100-E4-T-Win10 • DRP-A100-E4-8L-T • DRP-A100-E4-6C-T • DRP-A100-E4-2L4C-T • Rating: 12 VDC, 5 A or 24 VDC, 2.5 A •...
- Page 15 DRP-C100 Series Trade Mark: Model/Rating: Model Names: DRP-C100-C1-T • DRP-C100-C1-T-Win10 • DRP-C100-C1-8L-T • DRP-C100-C1-6C-T • DRP-C100-C1-2L4C-T • DRP-C100-C5-T • DRP-C100-C5-T-Win10 • DRP-C100-C5-8L-T • DRP-C100-C5-6C-T • DRP-C100-C5-2L4C-T • DRP-C100-C7-T • DRP-C100-C7-T-Win10 • DRP-C100-C7-8L-T • DRP-C100-C7-6C-T • DRP-C100-C7-2L4C-T • Rating: 12 VDC, 6.82 A or 24 VDC, 3.25 A •...
- Page 16 • The EUT with other operating units shall be mounted with a minimum spacing of 2.5 cm on both sides and above/below or standalone. WARNING EXPLOSION HAZARD Do not remove or replace battery unless power has been disconnected or the area is free of ignitable concentrations. AVERTISSEMENT—RISQUE D’EXPLOSION.
