Micsig MHO1 Series Quick Manual

Quick Guide Quick Guide
High Resolution Tablet Oscilloscope MHO1 Series High Resolution Tablet Oscilloscope MHO1 Series
1. General Inspection 1. General Inspection
Please check package status when received the goods:
■Check Transport Damage
If you find serious damage to the packing box or foam plastic,please keep
them until the equipment passed electrical and mechanical performance
tests.
■Check The Accessory
A packing list is included in the box. Please check if the accessories
arecomplete.lf accessories are missing or damaged, please contact the seller.
■Check The Instrument
If the appearance of the oscilloscope is damaged or fails to pass the
performance test, please contact the seller or Micsig
Oscilloscope lmplementation standard: GB/T15289-2013
2. Initial Start-up 2. Initial Start-up
For first time use, please connect the adapter first and then start the
oscilloscope. Make sure the power lock is in the pressed-down position.
Power Lock
Popped-up: Power-off
Note: Please use Micsig standard power adapter to charge the oscilloscope to Note: Please use Micsig standard power adapter to charge the oscilloscope to
prevent damage. prevent damage.
3. Language Setting 3. Language Setting
1) Press button on the button control panel;
2) Select "Settings" on homepage;
3) Select "System"
4) Select "Languages & input"
5) Select "Languages"
6) Select " Add a Languages"
7) Select your language and apply.
Tablet Oscilloscope Creator
Optical-isolated Probe Leader
Power Lock
Pressed-down: Power on
;
;
;
;
4. User Manual (built-in) 4. User Manual (built-in)
12 bit Touch 12 bit Touch
Screen Screen
Analog Channels Analog Channels
Bracket Bracket
Built-in Built-in
Battery Battery
(optional) (optional)
Button Panel Button Panel
Power Button Power Button
Multimeter Jack Multimeter Jack
Multimeter is not included in the model with the "N" symbol
Type-C Type-C USB 3.0 Host USB 3.0 Host
Trigger Output Trigger Output
Power Socket Power Socket
Power Lock Power Lock
HDMI HDMI
Bracket Bracket
