LEG PRESS MACHINE
400698 - LEGPRS1-LEGPRS2-LEGPRS3;
UPDATED VERSION: 401486 - LEGPRSKIT
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!
Advertisement
Related Manuals for Titan Fitness LEGPRS1
Summary of Contents for Titan Fitness LEGPRS1
- Page 1 LEG PRESS MACHINE 400698 - LEGPRS1-LEGPRS2-LEGPRS3; UPDATED VERSION: 401486 - LEGPRSKIT Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
- Page 2 ASSEMBLY PARTS DIAGRAM / EXPLODED VIEW ASSEMBLY PARTS LIST DESCRIPTION DESCRIPTION Rear Base Frame Right Side Handle Frame (22) Rear Upright Frame (23) Left Side Handle Frame Back Pad Frame Waist Pad (27) Combination Back Pad (10) Diagonal bracing (28) (11) Weight Plate Holder (29)
- Page 3 HARDWARE PACK...
- Page 6 ASSEMBLY INSTRUCTIONS STEP 1 1. Assemble the Middle Base Frame (3) with Rear Base Frame (1), using Flat Washer Φ11*Φ20*2(55), Nut M10 (57) and Hex Bolt M10*95 (59). 2. Assemble the Rear Upright Frame (2) with Rear Base Frame (1), using Flat Washer Φ11*Φ20*2(55) and Hex Bolt M10*25 (60).
- Page 7 ASSEMBLY INSTRUCTIONS STEP 2 1. Assemble Upper Cross Frame (6) with Rear Upright Frame (2), using Flat Washer Φ11*Φ20*2(55), Nut M10 (57), Hex Bolt M10*120(63), and Hex Bolt M10*70 (64). 2. Remove the Flat Washer Φ11*Φ20*2 (55), Nut M10 (57) , Hex Bolt M10*30 (65) from Right &Left Side Frame (17&18).Connect Right &...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Adjust the Pedal (12) to the proper position. The Right &Left Limited Frame (15&16) through the hole on Right &Left Side Frame (17&18), then insert it into the Fixing Frame (37), using Flat Washer Φ11*Φ20*2(55), and Hex Bolt M10*15(61).
- Page 9 ASSEMBLY INSTRUCTIONS STEP 4 Assemble Diagonal bracing (10) by using Flat Washer Φ11*Φ20*2(55) and Hex Bolt M10*25 (60). Then install the Weight Plate Holder (11) at the sliding frame and the Diagonal bracing (10) by using Flat Washer Φ11*Φ20*2(55), Nut M10 (57), Hex Bolt M10*70 (64) as show.
- Page 10 ASSEMBLY INSTRUCTIONS STEP 5 Assemble Right &Left Handle Bar Frame (13&14) with Sliding Frame (21), using Flat Washer Φ11*Φ20*2 (55), Nut M10 (57), Hex Bolt M10*25 (60), and Hex Bolt M10*75 (66), then tighten all bolts.
- Page 11 ASSEMBLY INSTRUCTIONS STEP 6 Assemble Cross Support Frame (74) with Sliding Frame (21), using Flat Washer Φ11*Φ20*2 (55), Nut M10 (57), Hex Bolt M10*70 (64).
- Page 12 ASSEMBLY INSTRUCTIONS STEP 7 Assemble Waist Pad(27),Back Pad(28),Shoulder Pad(29),Seat Pad(30) and Back Pad(31) as shown, using Flat Washer Φ11*Φ20*2 (55), Hex Bolt M10*25 (60), and Pan Head, Hex Bolt M10*55 (73),then tighten all bolts.
- Page 13 APPENDIX - FULL ASSEMBLY/EXPLODED VIEW/ FULL PARTS LIST...
- Page 14 APPENDIX - FULL PARTS LIST DESCRIPTION DESCRIPTION Rear Base Frame (39) Stopper 30*70*20 Rear Upright Frame End Cap Φ48*2 (40) Middle Base Frame Bushing (41) Right Connecting Frame Knob (42) Left Connecting Frame Base Mat (43) Upper Cross Frame Pin Sleeve (44) Adjustable Frame Pin Shaft Φ12*80*M8...
- Page 15 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 16 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2025 Titan Brands...
