Summary of Contents for Samuel Heath V777-EXT
- Page 1 Product Data Sheet V777-EXT Cistern Lever - Available Control Options - V777-EXT-LF V777-EXT-LK...
- Page 2 Dimension Key V777EXT-LF...
- Page 3 Dimension Key V777EXT-LK...
- Page 4 Spares Information Item Part No. Description Lever Assembly Threaded Tube Assembly Metal Washer Rubber Washer Split Pin...
-
Page 5: Installation
Installation 1. Remove arm (A) by undoing its fixing screw. 2. Remove split pin (B). 3. Remove lever assembly (C). - Page 6 Set Up 4. Push threaded tube assembly (D) through pre-drilled hole in the finish wall and the cistern. 5. Secure in place using nuts and washers provided.
- Page 7 Set Up 6. Push the lever assembly (C) through the threaded tube assembly (D) and secure in place using split pin (B). 7. Reassemble arm (A) and connect to the cistern flushing mechanism.
-
Page 8: Important Notes
5. Ceramic cartridges in hard water areas. To prolong the lifespan and reduce servicing periods of your Samuel Heath tap we recommend that a suitable water softener be fitted. Consult your installer/designer for details.
