- Page 1 Product Data Sheet V277-EXT Extended Cistern Lever - Available Control Options - V277EXT-TC V277EXT-TGBC V277EXT-TM V277EXT-TSB V277EXT-TSC V277EXT-TW...
- Page 2 Dimension Key V277EXT-TC / V277EXT-TGBC / V277EXT-TM / V277EXT-TW V277EXT-TSB / V277EXT-TSC...
- Page 3 Spares Information Item Part No. Description Lever Assembly Threaded Tube Assembly Steel Washer Rubber Washer Split Pin...
-
Page 4: Installation
Installation 1. Remove arm (A) by removing the fixing screw. 2. Remove split pin (B). 3. Remove lever assembly (C). - Page 5 Installation 4. Push threaded tube assembly (D) through pre-drilled hole in the finish wall and the cistern. 5. Secure in place using nuts and washers provided.
- Page 6 Installation 6. Push the lever assembly (C) through the threaded tube assembly (D) and secure in place using split pin (A). 7. Re-assemble arm (B) and connect to the cistern flushing mechanism.
-
Page 8: Important Notes
5. Ceramic cartridges in hard water areas. To prolong the lifespan and reduce servicing periods of your Samuel Heath tap we recommend that a suitable water softener be fitted. Consult your installer/designer for details.
