Summary of Contents for Samuel Heath V722
- Page 1 Product Data Sheet V722 Volume Control - Available Control Options - V722LK V722LF...
- Page 3 Dimension Key V722LK V722LF...
-
Page 4: Flow Rates
Flow Rates The flow rate data provided in this document is indicative of each product and is given in an open outlet condition. Installation design, external connections and fittings not supplied may affect the data provided. - Page 5 Spares Information Item Part No. Description Indice Lever Screw Washer Lever Stem Body Cap Volume Stem VS56041 CD Valve Grub Screw Volume Body Control...
-
Page 6: Installation
(E). 3. Position the volume control body onto chassis ensuring alignment with any other Samuel Heath products. Using the Allen key provided screw the grub screws home to secure the volume control body in position. 4. Slide the escutcheon back down into its original position to obscure grub screws. - Page 7 Control Assembly Instructions 1. Screw handle (A) onto spindle (B) using screw (C) and washer (D). 2. Push indice (E) into the handle option (A) to conceal the fixing. 3. The octagonal nut (F) can be rotated to the desired angle. Note: The taper on the spindle (B) will lock in to the female taper in the handle option (A).
-
Page 8: Important Notes
5. Ceramic cartridges in hard water areas. To prolong the lifespan and reduce servicing periods of your Samuel Heath tap we recommend that a suitable water softener be fitted. Consult your installer/designer for details.
