- Page 1 Product Data Sheet V208 / V208-AUS Small Single Lever Mixer with Pop-Up Waste V210 / V210-AUS Small Single Lever Mixer without Pop-Up Waste - Available Control Options - V2K08C V2K08GB V2K08GBC V2K08GC V2K08M V2K08W...
- Page 2 Dimension Key V2K08C / V2K08GBC / V2K08M / V2K08W V2K08GB / V2K08GC...
- Page 3 Dimension Key V2KA08C / V2KA08GBC / V2KA08M / V2KA08W V2KA08GB / V2KA08GC...
- Page 4 Dimension Key V2K10C / V2K10GBC / V2K10M / V2K10W V2K10GB / V2K10GC...
- Page 5 Dimension Key V2KA10C / V2KA10GBC / V2KA10M / V2KA10W V2KA10GB / V2KA10GC...
- Page 6 Flow Rates The flow rate data provided in this document is indicative of each product and is given in an open outlet condition. Installation design, external connections and fittings not supplied may affect the data provided.
- Page 7 Flow Rates The flow rate data provided in this document is indicative of each product and is given in an open outlet condition. Installation design, external connections and fittings not supplied may affect the data provided.
- Page 8 Spares Information V208 Item Part No. Description Indice Cap Screw Rocker Cover Locking Ring VS56039 Cartridge Flow Changer Body Pop-Up Knob C-Washer Kit Flexi Tails Aerator Pop-Up Waste...
- Page 9 Spares Information V208-AUS Item Part No. Description Indice Cap Screw Rocker Cover Locking Ring VS56039 Cartridge Flow Changer Body Pop-Up Knob C-Washer Kit Flexi Tails Joining Block Aerator Pop-Up Waste...
- Page 10 Spares Information V210 Item Part No. Description Indice Cap Screw Rocker Cover Locking Ring VS56039 Cartridge Body C-Washer Kit Aerator Flexi Tails...
- Page 11 Spares Information V210-AUS Item Part No. Description Indice Cap Screw Special Nut Set Screw Rocker Cover Locking Ring VS56039 Cartridge Body C-Washer Kit Aerator Flexi Tails...
- Page 12 V208-AUS / V210-AUS Waste Set Up 1. Assemble the drain to the basin. 2. Assemble the spout to the deck with the pop-up rod in position as shown above.
- Page 13 V208-AUS / V210-AUS Waste Set Up 3. Assemble the ball rod to the drain. 4. Bend the metal strap to link the pop-up rod as shown above. 5. Secure the metal strap in place using wing nut and retainer clip.
- Page 14 V208-AUS / V210-AUS Waste Set Up 6. Adjust the position of the metal strap to allow the pop-up waste to action correctly.
- Page 15 V208-AUS / V210-AUS Waste Set Up Note: Alternatively, the ball rod and pop-up rod can be joined with the Joining Block (illustrated above).
-
Page 16: Important Notes
5. Ceramic cartridges in hard water areas. To prolong the lifespan and reduce servicing periods of your Samuel Heath tap we recommend that a suitable water softener be fitted. Consult your installer/designer for details.
