F2X03 Series
User Manual
F2X03 Series User Manual
The user manual is suitable for the following model:
Documentation No.
Product Name：
Model
Product Type
F2003
GSM IP MODEM
F2103
GPRS IP MODEM
F2203
CDMA IP MODEM
F2303
EDGE IP MODEM
F2403
WCDMA IP MODEM
F2503
TD-SCDMA IP MODEM
F2603
EVDO IP MODEM
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300326 ，6300325，6300324
Fax:+86 592-5912735
http://www.fourfaith.com
Product Version
Zip Code:361008
Page
Total:
Advertisement
Table of Contents
Related Manuals for Four-Faith F2503
Summary of Contents for Four-Faith F2503
- Page 1 GPRS IP MODEM F2203 CDMA IP MODEM F2303 EDGE IP MODEM F2403 WCDMA IP MODEM F2503 TD-SCDMA IP MODEM F2603 EVDO IP MODEM Xiamen Four-Faith Communication Technology Co., Ltd. Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare Park,XiaMen,China Zip Code:361008 Tel：+86 592-6300326 ，6300325，6300324 Fax:+86 592-5912735 http://www.fourfaith.com...
- Page 2 User Manual Files Revised Record Date Version Remark Author Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 3: Copyright Notice
Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome. - Page 4 User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 5: Table Of Contents
3.5.2 IP MODEM Settings ....................17 3.5.3 Other Settings ......................23 3.6 Functions ........................... 26 3.7 Work State Switch ......................27 Appendix ............................28 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324... -
Page 6: Chapter 1 Brief Introduction Of Product
RS232/RS485/RS422 port: 15KV ESD protection SIM/UIM port: 15KV ESD protection Power port: reverse-voltage and overvoltage protection Antenna port: lightning protection(optional) Standard and Convenience Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... -
Page 7: Working Principle
F2103 GPRS IP MODEM 85.6Kbps GSM850/900： <-107 EGSM900/GSM1800MHz, <33dBm GSM850/900/1800/1900MHz(optional) Compliant to GSM phase 2/2+ GSM1800/1900： GPRS class 10, class 12(optional) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... - Page 8 <-109 UMTS/WCDMA/HSDPA/HSUPA HSUPA:5.76Mbps 850/1900/2100MHz, (Upload speed) 850/900/1900/2100MHz(optional) GSM850/900/1800/1900MHz HSDPA:7.2Mbps GPRS/EDGE CLASS 12 (Download speed) UMTS:384Kbps (DL/UL) F2503 TD-SCDM IP MODEM <24dBm <-108 TD-SCDMA/HSDPA/HSUPA Download speed:2.8Mbps 1880-1920/2010-2025MHz Upload speed:2.2Mbps GSM850/900/1800/1900MHz GPRS/EDGE CLASS 12 F2603 CDMA2000 1X EVDO IP MODEM <23dBm <-104 CDMA2000 1X EVDO Rev A Download speed:3.1Mbps...
- Page 9 Operating -25~+65º C（-13~+149℉） Temperature Extended -30~+75º C（-22~+167℉） Operating Temperature Storage -40~+85º C（-40~+185℉） Temperature Operating 95% ( Non-condensing) Humidity Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 10: Chapter 2 Installation Introduction
RS485 data cable optional Manual CD Certification card Maintenance card 2.3 Installation and Cable Connection : (unit: mm) Dimension Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... -
Page 11: Installation Of Antenna
The signal connection of the RS232 data cable is as follows: DB9F DB9F RXD 2 2 RXD TXD 3 3 TXD GND 5 5GND RS232 data cable Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... -
Page 12: Power
BLINK Data is communicating No data Online IP MODEM has logged on network IP MODEM hasn’t logged on network Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... -
Page 13: Chapter 3 Configuration
The following describes how to configure IP MODEM with the configure software tool. At the same time, it gives out the corresponding AT command of each configuration item. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 14: Run The Configure Tool: Ip Modem Configure.exe
“Port(COM1) Has Opened，Please Re-Power the IP MODEM, Waiting IP MODEM Enter Configure State...” 3.4 Re-power IP MODEM After Re-power IP MODEM, The configure tool will make it enter configure state. At the Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 15: Configuration
IP Address and Port of the Main DSC, It’s better to set the port greater than 1024. AT command of the Main DSC IP address or domain name: AT+IPAD=xxx Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... - Page 16 1~4 correspond to port of center 2~5 xxx: The port value Example: Set IP address of center 3 as 166.111.8.238, and port 5001, the AT command is as following: AT+IPAD2=166.111.8.238 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
-
Page 17: Ip Modem Settings
AT+DNSSVRn=aaa.bbb.ccc.ddd n is 1~4 correspond to center 2~5 DNS server. aaa.bbb.ccc.ddd is the DNS server IP address 3.5.2 IP MODEM Settings ◆ IP MODEM WorkMode Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... - Page 18 SMSD: send a special short message to make IP MODEM online CTRL: make IP MODEM online through a phone call to IP MODEM DATA: send special serial data to make IP MODEM online Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
- Page 19 8O1 --- 8 Databit, Odd parity, 1 Stopbit AT Command: AT+SERMODE=xxx xxx: one of the above serial mode ◆ Communication Baudrate Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
- Page 20 AT Command: AT+RETMAIN=x x : 0 or 1 ◆ Device ID Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
-
Page 21: Sim Card No
This item is only valid when the WorkMode is TCST. It’s the self defined register string. It can be empty, the maximum length is 70 bytes. AT Command: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... - Page 22 “Reconnect Time Interval” AT Command: AT+RDLWT=xxx xxx: the sleep time until next retry. ◆ Transfer meanning Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
-
Page 23: Other Settings
ISP network Call Center: the call center phone number AT Command of APN: AT+APN=xxxx xxxx: access point name Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324... - Page 24 ◆ Call Trigger Phone No This item is only valid when the “Trigger Type” is CTRL or MIXD. In this trigger type, IP Xiamen Four-Faith Communication Technology Co.,Ltd. Page 24 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
- Page 25 : data trigger on password AT Command of data trigger off password: AT+DOFFPSWD=xxx xxx :data trigger off password ◆ TCP MTU Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
-
Page 26: Functions
Show the software and hardware version ◆ Signal Value Display current wireless signal value ◆ Factory setting Restore to factory settings ◆ Show Config Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324... -
Page 27: Work State Switch
This state is used as a common serial communication tool Reboot Device, Enter Communication State: This function button is used to reboot IP MODEM and make the software switch to Communication state Xiamen Four-Faith Communication Technology Co.,Ltd. Page 27 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 28: Appendix
XP Hyper Terminal. 1. Press “Start””Programs””Accessories””Communications””Hyper Terminal” 2. Input connection name, choose “OK” 3. Choose the correct COM port which connect to IP MODEM, choose “OK” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... - Page 29 Data bits: 8 Parity: None Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
- Page 30 Re-power IP MODEM, put mouse focus on the Hyper Terminal and press “s” key continuously until IP MODEM enter configure state as following 7. IP MODEM has entered configure state, you can configure the parameters through AT command. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 30 of 30 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
