F2X14-E IP Modem
User Manual
F2X14-E IP Modem User Manual
The user manual is suitable for the following model：
F2114-E
F2814-E
Document Version
Product Name： F2X14-E
Model
Product Type
GPRS IP MODEM
FDD LTE IP MODEM
Xiamen Four-Faith Smart Power Technology Co.,Ltd.
Hotline ：400-8838 -199
Tel：+86-592-6300320
Fax：+86-592-5912735
Web：https://en.four-faith.net/
Add：11th Floor, A-06 Area, No.370, Chengyi
Street, Jimei, Xiamen, Fujian, China
V2.0.0
Confidential
Total: 34
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Four-Faith F214-E Series
Summary of Contents for Four-Faith F214-E Series
- Page 1 The user manual is suitable for the following model： Model Product Type GPRS IP MODEM F2114-E FDD LTE IP MODEM F2814-E Xiamen Four-Faith Smart Power Technology Co.,Ltd. Hotline ：400-8838 -199 Tel：+86-592-6300320 Fax：+86-592-5912735 Web：https://en.four-faith.net/ Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China...
- Page 2 Add pin level description of LED state 2017/9/23 V2.0.0 Faine output 2020/4/16 V2.0.0 Contents translation and layout Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 2 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735 https://en.four-faith.net/...
- Page 3 Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 F2X14-E Series IP Modem User manual Product appearance Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 4 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735 https://en.four-faith.net/...
-
Page 5: Table Of Contents
3.2.7 “Multi IP data center”..........................22 3.2.8 “Multi connection strategy”........................22 3.2.9 “Other configuration”..........................23 3.2.10 “ Related settings of network management platform”................23 Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 5 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China https://en.four-faith.net/ Hotline：400-8838-199... - Page 6 Charpter 5 Test................................... 30 5.1 DC Test................................. 30 5.1.1 DCUDP mode.............................30 5.1.2 DCTCP mode test............................33 Appendix 1 FAQ................................. 34 Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 6 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China https://en.four-faith.net/ Hotline：400-8838-199 Tel：...
-
Page 7: Chapter1 Introduction Of Product
Support hardware and software WDT Support auto recovery mechanism, including online detect, auto redial when offline to make it always online Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 7 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China https://en.four-faith.net/... -
Page 8: Product Specfication
GSM850/EGSM900: Class 4 (2W) TX power DCS1800/PCS1900: Class 1 (1W) RX sensitivity <-107dBm F2814-E FDD LTE IP MODEM Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 8 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China https://en.four-faith.net/ Hotline：400-8838-199 Tel： 0592-6300320... - Page 9 100mA@3.6V Standby 30mA@5V 55mA@3.6V Physical Characteristics Item Content Installation Embedded Dimension 60x38x12mm weight About 8g Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 9 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China https://en.four-faith.net/ Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735...
- Page 10 F2X14-E Series IP Modem User manual Other parameters Item Content Working -40~+75ºC（-40~+167℉） temperature Storage -40~+85ºC（-40~+185℉） temperature 95%（( unfreezing） relative humidity Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 10 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China https://en.four-faith.net/ Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735...
-
Page 11: Chapter 2 Installation
(Note:The components and their position on the PCB board will change slightly with the version upgrade, please refer to the actual product.) Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 11 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 12: Power Introduction
12V), and ensure that the power supply is greater than 1W. 2.5 Indicator IP MODEM provides four indicators, definition showing as below：Power,Module, Status,SIM Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 12 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel：... -
Page 13: Pin Definition
Signal (power) 13,14 ground SIM card interface， compatible SIM Data SIMDATA with1.8V/3.0V SIM Reset SIMRST Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 13 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735 https://en.four-faith.net/... - Page 14 Serial port 1: Receive VIH>=2.0 data VIL<=0.8 33,34,35,36 Signal (power) ground 37,38,39,40 Power supply POWER DC 3.6~9V Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 14 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735 https://en.four-faith.net/...
-
Page 15: Pin Level Description Of Led Status
The output levels for each state are shown in the following table: Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 15 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... - Page 16 2.Low level output hold for at least 3 seconds; 3. Alternate slowly means 1 times/S； 4.Alternate quickly means 1times/200mS 5.“X”means any level Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 16 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel：...
-
Page 17: Chapter 3 Configuration
： Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 17 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... - Page 18 “overalll control” bar also displays the time of the current device, and it automatically reads the device time once a minute. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 18 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel：...
- Page 19 1 tree menu. All the configuration information is displayed in the information window, where you can view all the configuration information through the drop-down scroll bar. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 19 of 31 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199...
-
Page 20: Configuration Options
Phone Activation：Open or close the phone activation ( In general, select "Open") ,in short connection mode, activate the network if any calls come in. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 20 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 21: Gprs Dial Parameter Setting
Support platform connection mode: Only support UDP; Support platform heartbeat interval (seconds): Heartbeat interval associated with the WMMP protocol only, range: 4~3600 Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 21 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 22: Enterprise Gateway Related Settings
For the polling mode, datas will be sent in sequence according to the number of configuration centers. Once the data is sent successfully, it is no longer sent to the next center. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 22 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 23: Other Configuration
UDP login frame: For the enterprise gateway connection mode is pure UDP. UDP login response frame: For the enterprise gateway connection mode is pure UDP. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 23 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 24: Read/Write Configuration
“Download configuration successfully “ will be displayed in the log contents information bar，a prompt dialog box will pop up at the same time, asks if you Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 24 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China... -
Page 25: Modification Configuration
There is a default configuration when ex-factory, users only need to read the configuration, modify the corresponding parameters, and then write the configuration. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 25 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 26: Chapter 4 Use Description
Timing off-line interval(Minutes): 0 In this connection mode, online in real time, if the line is disconnected, it will dial again Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 26 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 27: Short Connection Mode
Users can see the current working status of the system through the system indicator light, there are definitions that indicator lights of the system when the system is running, showing as below: Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 27 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 28: Remote Upgarde
For example： <123456; RMTUPGRADE=00,0,16,120.42.46.98,9991, F2X64-STANDARD-V1-0-1> Command：STPUPGRADE Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 28 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199 Tel： 0592-6300320 Fax：0592-5912735... -
Page 29: Local Serial Upgrade
When the upgrade is complete, the red box showing as below will be displayed in the interface: 4、Close download tool, restart the device. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 29 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China Hotline：400-8838-199... -
Page 30: Charpter 5 Test
PLC, we use a computer simulate it here. ) to F2X14-E’s port, after it, power up them all. 1、Click “UDP” to enter DCUDP mode: 2、The default listener port is 1203. You can modify it by the menu“Setting”->“Setting Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 30 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Hotline：400-8838-199... - Page 31 We use a computer to connect serial port to simulate it here(You can use super terminal or other terminal software, we use a serial tool here.) Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 31 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Hotline：400-8838-199...
- Page 32 “Send”button, data will be send out by software,showing as below: Data sent by the center to the corresponding device will display in serial port tool, showing as below: Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 32 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Hotline：400-8838-199...
-
Page 33: Dctcp Mode Test
“F2X14D_DC.exe” will work on TCP mode, at this moment, you can start test if you config the device to DCTCO mode. Test steps is similar to UDP mode. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 33 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Hotline：400-8838-199... -
Page 34: Appendix 1 Faq
Solution: Please check serial port cable, ans check serial port of PC is normal or not, the selected port of the software is corrector not. Xiamen Four-Faith Smart Power Technology Co.,Ltd. Page 34 of 34 Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Hotline：400-8838-199...
