MONARCH INSTRUMENT Track-It Data Logger Quick Start Manual

1
Install USB Driver and Track-It™ Software
IMPORTANT! Do NOT plug the Track-It™ Data Logger
into the USB port until AFTER the USB Driver and Track-It
Software have been installed.
Download Track-It DataLogger Software from:
https://monarchinstrument.com/Files/Software/Track-It_
Software.zip
Unzip the downloaded file to a local directory on your PC.
Double click CD_Start.exe. This will launch the Track-It Data
Logger's splash screen (right).
1. Click Install USB Driver and
follow the prompts. Accept any
security messages to continue
installation.
2. Click Install Software and follow
the instructions to complete the
installation. The software is now
installed and ready to use.
3. Logger and software manuals may also be accessed here
Note: If you have trouble downloading or installing, refer to
our guide, How To Install Track-It™ Driver and
2
Install Data Logger Battery (if necessary)
Most models have the battery preinstalled. For the Rugged Temp
Logger, install the battery that was supplied with your Track-It Data
Logger. Refer to the diagram below for installation.
Remove threaded end cap with coin or screwdriver and insert battery
.
To replace the battery in any Track-It Data Logger, refer to the
Software.
product's Instruction Manual.
as shown.
end goes in first
Rugged Temp
3.6V 1/2AA Lithium
High Temperature
3
Connect Data Logger and Track-It™ Software
Plug the Track-It Logger into an available USB port on the PC.
Some models plug directly into the USB port; others connect to
the USB port with a cable (supplied). If the Found New Hardware
Wizard appears, follow the prompts to complete the installation.
Start the Track-It DataLogger Software by double clicking
the Track-It icon (shown at right) on your PC or from the
Start menu.
