- Page 1 Online Support If you require assistance or your Spirit Unit, please contact customerservice@dyaco.ca FUNCTIONAL CSF-FUNT SP-3526 FUNCTIONAL TRAINER TRAINER OWNER'S MANUAL 16812595260...
-
Page 3: Table Of Contents
Table of Contents Product Registration ............3 Warning / Safety Instructions Product Labels ..............4 Safety Instructions .............5 Facility Safety ..............6 Precautions ................7 Safety Guidelines ............... 8 Assembly Parts of Your Unit ............10 Assembly ................11 Maintenance Maintenance & Care ............17 Exploded View Diagram ..........18 Warranty Warranty ................19... -
Page 4: Product Registration
Congratulations on your new unit, and welcome to the Spirit Fitness family! Thank you for your purchase of this quality unit from Spirit Fitness. Your new unit was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most WARRANTY REGISTRATION comprehensive warranties available. -
Page 5: Product Labels
If any instructions or information are not clear, and please contact to SPIRIT FITNESS customer service right away. PRODUCT LABELS NOTE: STICKERS AND LABELS ARE NOT SHOWN TO SCALE The following pages show examples of warning labels and Warning Decal... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS Read the Owner’s Manual carefully before assembling, servicing or 16. DO NOT use dumbbells or other incremental weights, except those using the equipment. It is the responsibility of the facility owner and/ provided by the manufacturer . or owner of the equipment to instruct users on proper operation of the 17. -
Page 7: Facility Safety
FACILITY SAFETY PRECAUTIONS WARNING! ƒ Read the Owner’s Manual carefully before assembling, servicing or using the equipment. ƒ Make sure that each unit is set up and operated on a solid level surface. ƒ Make sure that all users are properly trained on how to use the equipment. -
Page 8: Precautions
PRECAUTIONS These safety notes are directed to you as the owner of the WARNING Strength Equipment manufactured by Dyaco Canada Inc. Please train all your users and fitness staff to follow these • Your Strength Equipment manufactured by Dyaco Canada safety instructions. -
Page 9: Safety Guidelines
This chapter includes precautions and fitness safeguards for the installation and use of the • Inappropriate or improper use may result in injury to users or third parties (bystanders). manufactured by SPIRIT FITNESS.. • Do not use machine if it is not located on a solid level surface or is improperly installed. -
Page 10: Assembly And Setup
ASSEMBLY & SETUP Use the following procedures to unpack and assemble your CAUTION: Damage to the Strength Equipment during assembly Strength Equipment manufactured by Dyaco Canada Inc. is not covered as part of the limited Dyaco Canada Inc. warranty. Take care not to drop or lean the Strength Equipment on its side. Unpacking &Parts Carefully stand the Strength Equipment up in the normal upright 1. -
Page 11: Parts Of Your Unit
PARTS OF YOUR UNIT Workout Diagrams Pulley Height Adjustment Handle Guide Rods Shroud Shroud Accessories... -
Page 12: Assembly
Link Span Socket Cap Screw M10*25 Flat Washer φ20*φ10.5*2 ASSEMBLY - STEP ONE Assembly Instructions STEP 1 Spring Washer Description Spec Left Doorframe Right Doorframe Link Span Socket Cap Screw M10*25 Flat Washer φ20*φ10.5*2 Spring Washer... - Page 13 Right Doorframe Upper Beam Bracket ASSEMBLY - STEP TWO Assembly Instructions STEP 2 Socket Cap Screw M10*25 Flat Washer φ20*φ10.5*2 Description Spec Spring Washer Left Doorframe Right Doorframe Upper Beam Bracket Socket Cap Screw M10*25 Flat Washer φ20*φ10.5*2 Spring Washer...
- Page 14 Big Washer φ24*φ8.4*2 Spring Washer ASSEMBLY - STEP THREE Assembly Instructions STEP 3 Description Spec Left Doorframe Right Doorframe Roller Hanger Guide Rod φ20*1726 Guide Rod Fixing Plate 10LB Weight Stack 10LB Counter Weight Stack Set 17 Holes Shaft Select Pin Rod End Cover Rubber Bumper φ62*φ20*26...
- Page 15 s Recessed Pan Head Tapping Screw ST4.2*16 Big Washer φ15*φ5.3*1.2 Front Shield ASSEMBLY - STEP FOUR Assembly Instructions STEP 4 Description Spec Cross Recessed Pan Head Tapping Screw ST4.2*16 Big Washer φ15*φ5.3*1.2 Front Shield 6 6 6 6 5 5 6 6 5 5 2 2 6 6 6 6 5 5 6 6...
- Page 16 Description Spec Short Handle Set Knee Cover Set Pull Back Rope Set ASSEMBLY - STEP FIVE Assembly Instructions STEP 5 Handle Grips Squat Handle Set Description Spec Short Handle Set Knee Cover Set Pull Back Rope Set Handle Grips Squat Handle Set 9 9 9 9 9 9 9 9...
-
Page 17: Start Workout
START WORKOUT... -
Page 18: Maintenance
MAINTENANCE A regular preventative maintenance schedule with all fitness equipment ensures that products are working at an optimal condition without affecting the end user exercise experience. To assist in the maintenance regiment, it is recommended to break service into: Daily, Weekly, & Monthly activities. Reference the table below on the preventative maintenance activities to be performed. All preventive maintenance activities must be performed on a regular basis. -
Page 19: Exploded View Diagram
EXPLODED VIEW DIAGRAM... -
Page 20: Warranty
WARRANTY - COMMERCIAL Functional Trainer LIMITED WARRANTY Dyaco Canada Inc. warrants the unit for a period of time listed below from the date of installation, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations. - Page 21 WARRANTY - CONTINUED EXCLUSIONS This warranty does not cover the following: 1. CONSEQUENTIAL, COLLATERAL, OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY. NOTE: Some provinces do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.
- Page 22 WARRANTY - CONTINUED SERVICE Twelve (12) months from the date of installation or eighteen (18) months from the date of factory shipping as determined by the serial number establishes the labour warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
- Page 24 5955 Don Murie, Niagara Falls, ON L2G 0A9 | Phone: 888-707-1880 | Fax: 905-353-8968 www.spiritfitness.ca ©2023 All Rights Reserved. CSF-FUNT Owner’s Manual...
