CHEST PRESS /

SHOULDER PRESS

Online Support

If you require assistance or

are experiencing issues with

your Spirit Unit, please contact

customer care for additional help.

1-800-258-8511

questions@spiritfitness.com

Warranty Registration

Scan to quickly and easily

Fitness unit.

Table of Contents

Need help?

Do you have a question about the CSD-CPSP and is the answer not in the manual?

Questions and answers

Summary of Contents for Spirit CSD-CPSP

Page 1 Online Support If you require assistance or are experiencing issues with your Spirit Unit, please contact customer care for additional help. 1-800-258-8511 questions@spiritfitness.com Warranty Registration Scan to quickly and easily register your new Spirit Fitness unit. CHEST PRESS / CSD-CPSP...
Page 3: Table Of Contents
Table of Contents Product Registration ............3 Warning / Safety Instructions Product Labels ..............4 Safety Instructions .............5 Facility Safety ..............6 Precautions ................7 Safety Guidelines ............... 8 Safeguards ................9 Assembly Parts of Your Unit ............. 11 Assembly ................12 Cable Routing Diagram ...........
Page 4: Product Registration
Congratulations on your new unit, and welcome to the Spirit Fitness WARRANTY REGISTRATION family! Thank you for your purchase of this quality unit from Spirit Fitness. Your new unit was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
Page 5: Product Labels
NOTE: STICKERS AND LABELS ARE NOT SHOWN TO SCALE The following pages show examples of Spirit® Fitness warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers miss- ing or damaged contact your local dealer or distributor for a replacement.
Page 6: Safety Instructions
SAFETY INSTRUCTIONS Read the Owner’s Manual carefully before assembling, servicing or 16. DO NOT use dumbbells or other incremental weights, except those using the equipment. It is the responsibility of the facility owner and/ provided by the manufacturer . or owner of the equipment to instruct users on proper operation of the 17.
Page 7: Facility Safety
If unable to immediately replace worn or damaged components then remove from service until the repair is made. ƒ Use only Spirit Fitness supplied components to maintain/ repair the equipment. ƒ Keep a repair log of all maintenance activities. ƒ Inspect all cables and belts and connections prior to use.
Page 8: Precautions
PRECAUTIONS WARNING These safety notes are directed to you as the owner of the Strength Equipment manufactured by Spirit Fitness. Please train all your users and fitness staff to follow these safety • Your Strength Equipment manufactured by Spirit Fitness instructions.
Page 9: Safety Guidelines
SAFETY GUIDELINES AND PRACTICE Spirit Fitness recommends that all fitness equipment be used in a supervised area. It is recommended that the equipment be located in an access controlled area. Control is the responsibility of the owner. The extent of control is at the discretion of the owner.
Page 10: Safeguards
APPROVED FOR USE WITH THE SPIRIT FITNESS • DO NOT use any equipment in any way other than designed EQUIPMENT WHICH APPEARS TO BE DAMAGED OR or intended by the manufacturer. It is imperative that SPIRIT WORN. FITNESS equipment is used properly to avoid injury. •...
Page 11: Assembly
CAUTION: Damage to the Strength Equipment during assembly is not covered as part of the limited Spirit Fitness warranty. Take care not to drop or lean the Strength Equipment on its side. Carefully stand the Strength Equipment up in the normal upright position on a stable surface so it will not tip over during assembly.
Page 12: Parts Of Your Unit
PARTS OF YOUR UNIT Counterweight Accessory Tray 5lb Increment Weight Workout Diagrams Head Pad Rep & Time Counter Shroud Back Pad Guide Rods Press Handles Press Arm Adjustment Pin Weight Selector Pin Seat Pad Gas Cylinder Weight Stack Foot Brace Seat Height Adjustment Pin Adjusting Plate...
Page 13: Assembly
ASSEMBLY STEP 1 Assembly Instructions Step Description Specifications Door Frame Inner Hexagon Socket Head Bolt M10*35 Spring washer Flat washer Φ20*Φ10.5*2 Connect frame...
Page 14 ASSEMBLY - CONTINUED STEP 2 Assembly Instructions Step Description Specifications Main frame Rear ground frame Front ground fame Socket cap screw M10*25 Socket cap screw M10*80 Spring washer Flat washer Φ20*Φ10.5*2...
Page 15 Countersunk head hexagon socket screws M8*20 ASSEMBLY - CONTINUED Assembly Instructions STEP 3 Step Description Specifications Main frame Rotating frame Conect rod Short shaft Step rolling bearing Sink hole gaskets Circlip for shaft d0=25 Countersunk head hexagon socket screws M8*20...
Page 16 Countersunk head hexagon socket screws M8*20 Socket cap screw M10*95 Spring washer ASSEMBLY - CONTINUED STEP 4 Assembly Instructions Step Description Specifications Left arm frame Right arm frame Counter weight Long shaft Sink hole gaskets Plastic pad Circlip for shaft d0=25 Deep groove ball bearing 6305-2Z...
Page 17 Cushion frame ASSEMBLY - CONTINUED STEP 5 Assembly Instructions Step Description Specifications Support frame Adjusting plate Gas spring cylinder Rotating shaft Connect sleeve Socket cap screw M10*25 Socket cap screw M10*130 Spring washer Flat washer Φ20*Φ10.5*2 Extra big washer Φ34*Φ11*3 Cushion frame...
Page 18 ASSEMBLY - CONTINUED STEP 6 Assembly Instructions Step Description Specifications Small rotate shaft Socket cap screw M10*25 Spring washer Extra big washer Φ34*Φ11*3 Seat pad frame...
Page 19 ASSEMBLY - CONTINUED STEP 7 Assembly Instructions Step Description Specifications Socket cap screw M8*70 Spring washer Flat washer Φ16*Φ8.4*1.6 Back cushion set Seat cushion set Head pad set Socket cap screw M8*75...
Page 20 ASSEMBLY - CONTINUED 10LB top weight plate 10LB weight plate 15LB weight plate...
Page 21 Fixed bushing Front shield Back shield cross recessed countersunk head screw M5*10 ASSEMBLY - CONTINUED Countersunk head hexagon socket screw M6*16 STEP 9 Assembly Instructions Inner Hexagon Socket Head Bolt M6*16 Spring washer Step Description Specifications Flat washer Φ12*Φ6.4*1.6 Upper shield Shield fixed plate Fixed bushing Front shield...
Page 22: Cable Routing Diagram
Cable Routing Diagram CABLE ROUTING DIAGRAM Cable Routing Diagram Correct Wrong Cable Cable limiting post limiting post Correct Wrong Cable Cable limiting post limiting post...
Page 23 CABLE ROUTING DIAGRAM t p i Dry Reed Pipe Connection Wire...
Page 24 START WORKOUT...
Page 25 REPETITION AND TIME COUNTER A battery-operated (batteries not included) console is available for use on your equipment. The console tracks workout time and number of repetitions per set. REPS TIME RESET RESET Repetition Counter Time Counter This counter is powered by 2 pcs of AA batteries. (Alkaline Battery Recommended)
Page 26: Maintenance
All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all SPIRIT equipment. SPIRIT is not responsible for performing regular inspection and maintenance actions for your machines. Instruct all personnel in equipment inspection and maintenance actions and also in accident reporting and recording.
Page 27: Exploded View Diagram
EXPLODED VIEW DIAGRAM...
Page 28 EXPLODED VIEW DIAGRAM...
Page 29: Warranty
Effective September 13, 2023- CSD-CHEST PRESS / SHOULDER PRESS LIMITED WARRANTY Spirit Fitness warrants the unit for a period of time listed below from the date of installation, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Spirit Fitness’ responsibilities include providing new or remanufactured parts, at Spirit Fitness’...
Page 30 5. Products that have been: sold, transferred, bartered, or given to a third party. 6. Products that do not have a warranty registration on file at Spirit Fitness. Spirit Fitness reserves the right to request proof of purchase if no warranty record exists for the product.
Page 31 3. If there is a question as to where to obtain service, contact our service department at (870) 935-1107. 4. Spirit Fitness’ obligation under this warranty is limited to repairing or replacing, at Spirit Fitness’ option, the product through one of our authorized service centers.
Page 32: Troubleshooting
TROUBLESHOOTING Service Checklist Diagnosis Guide Problem Solution/ Cause Rep Counter & Timer does not turn on when Replace batteries. ƒ Check the magnet is still in position and the reed switch is still positioned next to the weight is lifted ƒ...
