CSC88O
Model# 16807448800
STAIR CLIMBER
Online Support
If you require assistance or you
are experiencing issues with your
Spirit unit, please contact
customer care for additional help.
1-888-707-1880
customerservice@dyaco.ca

Advertisement

loading
Need help?

Need help?

Do you have a question about the CSC880 and is the answer not in the manual?

Questions and answers

Summary of Contents for Spirit CSC880

  • Page 1 Online Support If you require assistance or you are experiencing issues with your Spirit unit, please contact customer care for additional help. 1-888-707-1880 customerservice@dyaco.ca CSC88O STAIR CLIMBER Model# 16807448800...
  • Page 3 Table of Contents Product Registration ..........2 Machine Care ............Warning/ Safety Instructions Troubleshooting ............32 Product Labels ............... 3 Exploded View ............34 Warnings, Compliance, and Notes ......Parts List ..............37 Safety Instructions ............5 Warranty Electrical Safety ............. 6 Warranty ...............
  • Page 4 PRODUCT REGISTRATION Congratulations on your new Stair Climber, and welcome to the Spirit WARRANTY REGISTRATION Fitness family! Thank you for your purchase of this quality unit from Dyaco Canada Inc. Your new unit was manufactured by one of the leading fitness...
  • Page 5 PRODUCT LABELS SERIAL NUMBER STICKER This sticker will be found on the frame. Please record the number below the barcode for the purpose of registering your Stair Climber's warranty. xxxxxxxxxxxxxxxx SAFETY WARNING STICKER This sticker will be found on your Stair Climber's upright.
  • Page 6 WARNINGS, COMPLIANCE AND NOTICES NOTE: This equipment has been tested and found to This product has been certified to meet the following comply with the limits for a Class B digital device, standards: pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against •...
  • Page 7 SAFETY INSTRUCTIONS When using an electrical stair climber, basic precautions 6. This stair climber is not intended for use by persons should always be followed, including the following: with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have Read all instructions before using this stair climber.
  • Page 8 ELECTRICAL SAFETY Keep power cord away from heated surfaces. Unplug power cord ■ WARNING! when the machine is unattended and before performing any This equipment is designed for use in a commercial ■ preventative maintenance such as cleaning or replacing a worn gymnasium or health club.
  • Page 9 ELECTRICAL SAFETY & IMPORTANT OPERATION INSTRUCTIONS IMPORTANT OPERATION INSTRUCTIONS The safety and integrity of this machine can only be ■ maintained when the equipment is regularly examined NEVER operate this StairClimber without reading and completely ■ for damage and wear and repaired. It is the sole understanding the results of any operational change you request responsibility of the owner of this equipment to ensure from the computer console.
  • Page 10 PARTS INCLUDED HARDWARE PACK PARTS INCLUDED: □ 1 Frame Assembly □ 2 Hexagon socket countersunk head screws □ 1 Front Column Assembly □ 1 Front Column Assembly Welding □ 1 Column Decorative Rubber □ 1 Left Handrail Assembly □ 1 Right Handrail Assembly □...
  • Page 11 PARTS OF YOUR STAIR CLIMBER A. Console B. Pulse Sensors C. Accessory Pocket D. Safety Key E. Handlebars F. Console Mast G. Main Frame H. Steps Step Up J. Leveler K. Safety-Stop Sensor...
  • Page 12 PRE-ASSEMBLY 1. Read all instructions before assembling. 2. Assemble and operate the StairClimber on a hard, level surface in the area intended for use. 3. Attach all fasteners and partially tighten them. Do not fully tighten fasteners until assemble of all components is complete.
  • Page 13 ASSEMBLY – STEP ONE 1. Put the Column Decorative Rubber over the front column assembly, as shown. 2. Connect the connecting wires of the front column Column assembly to the frame assembly in pairs making Decorative sure not to pinch the wires. Rubber Front column assembly 3.
  • Page 14 ASSEMBLY – STEP TWO 1. Insert the left and right front handrail Right front handrail assembly assemblies into the positions shown. Left front handrail The hole The hole on the on the 2. Remove the two bolts from the positions shown. left side right side is for the...
  • Page 15 ASSEMBLY – STEP THREE Insert the left and right handrail to the positions shown in the picture and bolt it in place. bolts M8x25-2pcs ⦶ 8 arc Hexagon socket flat round head bolts M8x25-2pcs ⦶ 8 arc Hexagon socket flat round head Left Right Handrail...
  • Page 16 ASSEMBLY – STEP FOUR 1. Connect the connecting wire of console to the connecting wire of main body, as shown in the picture. 2. Install the console to the position as shown Cross recessed pan head tapping screws ST4.8x10 in the picture, fixed with the bolts. Console assembly 3.
  • Page 17 QUICK START • Press the Start/Stop button. All data starts counting. Display intensity can be adjusted by pressing the +/- buttons. The data can be switched. • Press the Start/Stop button, to clear all the data, display remind "Any Key To Continue or Press OK to Quit". Power Input Location There are Safety-Stop Sensors on each panel of the stair climber.
  • Page 18 FEATURES Entering a Program & Changing Settings A safety tether cord is provided with this unit. It is a simple switch An adjustable vent, two-speed fan is integrated into the design that should always be used. It is for your safety should you console to help keep you cool during the workout.
  • Page 19 FEATURES Console The console display is separated into 4 separate display windows with twelve total data points. Using the button below each window changes the display data point as shown. WINDOW ONE WINDOW TWO WINDOW THREE WINDOW FOUR VERTICAL DISTANCE CALORIES TIME ELAPSED STEPS PER MINUTES...
  • Page 20 FEATURES Basic Information The Dot Matrix, or Profile Window, will display the workout Profile. The Message window displays pertinent exercise data. There are four windows to display a large variety of pertinent data during the workout. A Vertical window measures vertical height climbed along with Heart Rate and METS.
  • Page 21 CONSOLE SCREEN - OVERVIEW Premium, ultra-bright White LED display Large LED Matrix window to track workout progress Program Direct Keys Resistance Workout Results level display window...
  • Page 22 FEATURES Programming the Console Each of the programs can be customized with your personal information and changed to suit your needs. Some of the information asked for is necessary to ensure the readouts are correct. You will be asked for your Age and Weight. Your Age is also necessary during the Heart Rate control program to ensure the correct settings are in the program for your Age.
  • Page 23 PRESET PROGRAMS FAT BURNING The FAT BURNING Program keeps the user as at low to moderate intensity for a prolonged workout. The focus is on aerobic endurance. 1. Press the FAT BURNING button. 2. Console displays: Start Or Press OK To Set Up. Press OK. 3.
  • Page 24 PRESET PROGRAMS TRAINING The TRAINING Program allows the user to gradually ramp-up their intensity until reaching a level for steady state exercise. The focus is on aerobic endurance. 1. Press the TRAINING button. 2. Console displays: Start Or Press OK To Set Up. Press OK. 3.
  • Page 25 PRESET PROGRAMS ROLLING HILLS The ROLLING HILLS Program a traditional program giving the user segments of medium and medium-high intervals. This program trains aerobic capacity. 1. Press the ROLLING HILLS button. 2. Console displays: Start Or Press OK To Set Up. Press OK. 3.
  • Page 26 PRESET PROGRAMS CHALLENGE The CHALLENGE Program gives the user a prolonged gradual warm-up, followed by sustained training at a higher intensity. This program introduces anaerobic training within an aerobic workout. 1. Press the CHALLENGE button. 2. Console displays: Start Or Press OK To Set Up. Press OK. 3.
  • Page 27 PRESET PROGRAMS INTERVAL The INTERVAL Program alternates high intensity anaerobic sprints with low intensity segments for recovery. This program trains anaerobic capacity. 1. Press the INTERVAL button. 2. Console displays: Start Or Press OK To Set Up. Press OK. 3. Enter Your Age displays on the screen. The default age of 35 will blink repeatedly. Use the Level + or - keys or the numerical Keypad to adjust age.
  • Page 28 PRESET PROGRAMS TARGET TRAINING The TARGET TRAINING Program allows the user to choose their own workout goal: Time, Vertical Distance, or Calories. The Program counts down from the time goal or tracks up for both vertical distance or calories. 1. Press the TARGET button. 2.
  • Page 29 PAUSING OR ENDING A PROGRAM 1. The console has a START/STOP button with a PAUSE feature. Once the StairClimber has started rotating the staircase, the PAUSE function can be activated. 2. Pressing the START/STOP button once will slow and PAUSE the staircase from rotating and lock it in place.
  • Page 30 HEART RATE EXERTION The two most popular reasons for, or goals, of exercise are The old motto, "no pain, no gain", is a myth that has cardiovascular fitness (training for the heart and lungs) and been overpowered by the benefits of exercising weight control.
  • Page 31 HEART RATE – PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in Rating Perception of Effort how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate all contribute to the intensity at which you should...
  • Page 32 MACHINE CARE Post-Workout Machine Care Wipe down all areas in the sweat path with a damp cloth after each Post-Workout Machine Care workout. If a squeak, thump, clicking or rough feeling develops the main cause is most likely the following reason: Unupholstered high-contact surfaces (hard plastics) can ■...
  • Page 33 MACHINE CARE – CONTINUED - SCHEDULE UNPLUG STEPPER BEFORE PERFORMING ANY MAINTENANCE. Item Daily Weekly Monthly Quarterly Biannually Entire Unit Clean Inspect Detailed Cleaning Clean Unit Hardware Inspect Console Hardware Inspect Steps Clean Inspect Console Overlay Clean Inspect Accessory Cups Clean Stop Switch Clean...
  • Page 34 TROUBLESHOOTING PROBLEM REASON METHOD 1. Check whether the light sensor line is off or damaged Press “START” at the start, the machine speed is 2. Check whether the distance between the light sensor and the abnormal, 3 seconds after the stop, display data Light sensor failure.
  • Page 35 TROUBLESHOOTING - CONTINUED PROBLEM REASON METHOD Bad membrane key or damaged wire Key Failure Membrane key failure Replace membrane keys Contact a trained technician Use a multimeter to check the following: 1. Power adapter failure 1. Measure whether the adapter is 24V output 2.
  • Page 36 EXPLODED VIEW...
  • Page 37 EXPLODED VIEW...
  • Page 38 EXPLODED VIEW...
  • Page 39 PARTS LIST ITEM # DESCRIPTION SPECIFICATION Q'TY Frame assembly Upper sprocket set welding Lower sprocket set welding Middle shell support tube assembly welding Left decorative pipe group welding Right decorative pipe group welding Pulley assembly 1.7.1 Belt pulley fixing shaft Φ30x607.6 1.7.2 Pk190 belt pulley...
  • Page 40 PARTS LIST ITEM # DESCRIPTION SPECIFICATION Q'TY 1.10.8 Φ14 shaft elastic retaining ring Φ14 1.10.9 Hexagon socket head bolts M6X16 1.10.10 Hexagon socket head bolts M5X35 1.10.11 Hexagon socket head bolts M5X12 1.10.12 Cross recessed large flat round screws M4×8 1.10.13 Flat washer Φ6.5×Φ12×1.2 1.10.14 Flat washer...
  • Page 41 PARTS LIST ITEM # DESCRIPTION SPECIFICATION Q'TY 1.20 182 large chain sections Section 08A -182 Section 08A-106 1.21 Auxiliary Chain No Snap 1.22 67-tooth auxiliary sprocket 08A-67-tooth 1.23 Step Pedal 239.4x458.6x23 1.24 Connection Arc Plate 204.2x454.1x83.2 1.25 upper decorative shell 150.7x150.7x40.6 1.26 Middle Decorative Shell...
  • Page 42 PARTS LIST ITEM # DESCRIPTION SPECIFICATION Q'TY 2.2.1 2.2.2 113.4×155.3×33.7 2.2.3 113.4×155.3×33.7 2.2.4 2.2.5 ST4.2×16 2.3.1 120.1×43×22.8 2.3.2 120×21.3×43 2.3.3 Φ43×26.9 2.3.4 Φ43×40.3 2.3.5 13.9×8.2×5.6 2.3.6 R15.3×28.1×7.1 2.3.7 M5X10 2.3.8 M4×25 2.3.9 Hexagon socket cheese head screws M3×5 2.3.10 Hexagon socket cheese head screws M3×10 2.3.11 ST2.2x6...
  • Page 43 PARTS LIST ITEM # DESCRIPTION SPECIFICATION Q'TY Outer Φ38×3×2060 Outer Φ38×3×2060 Spraying 510×344×59, ABS black 510×344×49, ABS black 377×254×36, ABS black Black 416×334×54, ABS black 62×54×35, ABS black 62×52×37, ABS black 70×27×17, ABS black 7.10 Black 7.11 288×27×27, ABS black 7.12 186×197×17.8, ABS black 1 ST4.8×10 black zinc...
  • Page 44 WARRANTY CSC880 Stair Climber LIMITED WARRANTY Dyaco Canada Inc. warrants all its home use Stair Climber parts for a period of time listed below from the date of retail sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Dyaco Canada’s responsibilities include providing new or remanufactured parts, at Dyaco Canada’s option, and technical support to our...
  • Page 45 3. Damages caused by services performed by persons other than authorized Dyaco Canada service companies; use of parts other than original Spirit Fitness parts; or external causes such as corrosion, discoloration of paint or plastic, alterations, modifications, abuse, misuse, accident, improper maintenance, inadequate power supply, or acts of God.
  • Page 46 This written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under this warranty must be obtained by following these steps, in order: 1. Contact your selling authorized Spirit Fitness dealer. OR 2. Contact your local authorized Spirit Fitness service organization.
  • Page 47 5955 Don Murie Street, Niagara Falls, ON L2G 0A9 Phone: 1-888-707-1880 Fax: 905-353-8968...
