Dreamline INFINITY-Z Installation Instructions Manual

Shower door, base and backwalls

Hide thumbs Also See for INFINITY-Z:

Installation instruction (14 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

HOWER

PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION

IMPORTANT!

DreamLine

reserves the right to alter, modify or redesign products at any time without prior notice for the

purpose of product improvement and customer experience. Please refer to the model's web page on

DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional

product details.

STEP 1:

Shower Base Installation Instructions

STEP 2:

Shower Backwalls Installation Instructions

STEP 3:

Shower Door Installation Instructions

Do Not Return Product to the Store. Contact DreamLine® with any questions

Please contact DreamLine Customer Support

See DreamLine.com for hours of operation

INFINITY-Z SHOWER DOOR_BASE_QWALL-VS Installation Manual Ver1 062025

INFINITY-Z

, B

OOR

ASE AND

ACKWALLS

NSTALLATION

NSTRUCTIONS

1-866-731-2244

Table of Contents

Need help?

Do you have a question about the INFINITY-Z and is the answer not in the manual?

Questions and answers

Summary of Contents for Dreamline INFINITY-Z

Page 1 ® purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details. STEP 1:...
Page 2 Low Profile Acrylic Shower Base Low Profile Acrylic Shower Base hower hower imenSionS anD imenSionS anD nStallation nStallation nStructionS nStructionS PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION Single Threshold Left, Center, Right drain (Certain models do not have all 3 drain locations) Neo Angle Quarter Round Double Threshold Left, Corner, Right drain...
Page 3 Record the following purchase information for your records or in the event you need to contact the manufacturer: Purchase Order Store/Vendor Number __________________________ Purchased From __________________________ Installation Date __________________________ OD Number __________________________ (Optional) *found on shipping box/label Installed by __________________________ SKU Number __________________________ Low Profile Acrylic Shower Base Installation Manual Ver1 Rev3 062025...
Page 4 Table of Contents Section Title Page # Warnings and General Preparation Tools and Materials Model Specific Preparation Model Types and Dimensions Guides 6-13 Detailed Cross Section Diagram Installation Steps 15-23 Product Maintenance Average Installation Time 1 hr CORRECT - TIP - for ease of installation. recommended.
Page 5 Warning Disclosure Statement WARNING DISCLOSURE STATEMENT IMPORTANT GENERAL PREPARATION • • The manufacturer reserves the right to alter, modify or redesign products any time After opening all boxes and packages, read this introduction carefully. Check that all the without prior notice for product improvement and customer experience. items are included in the package by marking off the components on the “Detailed •...
Page 6 Tools Tape Measure Pencil Caulk Gun 2 FT Ø3/16" (4mm) 4 FT Levels Power Drill Screw Gun Materials OPTION # 1 OPTION # 2 Drain Assembly Mortar Mix Acrylic-Safe Wood Shims 1-1/4” Stainless Steel (option # 1) Adhesive (Various Sizes) Corrosion-Resistant Truss Head #8 Screws NOTE: Some shower base...
Page 7 Shower Bases for Alcove Installation (Single Threshold) When installing an alcove shower base, consider how the total thickness of the wall treatment (wallboard tile, acrylic walls, etc.) will affect the finished opening size for a shower door. Always order a shower door based on the finished opening dimensions after the finished wall treatment has been installed.
Page 8 Shower Bases for Corner Installation (Double Threshold, Neo Angle, Quarter Round) When installing a shower base designed for corner installation, consider how the total thickness of the wall treatment (wallboard tile, acrylic walls, etc.) will affect where the shower enclosure will sit on the threshold. Always order a shower enclosure based on the finished opening dimensions after the finished wall treatment has been installed.
Page 9: Specification
SINGLE THRESHOLD SHOWER BASE Center Drain Configuration SPECIFICATION D (in) W (in) D1 (in) W1 (in) 32" x 32" 32" 32" 15" 16" 36" x 36" 36" 36" 15" 18" 32” x 42” 32" 42" 15" 21" 34” x 42” 34"...
Page 10 SINGLE THRESHOLD SHOWER BASE Left-Hand Drain Configuration SPECIFICATION D (in) W (in) D1 (in) W1 (in) 30" x 60" 30" 60" 15" 12" 32" x 60" 32" 60" 15" 12" 34" x 60" 34" 60" 17" 12" 36" x 60" 36"...
Page 11 SINGLE THRESHOLD SHOWER BASE Right-Hand Drain Configuration SPECIFICATION D (in) W (in) D1 (in) W1(in) 30" × 60" 30" 60" 15": 12" 32" × 60" 32" 60" 15" 12" 34" × 60" 34" 60" 17" 12" 36" × 60" 36" 60"...
Page 12 NEO ANGLE SHOWER BASE SPECIFICATION W (in) A (in) B (in) C (in) 36" x 36" 36" 18 5/16" 25" 12" 38" x 38" 38" 20 5/16" 25" 12" 40" x 40" 40" 22 5/16" 25" 14 3/8" 42" x 42" 42"...
Page 13 QUARTER ROUND SHOWER BASE SPECIFICATION W (in) C (in) R (in) 33" x 33" 33" 12" 21 5/8" 36" x 36" 36" 12" 21 5/8" 38" x 38" 38" 12" 21 5/8" Low Profile Acrylic Shower Base Installation Manual Ver1 Rev3 062025...
Page 14 DOUBLE THRESHOLD SHOWER BASE Corner Drain Configuration SPECIFICATION W (in) C (in) 32" x 32" 32" 12" 36" x 36" 36" 12" 42" x 42" 42" 12" Low Profile Acrylic Shower Base Installation Manual Ver1 Rev3 062025...
Page 15 DOUBLE THRESHOLD SHOWER BASE Left-Hand Drain Configuration SPECIFICATION D (in) W (in) D1 (in) W1(in) 32" x 60" 32" 60" 15" 12" 36" x 60" 36" 60" 18" 12" 36" x 54" 36" 54" 18" 12" 32" x 48" 32" 48"...
Page 16 DOUBLE THRESHOLD SHOWER BASE Right-Hand Drain Configuration SPECIFICATION D (in) W (in) D1 (in) W1(in) 32" x 60" 32" 60" 15" 12" 36" x 60" 36" 60" 18" 12" 36" x 54" 36" 54" 18" 12" 32" x 48" 32" 48"...
Page 17 Shower Base Cross Section Diagram Cement board Finished Wall Shower Base Mortar or (2"×4") Stud Adhesive Drain 2” PVC waste pipe This product should be installed by someone familiar with the construction requirements for this type of project and the care necessary for the safe installation and operation of the product.
Page 18: Corner Installation
Corner Installation • Ensure that the floor and the studs are at right angles. • Provide a 5” x 5” opening in the sub- floor for the drain. • The 2” PVC waste pipe should extend above the surface of the sub-floor according to the drain installation instructions and the height of the shower base.
Page 19 This shower base is designed to accept a standard 2” shower drain. NOTE Please carefully read and follow all the installation instructions and requirements that come with the drain assembly you use for this shower base installation. Install the shower drain according to the drain installation manual (supplied with the drain), then place the shower base into the designated position so that it butts up against the studs and...
Page 20 Level the base in two directions (left-to-right, and front-to-back). Once the base is perfectly level, place marks on the studs above the upper edge of the tile flanges. NOTE: For proper drainage, the shower base must be installed level on all sides. * Neo Angle Shower Base shown as an example Fig 3...
Page 21: Installation Option
INSTALLATION OPTION # 1 INSTALL SHOWER BASE IN A BED OF MORTAR (Recommended Installation Method) A sand-mix, topping/bedding mortar type is recommended for NOTE installation of this shower base. Do Not use concrete or plaster. Carefully read the mixing directions on the bag of mortar.
Page 22 INSTALLATION OPTION # 2 INSTALL SHOWER BASE WITH SCREWS AND ADHESIVE The shower base must be installed on a level sub-floor. If installation option # 2 is selected and the sub-floor is not level, self-leveling compound can be used to level the sub-floor prior to installation.
Page 23 (CONTINUED) The adhesive used for this step must be an acrylic-safe adhesive. Please carefully read the packaging of the adhesive to be sure it specifies it is safe for use on acrylic and ABS plastic Apply several tubes of acrylic-safe construction adhesive to the sub-floor making sure to thoroughly cover the area where the base will be installed.
Page 24 (CONTINUED) Install the shower base back into the opening and firmly press it down into the adhesive making sure the tile flanges are butted up to the studs and making sure the shower base is level on all sides. IMPORTANT! Make sure the shower base remains level the entire time as you perform the next step.
Page 25: Side View
(CONTINUED) There may be some parts of the tile flanges where there is a slight rim that creates some dead space between the stud and the base. Use small wooden shims between the flanges and the stud in any area where this small void is apparent.
Page 26 If you used installation option # 1, allow the mortar to completely cure and harden NOTE before applying weight to the bottom of the shower base. Install the cement board (or wallboard) above the tile flanges and secure it to the studs Put the tiles (or other finishing wall material) over the cement board leaving a 1/8”...
Page 27 24 Hours Hours * Neo Angle Shower Base shown as an example Low Profile Acrylic Shower Base Installation Manual Ver1 Rev3 062025...
Page 28: Product Maintenance
Product Maintenance ACRYLIC BASES and BACK WALLS: To ensure long-lasting life for your acrylic base and/or back walls, wipe them off after each use with a soft cloth. To clean the acrylic base and/ or back walls, use only non-abrasive sprays or cream-based cleaners.
Page 29 Low Profile Acrylic Shower Base Low Profile Acrylic Shower Base Prior to contacting the manufacturer, please have the following information readily available: - Purchase Order information ◾ Name, PO Number, Dealer/Vendor Name, etc. - SKU/Model Number - Factory Part Information IMPORTANT! The manufacturer reserves the right to alter, modify, or redesign products at any time without prior notice for the purpose of product improvement and customer experience.
Page 30 ® purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details. Do Not Return Product to the Store. Contact DreamLine® with any questions...
Page 31: Table Of Contents
NOTE feature; additional information. not recommended. REQUIRED - requires special attention; signifies a warning. Record the following purchase information for your records or in the event you need to contact DreamLine ® Purchase Order Store/Vendor Number Purchased From OD Number...
Page 32 IMPORTANT GENERAL PREPARATION • DreamLine® reserves the right to alter, modify or redesign products any time without • After opening all boxes and packages, read this introduction carefully. Check that all the prior notice for product improvement and customer experience. Please refer to the items are included in the package by marking off the components on the “Detailed...
Page 33 2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine™ is not responsible for code compliance standards for your project and will not accept any returns on this basis.
Page 34 Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement. The shipping boxes may contain extra parts not used in ®...
Page 35: Side Panels 4 J-Strips Screws Anchors
2 back panels 2 back panels 3 side panels 2 side panels 2 side panels 2 side panels 4 J-Strips 3 J-Strips 4 J-Strips 4 J-Strips Screws Screws Screws Screws anchors anchors anchors anchors © 2019 DreamLine® All Rights Reserved...
Page 36: Back Panels
J-Strip Installation J-Strip (x4) Installation for J-Strip an alcove configuration Back Panel(s) Screw and Anchor Side Panel J-Strip (Installed w/Silicone) Screw and Anchor J-Strip (x3) Installation for a Corner Shower The J-Strip secures the J-Strip (Installed w/Silicone) overlapping panel J-Strip (Installed w/Silicone) Side Panel Side Panel...
Page 37: Strips
Q-Wall Parts List 01 Q-Wall Back Panel 2 pcs 02 Q-Wall Side Panel 2 pcs 03 J-Strips 4 pcs 04 5/16” Wall Anchors 20 pcs ST 4.2 x 30 Countersunk Screws 20 pcs © 2019 DreamLine® All Rights Reserved...
Page 38: Strips
Q-Wall Parts List 2 pcs 01 Q-Wall Back Panel 02 Q-Wall Side Panel 2 pcs 03 J-Strips 4 pcs 04 5/16” Wall Anchors 20 pcs ST 4.2 x 30 Countersunk Screws 20 pcs © 2019 DreamLine® All Rights Reserved...
Page 39 See “Installation of other configurations” on page 24 Q-Wall Parts List 02 Q-Wall Side Panel 3 pcs 03 J-Strips 4 pcs 04 Ø 5/16” Wall Anchors 20 pcs 20 pcs ST 4.2 x 30 Countersunk Screws © 2019 DreamLine® All Rights Reserved...
Page 40 See “Installation of other configurations” on page 24 Q-Wall Parts List 2 pcs 02 Q-Wall Side Panel 03 J-Strips 3 pcs 04 5/16” Wall Anchors 20 pcs 20 pcs ST 4.2 x 30mm Countersunk Screws © 2019 DreamLine® All Rights Reserved...
Page 41: Parts List
Parts List ST4.2 x 30mm Wall Anchor Countersunk Screw 8mm (5/16in) All Q-Wall Panels have a thin layer of protective plastic on the NOTE primary surface. Leave the protective plastic on when marking and cutting the Q-Wall Panels. Remove the protective plastic when instructed during the installation.
Page 42: Installation Steps
Installation Steps Remove the Q-Wall panels from the box(es) and identify the Q-Wall Side Panels and Q-Wall Back Panels. The Q-Wall Back Panels are different: The Overlap Panel is 33” wide; the Underlap Panel is 32-1/2“ wide. The Q-Wall Side Panels are 41-1/2” wide. The grout lines are recessed on the primary surface of the Q-Wall panels.
Page 43 NOTE protective plastic. Leave this protective plastic on when marking and cutting the Q-Wall Back Panels Tools Needed to prevent damage to the primary surface. Remove the protective plastic sheet as instructed during installation. © 2019 DreamLine® All Rights Reserved...
Page 44 5. Use a straight edge and a fresh blade to score along the finished cut line several times to get a clean break. The Q-Wall Back Panel will snap at the scored line. Fig 5 Tools Needed Fig 5 © 2019 DreamLine® All Rights Reserved...
Page 45 The primary surface of each Q-Wall Back Panel is covered with protective plastic. Leave this protective plastic on when marking and cutting the NOTE Q-Wall Back Panels to prevent damage to the primary surface. Remove the protective plastic sheet as instructed during installation. Tools Needed © 2019 DreamLine® All Rights Reserved...
Page 46 Q-Wall Back Panel, especially at the corners and the edges. Remove the protective plastic from the left side Q-Wall Back Panel once installed. Fig 8 Fig 7 8. Dry fit the 2nd Q-wall Back Panel and make any adjustments necessary. Fig 8 Fig 8 Tools Needed © 2019 DreamLine® All Rights Reserved...
Page 47 Remove the protective plastic covering from the 2nd Q-Wall Back Panel once installed. Fig 10 NOTE Do not apply adhesive to the overlap on the 2nd Q-wall Back Panel Tools Needed overlapping Fig 10 section © 2019 DreamLine® All Rights Reserved...
Page 48 Wipe away any excess silicone with a clean rag. Use an Ø 1/8” bit to drill into the wall through the holes in the J-Strips. Secure the J-Strips with the ST 4.2 x 30 Countersunk Screws (#05). Be sure the screw heads are flush with the surface of the J-Strips. Fig 12 Tools Needed Fig 12 © 2019 DreamLine® All Rights Reserved...
Page 49 Attempting to align the horizontal grout lines may produce NOTE undesired results to your installation. Try ipping the side panels around to produce a more desirable staggering of the horizontal grout lines. Corner Alignment examples: Tools Needed Fig 14 © 2019 DreamLine® All Rights Reserved...
Page 50 • from the tub deck or shower threshold up to the center of the fixture holes (D, E, F). back corner of wall Measure the fixture locations on the wall Fig 15 Tools Needed Right Q-Wall Side Panel with typical fixture locations shown as an example. © 2019 DreamLine® All Rights Reserved...
Page 51 J-Strips in the back corners. Press firmly over the entire surface, paying special attention to the edges and corners. Remove the rest of the protective plastic film. Fig 17 Tools Needed Fig 17 © 2019 DreamLine® All Rights Reserved...
Page 53 Panels overlap, both sides of the J-Strips; on the outside edges of the Q-Wall Side Panels and along the exposed top edges if desired. Fig 18 Allow 24 hours for the silicone to cure before using the shower. Hours Tools Needed Fig 18 © 2019 DreamLine® All Rights Reserved...
Page 54: Other Configurations
Other Configurations The techniques to install the Q-Wall Back Panels, Q-Wall Side Panels and J-Strips are the same for all con gurations. The di erence is in the amount and types of Q-Wall Panels and J-Strips and the installation order. The Small Shower Height and the corner con gurations do not have overlapping Q-Wall Back Panels.
Page 55 NOTE and/or damage. Contact DreamLine with any questions or concerns. ® Prior to contacting DreamLine® Customer Service, please have the following information readily available: - Purchase Order Information - Name, PO Number, Dealer/Vendor Name, etc. - SKU/Model Number (see cover Page)
Page 56: Factory Parts Information
00 = White 22 = Biscuit 88 = Black bold digit within part # 01-White 02/04-Biscuit 02/08-Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2019 DreamLine® All Rights Reserved...
Page 57 00 = White 22 = Biscuit 88 = Black bold digit within part # 01-White 02/04-Biscuit 02/08-Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2019 DreamLine® All Rights Reserved...
Page 58 00 = White 22 = Biscuit 88 = Black bold digit within part # 01-White 02/04-Biscuit 02/08-Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2019 DreamLine® All Rights Reserved...
Page 59 # Q-Wall side panels 00 = White 01-White 22 = Biscuit 02/04-Biscuit 88 = Black 02/08-Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2019 DreamLine® All Rights Reserved...
Page 62 LIDING HOWER AND IXED ANEL NSTALLATION NSTRUCTIONS PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION Available in: This door is reversible. 01 - Chrome 04 - Brushed Nickel Installation instructions are the 06 - Oil Rubbed Bronze same for Tub or Shower height. 09 - Matte Black IMPORTANT! The manufacturer reserves the right to alter, modify or redesign products at any time without prior notice for the...
Page 63: Purchase Order Number
NOTES Record the following purchase information for your records or in the event you need to contact the manufacturer. Purchase Order Store/Vendor Number Purchased From OD Number Installation Date (optional) *found on the shipping box or label if available. SKU Number Installed By: ©...
Page 64 Table of Contents Section Title Page # General Preparations and Warnings Model Specific Preparation Adjustable Wall Profile System Tools Detailed Diagram of Shower Door Components Parts List Installation Steps 9-24 Top and Bottom Roller Assembly Installation Decorative Cover with Washer Installation Handle and Vinyl(s) Installation Product Maintenance Troubleshooting...
Page 65: Important Product Information
Important Product Information WARNING DISCLOSURE STATEMENT IMPORTANT GENERAL PREPARATION • • The manufacturer reserves the right to alter, modify or redesign products any time without After opening all boxes and packages, read this introduction carefully. Check that all the prior notice for product improvement and customer experience. Please refer to the items are included in the package by marking o the components on the “Detailed Diagram of Product Components”...
Page 66: Model Specific Preparation
Model Specific Preparation REQUIRED: 1” minimum threshold 1” Out-of-Plumb Adjustment; Verify threshold and walls ±0.0 ±0.0 with a level 1” Threshold must be minimum level flat threshold ±0.0 DO NOT attach the handle and/or towel bar to the glass until instructed to do so. DO NOT attempt to use the handle/towel bar to lift the glass during installation.
Page 67: Adjustable Wall Profile System
Adjustable Wall Profile System Wall Profile Glass Profile The Glass Profiles can be adjusted up to 1” within the Wall Profiles for overall width or to correct for out-of-plumb conditions within the model size. Screw them together after making final adjustments.
Page 68: Tools
Tools Tape Phillips Silicone Hacksaw Level Pencil Measure Screwdriver Drill Bit Drill Bit Drill Bit Extender Screw Gun Power Ø5/16" Ø3/16" Ø1/8" Mitre Saw Drill Driver Bit or Impact Driver (8mm) (4mm) (3mm) w/ #2 Phillips bit Professional-grade Soft Head Safety Glasses Work Gloves Metal File...
Page 69 Detailed Diagram of Components inside inside inside inside inside SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 70: Parts List
Parts List Guide Rail (Top and Bottom) Inline Panel Glass Door Glass Anti-water Strips Push-in Glazing ST4.0×55mm 1 Short, 2 Long Vinyl Pan Head Screw ST4.0x25mm ST4.0x10mm ST4.2x16mm Pan Head screw Pan head screw Flat Head Screw SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 71 Parts List Decorative Cover (with washer) Wall Anchor Wheel Assembly Wheel Assembly Glass Clip (Top) (Bottom) Towel Bar SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 72: Installation Steps
Installation Steps *at model height ________” Middle ________” Bottom ________” Fig 1 Use the smallest measurement from Fig 1 to determine the finished cut length of the Guide Rails (#03). The Top and Bottom Guide Rails (#03) are shorter than the model size by design.
Page 73 Finished MODEL SIZE Cut-off Length (C) Opening *from Table A *from Door End only Width (W) Hole for Centerline Glass Clip of rail Panel Side Door Side Cut the Top and Bottom Guide Rails (#03) from the Door End only, (which is the end farthest from the Glass Clip hole) and cut Distance from the Glass Table B...
Page 74 Reinstalling the Door-side Bumper 3-1/8” Drill through to the center of the hole top layer only Ø1/8” Fig 3 It’s necessary to reposition the door-side stoppers in both the Top Door Top Rail and Bottom Rails once the door end of the rails have been cut. Parts Needed Tools Needed Bottom Rail...
Page 75: Assembling The Frame
Assembling the Frame Fig 4 For ease of installation: Add liquid soap, wax, or lubricant to the screws prior to attaching the Glass Profiles (#01) to the Guide Rails (#03). Use a low setting on a bottom screw gun to prevent stripping the screws, or use a Phillips screwdriver as shown.
Page 76 Adding the Wall Profiles Fig 5 Holes in both inside profiles inside must line up Parts Needed The holes in the Wall Profiles (#02) are off-center, and must line up with the corresponding holes in the Glass Profiles (#01). SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 77 Positioning the Frame in the Opening Decide on the handing of the door and panel prior to placing the assembly into the opening to mark the holes for drilling. Position the frame assembly so that the Inline Panel Glass (#06) as well as the Door Glass (#04) will be installed on the NOTE desired side of the opening.
Page 78: Drill Bit
Drilling for Frame Installation Ø3/16” Drill Bit *see NOTE Fig 7 If a stud is present behind the wall, drill a hole using a Ø3/16” drill bit and pilot the stud using a Ø1/8” bit. Do not use wall anchors. Parts Needed If no stud is present, drill the hole using a Tools Needed...
Page 79 Installing the Roller Wheels on the Door Glass inside inside Fig 8 NOTE *Left-hand door installation shown The lock nut on the Top Roller Assembly (#17a) and the push-button on the Bottom Roller Assembly (#17b) should both be installed pointing up. DO NOT overtighten the Parts Needed Roller Assemblies (#17a/17b).
Page 80 Placing the Door Glass in the Opening Before securing the frame assembly, bring the Door Glass (#04) into the tub area and lean it safely against the wall, using padding to protect the glass, walls, and tub surface. Make sure the handle holes on the Door Glass (#04) are on the correct side for installation.
Page 81 Installing the Frame in the Opening wall profiles bottom rail ST4.0×55 ST4.0×55 wall wall Overhead View Fig 10 The screwheads on the ST4.0×55 Pan Head Screws (#09) will pass through the larger NOTE holes in the Glass Profiles (#01) and then secure the Wall Profiles (#02) to each wall.
Page 82 Installing the Inline Panel Glass & Towel Bar inside inside Fig 11a Use caution when installing the Inline Panel Glass (#05) into the frame to prevent damage to the edges of the glass. outside Fig 11b Parts Needed Tools Needed SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 83 Installing the Push-In Glazing Vinyl inside NOTE Fig 12 A right-hand panel installation is shown as an example. The door is reversible. Parts Needed To prevent scratching or damaging the glass and aluminum, DO NOT use a screwdriver or other metal tool to install the Push-in Glazing Vinyl (#08).
Page 84 Installing the Door Glass align and install bottom lift up inside adjust if needed align and install Fig 13 If necessary: Adjust the Top Roller NOTE Assemblies (#17a) for smoother operation. Tools Needed Be sure to center the frame within NOTE the Wall Profiles before the next step.
Page 85 Connecting the Profiles DO NOT drill the profiles throughout, ONLY through the first layer of the Wall Profile (#02) and Glass Profile (#01). 3/4” Ø1/8” inside inside inside inside Fig 14 Make sure the frame is centered within the Wall Pfiles, and that the Bottom Rail is NOTE tight to the tub deck before screwing the Wall Profiles and Glass Profiles together.
Page 86: Handle And Vinyl(S) Installation
Handle and Vinyl Installation inside door glass Inline Panel Glass Shorter Vinyl Seal Handle Installation door glass outside Fig 15 The two longer Vertical Vinyl Seals (#07) attach to both edges of the Door Glass (#04) with the soft fins facing the outside of the shower. NOTE The shorter Vertical Vinyl Seal (#07) attaches to the edge of the Inline Panel Glass (#05) in the middle of the shower with the soft fin facing inside the shower.
Page 87 Applying Silicone NOTE The surfaces need to be clean and free of debris before applying silicone. Tools Needed Fig 16 Allow 24 hours for the silicone caulk to cure before using the shower. SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 88: Product Maintenance
Product Maintenance BASES and BACKWALLS: To ensure long lasting life for your acrylic back walls: wipe them off after each use with a soft cloth. To clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Avoid the use of aerosol spray cleaners. Never use abrasive cleansers, metal brushes or scrapers that could permanently scratch or dull the surface.
Page 89: Troubleshooting
Troubleshooting Problem/Symptom Suggested Solution • Check all shipping/packaging material for missing parts/components. Missing Parts • If not found, contact the manufacturer to order factory part replacement. • Make certain that the Bottom Rail (#03) is tight to the threshold and that the silicone is creating a seal along the entire Water leakage underneath Bottom length of the Bottom Rail.
Page 90 Factory Parts Information SLIDING TUB DOOR WITH FIXED PANEL (58X60) - FACTORY PARTS INFORMATION ITEM FACTORY PART NUMBER ITEM DESCRIPTION 04002011-1474 / 04002041-1474 / 04002061-1474 / 04002091-1474 Left or Right Glass Profile for 6mm (1/4in) Glass 2 pcs 04183011-1474 / 04183041-1474 / 04183061-1474 / 04183091-1474 Left or Right Wall Profile 2 pcs 04001011-1437 / 04004011-1437 / 04006011-1437 / 04009011-1437...
Page 91 Factory Parts Information SLIDING SHOWER DOOR WITH FIXED PANEL (48X72) - FACTORY PARTS INFORMATION ITEM FACTORY PART NUMBER ITEM DESCRIPTION 04002011-1830 / 04002041-1830 / 04002061-1830 / 04002091-1830 Left or Right Glass Profile for 6mm (1/4in) Glass 2 pcs 04183011-1830 / 04183041-1830 / 04183061-1830 / 04183091-1830 Left or Right Wall Profile 2 pcs 04001011-1134 / 04004011-1134 / 04006011-1134 / 04009011-1134...
Page 92 Factory Parts Information SLIDING SHOWER DOOR WITH FIXED PANEL (54X72) - FACTORY PARTS INFORMATION ITEM FACTORY PART NUMBER ITEM DESCRIPTION 04002011-1830 / 04002041-1830 / 04002061-1830 / 04002091-1830 Left or Right Glass Profile for 6mm (1/4in) Glass 2 pcs 04183011-1830 / 04183041-1830 / 04183061-1830 / 04183091-1830 Left or Right Wall Profile 2 pcs 04001011-1283 / 04004011-1283 / 04006011-1283 / 04009011-1283...
Page 93 Factory Parts Information SLIDING SHOWER DOOR WITH FIXED PANEL (60X72) - FACTORY PARTS INFORMATION ITEM FACTORY PART NUMBER ITEM DESCRIPTION 04002011-1830 / 04002041-1830 / 04002061-1830 / 04002091-1830 Left or Right Glass Profile for 6mm (1/4in) Glass 2 pcs 04183011-1830 / 04183041-1830 / 04183061-1830 / 04183091-1830 Left or Right Wall Profile 2 pcs 04001011-1437 / 04004011-1437 / 04006011-1437 / 04009011-1437...
Page 94 NOTES SLIDING SHOWER AND TUB DOOR WITH FIXED PANEL Installation Manual Ver3 EF022 WL 062025...
Page 95 LIDING HOWER AND IXED ANEL NSTALLATION NSTRUCTIONS IMPORTANT! The manufacturer reserves the right to alter, modify or redesign products at any time without prior notice for the purpose of product improvement and customer experience. Please refer to the manufacturer’s web page for the latest technical drawings, installation manuals, warranty information or additional product details.
