Dreamline SAPPHIRE-V ACVH48W760XXX01 Installation Instructions Manual

Shower and tub door

Advertisement

S
HOWER AND
PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION
ACVH48W760XXX01
ACVH54W760XXX01
ACVH60W760XXX01
ACVH60W620XXX01
Glass BGlass Box GLVH48W760VXXC-
ACVH48W760XXX04
CGLVH48W760VXXGGGLVH54W760VXXC-
ACVH54W760XXX04
CGLVH54W760VXXGG-
ACVH60W760XXX04
GLVH60W760VXXCCGLVH60W760VXXGGGLVH60W620V
ACVH60W620XXX04
XXCCGLVH60W620VXXGGox GLVH48W760VXXC-
ACVH48W760XXX05
CGLVH48W760VXXGGGLVH54W760VXXC-
ACVH54W760XXX05
IMPORTANT!
IMPORTANT!
DreamLine
DreamLine
reserves the right to alter, modify or redesign products at any time without prior notice for the
reserves the right to alter, modify or redesign products at any time without prior notice for the
®
®
purpose of product improvement and customer experience. Please refer to the model's web page on
purpose of product improvement and customer experience. Please refer to the model's web page on
DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional
DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional
product details.
product details.
Do Not Return Product to the Store. Contact DreamLine® with any questions
Do Not Return Product to the Store. Contact DreamLine® with any questions
Please contact DreamLine Customer Support
See DreamLine.com for hours of operation
SAPPHIRE-V Shower and Tub Door Manual Ver 1 Rev 1 05/2022
SAPPHIRE-V
T
D
UB
OOR
MODEL #s:
ACVH60W760XXX05
ACVH60W620XXX05
ACVH48W760XXX06
ACVH54W760XXX06
ACVH60W760XXX06
ACVH60W620XXX06
ACVH48W760XXX09
ACVH54W760XXX09
ACVH60W760XXX09
ACVH60W620XXX09
I
NSTALLATION
GLASS BOXES:
GLVH48W760VXXCC
GLVH48W760VXXGG
GLVH54W760VXXCC
GLVH54W760VXXGG
GLVH60W760VXXCC
GLVH60W760VXXGG
GLVH60W620VXXCC
GLVH60W620VXXGG
1-866-731-2244
©2022 DreamLine® All Rights Reserved
I
NSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAPPHIRE-V ACVH48W760XXX01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dreamline SAPPHIRE-V ACVH48W760XXX01

  • Page 1 Please refer to the model’s web page on purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details.
  • Page 2 For best results, squeegee the glass after each use and dry with a soft cloth. Record the following purchase information for your records or in the event you need to contact DreamLine ® Purchase Order...
  • Page 3: Table Of Contents

    Table of Contents Section Title Page # ® ClearMax Coating Information — Warnings and General Preparation Model Specific Preparation Tools Detailed Diagram of Shower/Tub Door Components Parts List Installation Steps 8-26 Roller Wheel Adjustment Product Maintenance Symbol Legend CORRECT - Average Installation Time TIP - for ease of installation.
  • Page 4 • • DreamLine® reserves the right to alter, modify or redesign products any time without DreamLine® reserves the right to alter, modify or redesign products any time without After opening all boxes and packages, read this introduction carefully. Check that all the After opening all boxes and packages, read this introduction carefully.
  • Page 5: Model Specific Preparation

    Model Specific Preparation 2-3/4”(70 mm) REQUIRED: minimum threshold 1/4” (6.35mm) Out-of-Plumb 2-3/4”(70 mm) Adjustment on the minimum Vertical Profile Only; ±0.0 ±0.0 threshold Verify threshold and walls with a level Threshold must be level !! ±0.0 ±0.0 Threshold must be level DO NOT attach the handle or towel bar to Tile the glass until instructed to do so.
  • Page 6: Tools

    Diagram on page 7; and packing list in this manual as a reference. Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any NOTE parts are damaged or missing, please contact DreamLine for replacement. The shipping ®...
  • Page 7: Detailed Diagram Of Shower/Tub Door Components

    Detailed Diagram of Shower Door Components © 2022 DreamLine® All Rights Reserved...
  • Page 8: Parts List

    Parts List SAPPHIRE-V Shower and Tub Door Manual Ver 1 Rev1 05/2022...
  • Page 9 Parts List SAPPHIRE-V Shower and Tub Door Manual Ver 1 Rev1 05/2022...
  • Page 10: Installation Steps

    Confirm the walls are within 1/4” of plumb before proceeding with the installation. Also, the threshold must be level and pitched slightly inward for proper installation. ________” ________” (W 2) Tools Needed Fig 1 © 2022 DreamLine® All Rights Reserved...
  • Page 11 NOTE ◻ Cut the Upper Guide Rail (#01) to: “W1”(top) dimension - 9/16” (Fig 2a) Tools Needed ◻ Cut the Bottom Rail (#08) to: “W2” (bottom) dimension - 1/16” (Fig 2b) © 2022 DreamLine® All Rights Reserved...
  • Page 12 Bumpers and Center Guide Block ™ NOTE Measure to locate the center of the Bottom Guide Rail (#08) and place the Center Guide Block (#10) on the mark. Parts Needed Fig 3 Tools Needed © 2022 DreamLine® All Rights Reserved...
  • Page 13 Bumpers and Center Guide Block ™ Parts Needed NOTE Bottom Guide Rail must be parallel to and even with the outside edge of the threshold Fig 4 across the span. Tools Needed Fig 4 © 2022 DreamLine® All Rights Reserved...
  • Page 14 Installing the Bottom Guide Rail and SafeClose Bumpers ™ Bottom of Bumper Parts Needed Fig 5 Tools Needed © 2022 DreamLine® All Rights Reserved...
  • Page 15 Pan Head Screw(#16) NOTE ◾For installation into a Tile Threshold: drill a Ø3/16”(4mm) hole to the stud, drill an Ø1/8”(3mm) pilot hole into the stud and use the ST4.2 x 20mm Pan Head Screw (#16). © 2022 DreamLine® All Rights Reserved...
  • Page 16 Installing the Wall Profiles and Bumpers Parts Needed Fig 7 Repeat steps for the NOTE other side of the shower © 2022 DreamLine® All Rights Reserved...
  • Page 17 Plumb and Mark the Wall Profiles for Drilling Parts Needed Fig 8 Tools Needed © 2022 DreamLine® All Rights Reserved...
  • Page 18 ST4.2 x 40mm Countersunk Screws (#17) ◾If no stud is present behind the wall: drill a Ø5/16”(7mm) hole and insert Tools Needed the Wall Anchors (#18) and use the ST4.2 x 40mm Countersunk Screws (#17). © 2022 DreamLine® All Rights Reserved...
  • Page 19 Installing The Wall Profiles and the Guide Rail Brackets Parts Needed * Optional Tools Needed © 2022 DreamLine® All Rights Reserved...
  • Page 20 Installing the Vinyl Seals on the Bottom Guide Rail Dry t both vinyls, then remove the NOTE coverings on the VHB Tape. Press rmly. Inside of Shower Parts Needed Fig 11 © 2022 DreamLine® All Rights Reserved...
  • Page 21 A right-hand door Fig 12 strike side of installation is shown as NOTE the Inside an example. To reverse Door Glass. the installation, simply Tools Needed flip the glass around. Left-hand door installation © 2022 DreamLine® All Rights Reserved...
  • Page 22 Installing the Top Guide Rail and Caps Slots in the Top Guide Rail must face up. Parts Needed The Top Guide Rail must be level. Fig 13 Tools Needed © 2022 DreamLine® All Rights Reserved...
  • Page 23 Hanging the Inside Door OUTSIDE DOOR INSIDE DOOR ROLLER GUARD 1/16” Parts Needed Tools Needed Fig 14 Drawing Not to Scale © 2022 DreamLine® All Rights Reserved...
  • Page 24 Hanging the Outside Door Fig 15 NOTE Parts Needed Adjust the Roller Guards (#03) to within 1/16” beneath the Upper Guide Rail (#01). Tools Needed © 2022 DreamLine® All Rights Reserved...
  • Page 25: Roller Wheel Adjustment

    ◾ Re-adjust and fully tighten the Roller Guards (#03) to within 1/16” of the Upper Guide Rail (#01) small allen wrench (Fig 16) small hole disk wheel disk Parts Needed Tools Needed Fig 16 © 2022 DreamLine® All Rights Reserved...
  • Page 26 Installing the Towel Bar and the Handle Do Not use Towel bars or Handles as Grab Bars Parts Needed Tools Needed Fig 17 © 2022 DreamLine® All Rights Reserved...
  • Page 27 Clean all surfaces before applying silicone. Apply a good quality mildew-resistant silicone NOTE along the bottom rail and wall profiles where they meet the walls and threshold. Allow the silicone to cure for 24 hours before using the shower. Fig 18 © 2022 DreamLine® All Rights Reserved...
  • Page 28: Product Maintenance

    ◻ Inspect the Roller guards - positioned within 1/16” beneath the guide rail and tight ◻ Inspect the Towel Bars -tighten if loose ◻ Inspect the edges of the door glass for concealed damage. Damaged glass must be replaced! ◻ Inspect vinyl seals- replace if damaged or missing © 2022 DreamLine® All Rights Reserved...
  • Page 29 BOLD ("X") indicates finish: 1 = Chrome 4 =Brushed Nickel 5=Brushed Gold 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. ©2022 DreamLine® All Rights Reserved...
  • Page 30 1921X719X8 European Gray,2-sided ClearMax BOLD ("X") indicates finish: 1 = Chrome 4 =Brushed Nickel 5=Brushed Gold 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com.
  • Page 31 1921X795X8 European Gray,2-sided ClearMax BOLD ("X") indicates finish: 1 = Chrome 4 =Brushed Nickel 5=Brushed Gold 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com.
  • Page 32 1566X775X8 European Gray,2-sided ClearMax BOLD ("X") indicates finish: 1 = Chrome 4 =Brushed Nickel 5=Brushed Gold 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com.
  • Page 33: Tip

    Pages •Check all shipping/packaging material for missing parts/components. Missing Parts •If not found, contact DreamLine Customer Support [1-866-731-2244] to order factory part replacement. •Check that both doors enter the SafeClose™ Bumpers and meet the Bulb Vinyl Inserts in the Wall Profiles.
  • Page 34 NOTES SAPPHIRE-V Shower and Tub Door Manual Ver 1 Rev1 05/2022...
  • Page 35 NOTES SAPPHIRE-V Shower and Tub Door Manual Ver 1 Rev1 05/2022...
  • Page 36 TEL: 866-731-2244 FAX: 866-857-3638 DREAMLINE.COM For more information on DreamLine Shower Doors and Enclosures please visit DreamLine.com ® ©2022 DreamLine® All Rights Reserved...
