ILLUSION
S
D
I
I
HOWER
OOR
NSTALLATION
NSTRUCTIONS
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time without
TM
prior notice. For the latest up-to-date technical drawings, manuals or any other details
please refer to the
support.bathauthority.com
web page.
Please carefully read the instructions before installing. If you have any questions regarding
installation, please call our technical support specialists Monday through Friday 9:00 AM –
5:00 PM EST at 1-866-731-8378, ext. 3 or e-mail our technical support group
support@BathAuthority.com.
at
TM
For more information on
DreamLine
Shower Doors
please visit
www.BathAuthority.com
Rev. 1.1
1
Advertisement
Related Manuals for Dreamline ILLUSION
Summary of Contents for Dreamline ILLUSION
- Page 1 ILLUSION HOWER NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.bathauthority.com web page. Please carefully read the instructions before installing. If you have any questions regarding installation, please call our technical support specialists Monday through Friday 9:00 AM –...
-
Page 2: Tools Required
DreamLine will not replace any damaged products or missing parts free of charge after 3 business days or if the product has been installed. Feel free to contact DreamLine if you have any questions. 2. Please note that you should consult your local building codes with questions on installation compliance standards. - Page 3 Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
- Page 4 Shower Door Assembling 1. Connect the Upper guide rail (04) to the Glass profile 1 (06) using the Round head screw ST4.2×30 (17). Slide the Roller assembly 2 (11) into the groove of the Upper guide rail and connect the Glass profile 2 (07) to the Upper guide rail.
- Page 5 2. Push the Stationary glass (01) into the groove of the left Glass profile 1 (06) along the guide rails. Secure the Stationary glass with the Glass clamps (19) screwed into the upper and bottom guide rail using Flat head screw ST4.2×16 (16).
- Page 6 3. Secure the Roller assembly 1 (09) to the top of the Glass door 1 (02) with the Glass bolts (20) using the Hex wrench (24). See Fig. 5 for details. 4. Suspend the Glass door 1 (02) with the installed Roller assembly 1 (09) into the Upper guide rail (04).
- Page 7 5. Slide the Bottom guide 1 (10) into the Bottom guide rail (08). Fasten the Bottom guide 1 to the Glass door 1 (02) using the Glass bolts (20). Tighten using Hex wrench (24). NOTE: Pay attention to directions of the glass bolts.
- Page 8 6. Place the Glass door 2 (03) near the Roller assembly 2 (11) and fasten them with the Glass bolts (20) using the Hex wrench (24). Slide the Bottom guide 2 (12) into the Bottom guide rail (08). Secure the Glass door 2 (03) to the Bottom guide 2 and fasten it with the Glass bolts (20) using the Hex wrench.
- Page 9 Shower Door Installation The shower door has to be installed against a finished floor and finished walls. See Fig. 11 for details. . 11 7. Press the Wall profiles (05) on the Glass profile 1 (06) and Glass profile 2 (07). Make sure the flange of the wall profile faces inside the shower.
- Page 10 . 13 8. Move the finished Shower door assembly into the shower base or threshold and push it against the walls. If your top and bottom wall opening measurements are different or if the walls are out-of-plumb, make adjustment by slightly pulling the Wall profiles out of the Glass Profiles.
- Page 11 9. Using help to hold this Shower door assembly in the right position, mark the drill holes on the wall through the holes on the flange of the Wall Profile. Gently set the assembled unit aside. Drill the holes in the wall using Ø...
- Page 12 11. Fasten the Handle (13) to the Glass door 2 (03). Press the Magnetic strip (22) on the vertical edge of the Glass door 2 between the Glass door 2 edge and the Glass profile 2 (07). Press the Side strips (23) on the glass door edges.
-
Page 13: Product Maintenance
Product Maintenance To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive cleansers, metal brushes or scrapers that could scratch or dull the surface. To insure long lasting life for your glass shower products, wipe them off after each use with a soft cloth. - Page 14 SHOWER CABINS (JETTED & STEAM) DreamLine™ warrants glass, acrylic and finish to be free from defects in workmanship for a period of five (5) years from initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer; and plumbing, electrical and steam generator components for a period of one (1) year from the initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer.
- Page 15 TEL: 866-731-8378 – 215-957-1411 FAX: 866-227-9245 – 215-893-1780 WWW.B .COM UTHORITY For more information on DreamLine Shower Doors please visit www.BathAuthority.com Rev. 1.1...
