INFINITY-Z
S
D
& T
D
I
I
HOWER
OOR
UB
OOR
NSTALLATION
NSTRUCTIONS
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time without prior
TM
notice. For the latest up-to-date technical drawings, manuals or any other details please refer
to the
support.BathAuthority.com
web page.
Please read these instructions carefully before installing. If you have any questions regarding
installation, please call our technical support specialists Monday through Friday 9:00 AM – 5:00
PM EST at Phone: 1-866-731-2244, Fax:
1-866-227-1533
or e-mail our technical support group
support@BathAuthority.com.
at
TM
For more information on
DreamLine
Shower Doors
&
Tub Doors
please visit
www.BathAuthority.com
Advertisement
Summary of Contents for Dreamline INFINITY-Z
- Page 1 INFINITY-Z & T HOWER NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page.
- Page 2 Shower Door Components”. Examine boxes and packages for shipping damage. If the unit has been damaged, has a finishing defect, or is missing parts, please contact our customer support department within 5 business days of the delivery date. Please note that DreamLine will not replace any damaged products or missing parts free of charge after 5 business days or if the product has been installed.
-
Page 3: Packing List
Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement. NOTE: Retain these installation instructions for future reference. “INFINITY-Z” Rev.2 Ver.4 08/2013... -
Page 4: Shower Door Installation
L=Subtract W from the size of your Shower model. FOR EXAMPLE If your wall opening W=47”. Your shower model is 48”. L=48”-47”=1”, You have to cut 1” off from the rail. See Fig. 2 & Fig. 3 for details. “INFINITY-Z” Rev.2 Ver.4 08/2013... - Page 5 3 1/8” from the cut off edge of the Guide rail. Drill the new holes using Ø1/8” drill bit; then secure the stopper with screw. ATTENTION: Do not drill the Guide rail throughout, only the first layer. Ø 1/8” See Fig. 4 for details “INFINITY-Z” Rev.2 Ver.4 08/2013...
- Page 6 See Fig. 5 for details. 5. Slide the Stationary glass (05) fully into the groove of the Glass profile (01), and then secure it to the bottom Guide rail (03) with the Glass holder (16). See Fig. 6 for details. “INFINITY-Z” Rev.2 Ver.4 08/2013...
- Page 7 See Fig. 7 for details. 8. Slide the Wall profiles (02) all the way on the Glass profiles (01) on both sides. Make sure the flange of the wall profile faces inside the shower. See Fig. 8 for details. “INFINITY-Z” Rev.2 Ver.4 08/2013...
- Page 8 Guide rail (03). Place the whole shower assembly back in the designated position and secure Ø 5/16” it to the walls using the Round head screws ST4.2×30 (9). See Fig. 10 for details. . 10 “INFINITY-Z” Rev.2 Ver.4 08/2013...
- Page 9 Guide rail (03). Note: The lock nut of the upper wheel and the press button of the bottom wheel should be pointing See Fig. 12 for details. . 12 “INFINITY-Z” Rev.2 Ver.4 08/2013...
- Page 10 Press the anti-water strips (07) on the vertical edge of the Stationary glass (05) and both vertical edges of the Glass door. Insert the Seal gasket (15) into the Wall profile (02). See Fig. 14 for details. . 14 “INFINITY-Z” Rev.2 Ver.4 08/2013...
- Page 11 16. Apply the sealant along the profiles and guide rails; on the seams between the bottom guide rail and the profiles as well as along the shower base or threshold. See Fig. 16 for details. Waterproof Silicone . 16 “INFINITY-Z” Rev.2 Ver.4 08/2013...
-
Page 12: Product Maintenance
After cleaning the shiny finishes, rinse thoroughly and wipe dry with soft cloth. Clean stainless steel surfaces at least once a week. When applying stainless steel cleaner or polish, work with (not against/across) the grain. Never use an abrasive sponge or cloth, steel wool or wired brushes. “INFINITY-Z” Rev.2 Ver.4 08/2013... - Page 13 ™ EXCLUSIVE LIMITED WARRANTY AS OF MAY 6, 2013 DREAMLINE This warranty extends only to the original owner/end‐user for household use only and is not transferable to a subsequent owner. This warranty extends for a designated period of time, so long as it remains in use in its original place of installation. This warranty applies only to DreamLine products purchased from an authorized dealer in United States or Canada. Proof of purchase (original sales receipt) from the original consumer purchase must be provided with all warranty claims. IN NO EVENT SHALL THE LIABILITY OF DREAMLINE EXCEED THE PURCHASE PRICE OF THE UNIT. DreamLine products must be installed by a fully insured and licensed professional. Installation of DreamLine product by anyone other than fully insured licensed professionals shall VOID THE WARRANTY. DreamLine recommends that such licensed professionals have experience in the installation of bathroom products. Installation of certain products, including, without limitation, ...
- Page 14 TEL: 866-731-2244 FAX: 866-227-1533 WWW. UTHORITY.COM For more information on DreamLine Shower Doors & Tub Doors please visit www.BathAuthority.com...
