Cone Beam Computed Tomography Scanner, Panoramic
and Cephalometric X-ray imaging system
SERVICE MANUAL
THIS MANUAL MUST ALWAYS BE KEPT NEAR THE MEDICAL DEVICE
Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-Mind trium and is the answer not in the manual?

Questions and answers

Related Manuals for Acteon X-Mind trium

Summary of Contents for Acteon X-Mind trium

  • Page 1 Cone Beam Computed Tomography Scanner, Panoramic and Cephalometric X-ray imaging system SERVICE MANUAL THIS MANUAL MUST ALWAYS BE KEPT NEAR THE MEDICAL DEVICE Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 2 Via Roma, 45 21057 OLGIATE OLONA (VA) – ITALY Tel. +39 0331 376762 Fax +39 0331 376763 www.acteongroup.com For information and technical assistance, contact the manufacturer imaging.italysupport@acteongroup.com Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 2/200...
  • Page 3 ENGLISH Cone Beam Computed Tomography Scanner, Panoramic and Cephalometric X-ray imaging system DESCRIBED IN THIS MANUAL IS THE X-MIND trium MEDICAL DEVICE. “de Götzen® S.r.l. - ACTEON Group” RESERVES THE RIGHT TO MODIFY THE PRODUCT AND THIS MANUAL WITHOUT PRIOR NOTICE.

  • Page 4: Table Of Contents

    CORONAL LASER OFFSET ..........................154 13.4. ADJUSTMENT OF CEPH PATIENT EAR RESTS ....................156 QUALITY CHECK .............................. 158 PREVENTIVE MAINTENANCE ......................... 159 CALIBRATIONS REQUIRED AFTER PARTS REPLACEMENT ................160 Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 4/200...
  • Page 5 PGRADE FROM KEYBOARD TO KEYBOARD ALL MODELS 18.3. CEPH CEPH ......................... 184 PGRADE FROM READY TO 18.4. 3D .......................... 185 PGRADE FROM READY TO CABLING DIAGRAMS ............................192 Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 5/200...
  • Page 6 ENGLISH PAGE LEFT INTENTIONALLY BLANK Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 6/200...

  • Page 7: Warnings And Precautions

    1. WARNINGS AND PRECAUTIONS 1.1. WARNINGS TO BE OBSERVED DURING SERVICE Before attempting to service the X-MIND trium make sure that you know how to operate it. Read the operator’s manual. Read and familiarize yourself with the warnings and precautions listed in the operator’s manual.

  • Page 8: Cautions For Electrostatic Discharge

    1 Mohm current limiting cable. For a ground point use water pipes, radiators or other objects that are known to be connected to the ground. Also use a cable to connect the X-MIND trium to the same ground potential as the wrist wrap.

  • Page 9: General Warnings

    (six feet) away from the X-MIND trium during exposure. The X-MIND trium or its parts must not be changed or modified in any way without approval and instructions from de Götzen® S.r.l. - ACTEON Group.

  • Page 10: Introduction

    ENGLISH 2. INTRODUCTION This Service Manual details the corrective maintenance for the X-MIND trium system. In general, the defective part is located by means of diagnostic messages, self-test information or by the principle diagrams (to be defined). In the event of electronic defects, repairs are made by replacing one of the following exchangeable...

  • Page 11: Equipment Required

    ENGLISH 3. EQUIPMENT REQUIRED To perform corrective maintenance on X-MIND trium system, the following equipment is required: - standard toolset, - digital multimeter, - laser beam phantom, (not supplied: to be ordered separately, code W0900136) - panoramic geometric calibration phantom, (not supplied, to be ordered separately, code w0900135) Service manual •...
  • Page 12 - Ceph support for Quart phantom and additional 1mm copper filter, (not supplied, to be ordered separately as a kit, code w0900138) - CBCT geometric calibration phantom (left) and tray (right) (only for CBCT systems). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 12/200...

  • Page 13: X-Mind Trium Movements

    (CEPH models only) motor Vup and motor Vdown collimator vertical movements motor S (CBCT and CEPH models only) PAN/CBCT detector carriage movement (CBCT and CEPH models only) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 13/200...

  • Page 14: U-Arm Motion Management

    ENGLISH 5. U-ARM MOTION MANAGEMENT The U-ARM can be moved while X-MIND Trium is turned ON and the AIS software is closed (this includes also xmdriver). This is useful during covers installation to position the U-ARM in the most convenient position for each step of the installation of the covers.

  • Page 15: Troubleshooting

    6. TROUBLESHOOTING Error Codes When an error code appears on the display of the X-MIND trium and on the workstation monitor in AIS software, the unit will stop working and cannot be operated while the error code is on the display.
  • Page 16 If the damage cannot be repaired replace the cable. Note! If the connector on the corresponding board is also damaged, the board may also have to be replaced. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 16/200...

  • Page 17: Diagnostic Messages

    ENGLISH 7. DIAGNOSTIC MESSAGES While the X-MIND trium system is running, a number of messages may be generated on the display, to warn the operator of equipment irregularities or to indicate that some fault has occurred. In the latter case a diagnostic message will help to find the fault.
  • Page 18 In presence of a diagnostic message, the first action suggested is to reset the message from AIS software on the workstation; if the error persists, turn the X-MIND trium off from the main switch and turn it on again after 30 seconds. If the error still persists, leaving X-MIND trium on, restart the Workstation. If the problem is not solved despite the general reset, technical service is required.
  • Page 19 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 19/200...
  • Page 20 X-MIND trium and workstation. Unexpected motors condition MOTOR_AXES_TRJ_LOAD Reset error from AIS software on workstation; if error remains restart X-MIND trium and workstation. Trajectory loading from PC is failed Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 20/200...
  • Page 21 ++ 7 for Pan Image detector (cable P4104-E) + check ETHERNET switch; + check/replace AUX CBCT board (or, in case of PAN base unit, PAN sensor board); + check/replace image detector. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 21/200...
  • Page 22 + check motor X and its cable P4058 to Main board X-axis reset timeout (U-arm movement parallel to the wall) + check X optoswitch and its cable P4063 to Main board K11; + check/replace Main board. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 22/200...
  • Page 23 + check/replace Add On motor board; + check/replace Main board. B_AXIS_ERR_RES_RAMP Reset error from AIS software on workstation; if error remains restart X-MIND trium and workstation. Unexpected condition during B-axis reset Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 23/200...
  • Page 24 X-MIND trium and workstation. adjustment Y_AXIS_ERR_RUN_PTPT Reset error from AIS software on workstation; if error Unexpected condition during Y-axis position remains restart X-MIND trium and workstation. adjustment Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 24/200...
  • Page 25 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 25/200...
  • Page 26 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 26/200...
  • Page 27 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 27/200...
  • Page 28 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 28/200...
  • Page 29 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 29/200...
  • Page 30 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 30/200...
  • Page 31 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 31/200...
  • Page 32 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 32/200...
  • Page 33 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 33/200...
  • Page 34 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 34/200...
  • Page 35 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 35/200...
  • Page 36 RX tube calibration. NOTE: in case of Tubehead replacement, it is necessary to make a new collimator calibration (Pan - CBCT - Ceph). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 36/200...
  • Page 37 Power board even with the mains + check/replace Column board; switch off: disconnect X-MIND trium from the + check/replace Power board. mains supply before replacing this board Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 37/200...
  • Page 38 K25-red (+) and K25-white (-); switch off: disconnect X-MIND trium from the + check/replace Column board; mains supply before replacing this board + check/replace Power board. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 38/200...
  • Page 39 X-MIND trium and workstation. Column board error code 140 - Parameter memory If error remains technical service is required: CRC error + check/replace Column board. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 39/200...
  • Page 40 Dangerous mains voltage (100 – 240 VAC) is + check/replace Column board; present on the Power board even with the mains + check/replace Power board. switch off: disconnect X-MIND trium from the Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 40/200...
  • Page 41 HORZ_ONE_RESET_RAMP Reset error from AIS software on workstation; if error Unexpected condition during reset of primary remains restart X-MIND trium and workstation. collimator horizontal axis Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 41/200...
  • Page 42 XRAYS_EXAM_DO_BREAK releasing X-ray button; on the workstation will WARNING: operator has intentionally stopped the appear the message: “exposure button can be X-ray emission releasing X-ray button released”. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 42/200...

  • Page 43: Back Up Of Diagnostic Messages Log File

    C:AISsoftware\XMdriver\XM\config\log_inferr<date>.txt In case of request from the de Götzen® S.r.l. - ACTEON Group technical support, it is possible to create a back-up of the log file using the following the procedure. ...
  • Page 44 In the window click on START button. f. A diagnostic messages log file (AisLogManager<date>.log) will be stored in the following default directory with date and time of the creation: C:\AISsoftware\Tools\AisLogManager\Log Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 44/200...

  • Page 45: Hardware Troubleshooting

    Image is messy. Image is too dark or too light (preheating check, mA check, kV check). Column is not moving up/down. Column is moving in only one direction. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 45/200...

  • Page 46: Electronic Boards

    ENGLISH 10. ELECTRONIC BOARDS Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 46/200...

  • Page 47: Main Board - Pe4008

    4.7V – 5.5V K27 pin 6 K27 pin 1 12V internal (derived from +40VDC in) 11.3V – 12.8V K1 red K1 white 40VDC in 39V – 41V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 47/200...

  • Page 48: Pan Sensor Board - Pe4012 (Only Pan Base Model)

    12VDC in) - always present 5V analog PAN image detector (derived from 4.9V – 5.1V 12VDC in) - always present K1 red K1 white 12VDC in 11.5V – 12.5V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 48/200...
  • Page 49 Dangerous 385VDC voltage is present on this board. Dangerous mains voltage (100 – 240 VAC) is present on this board even when the mains switch is off: disconnect X-MIND trium from the mains supply before accessing to this board. Functions: Emergency switch interface.
  • Page 50 22 – 26V Trimmer P2 12V internal PFC 11.5V – 12.5V K21 red K21 white 12VDC OUT 11.5V – 12.5V K25 red K25 white 40VDC PUT 39V – 41V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 50/200...

  • Page 51: Aux Cbct Board - Pe4016

    + Green when microcontroller is running It is always ON/flashing + Green flashing when microcontroller programming is on going JUMPER SETTING DESCRIPTION Trigger CBCT image detector Closed CAN termination Closed Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 51/200...
  • Page 52 12VDC in) - present only when the image detector is ON K23 red K23 white 12VDC in 11.5V – 12.5V K24 red K24 white 40VDC in 39V – 41V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 52/200...

  • Page 53: Aux Ceph Board - Pe4020

    12VDC in) - present only when the image detector is ON K23 red K23 white 12VDC in 11.5V – 12.5V K24 red K24 white 40VDC in 39V – 41V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 53/200...

  • Page 54: Display Board - Pe4026

    ENGLISH 10.5. DISPLAY BOARD – PE4026 Trimmer DESCRIPTION + Trimmer to tune display brightness Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 54/200...

  • Page 55: Inverter Board - Pe4634

    Alarm, red ON when alarm present Red when +3.3VDC internal voltage is ON It is always ON Red when +24VDC internal voltage is ON It is always ON Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 55/200...
  • Page 56 3.1V – 3.5V J13 pin 21 TP2, J13 pin 24 +5.0VDC internal 4.75V – 5.25V J13 pin 23 TP2, J13 pin 24 +12VDC internal 11.0V – 14.4V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 56/200...

  • Page 57: Column Board - Dc-Fi

    Motor temperature sensor X204 Hall sensor X200, X201 Power supply X102, X103, X104, X105 Motor X205 Control connection 1 X206 Control connection 2 X207 Digital interface (CAN BUS) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 57/200...

  • Page 58: Add On Motor Board - Pe4010

    ENGLISH 10.8. ADD ON MOTOR BOARD – PE4010 Functions: S, B and C motor control. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 58/200...

  • Page 59: Configurations

     the vertical X-ray beam limitation  the serial number  the firmware update.  PROCEDURE a. End execution of AIS. b. Turn OFF then ON X-MIND trium. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 59/200...
  • Page 60 Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...

  • Page 61: Ip Address Setup

    In order that AIS software and X-MIND trium can communicate, the IP address programmed on Main board of X-MIND trium must be set into X-MIND driver; the IP address of the Network Interface Card (NIC) of the WorkStation must be of the same family of X-MIND trium IP address.
  • Page 62 VERIFY IP address e. Select SET IP address. f. In the window is shown the IP address used by X-MIND driver to establish connection with X-MIND trium. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 62/200...
  • Page 63 Right click on “TRIUM DO NOT MODIFY” network board and select properties. c. Select Internet Protocol and click on Properties. d. The persistent IP address used by NIC is shown in the window as follows: Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 63/200...
  • Page 64 CASE A) SET NEW IP ADDRESS FOR X-MIND DRIVER WITHOUT CHANGING IP ADDRESS OF X-MIND trium Do this when it is not possible to establish connection with X-MIND trium (having a different IP address). o TAKE NOTE OF THE IP ADDRESS OF X-MIND trium a.
  • Page 65 SET ACCORDINGLY IP ADDRESS OF X-MIND trium DRIVER g. Select SET IP address. h. Enter in the fields below the same IP address taken from X-MIND trium display (192.168.111.150 in this example). i. Click on SET driver IP button.
  • Page 66 Set the IP address as persistent and enter IP address value in accordance with X-MIND trium IP address value (192.168.111.4 in this example). n. SET Subnet mask to 255.255.255.0. Make effective the modification by ending the X-MIND driver SERVICE Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 66/200...
  • Page 67 Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). CASE B) SET NEW IP ADDRESS FOR X-MIND trium ON MAIN BOARD Do this when a different IP address from the factory one is desired for X-MIND trium. o LOGIN TO SERVICE a.
  • Page 68 Enter in the fields below the new desired IP address (192.168.111.150 in this example). h. Select the SET Model tab. Verify that the displayed IP address is correct and click on SET button. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 68/200...
  • Page 69 In Windows control panel select Network connections. k. Right click on “TRIUM DO NOT MODIFY” network board and select properties. Select Internet Protocol and click on Properties. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 69/200...
  • Page 70 Turn ON X-MIND trium. r. Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat s. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 70/200...

  • Page 71: Set Model Setup

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 72 SET Model PROCEDURE f. Click on SET Model tab. g. Verify that, depending on the actual model of X-MIND trium that is installed, the configuration in SET Model tab is as follows; if not click on the corresponding button (under...
  • Page 73 ENGLISH If the X-MIND trium is a PAN-CBCT or a PAN-CBCT-CEPH ready: If the X-MIND trium is a PAN-CEPH: If the X-MIND trium is a PAN-CBCT-CEPH: Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 73/200...
  • Page 74 ENGLISH h. In case in the setting above you have modified something, click on SET button. Consequently on the X-MIND trium control panel the red LED will be ON: i. To make effective the modification turn OFF X-MIND trium. j. End X-MIND driver SERVICE.

  • Page 75: Set Model Left - Right

    Turn OFF then ON X-MIND trium. c. Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating) e. Click on SERVICE tab and enter the required password: rdtech. o SET LEFT/RIGHT procedure f.
  • Page 76 LEFT/RIGHT in SET Model tab is as follows; if not flag the appropriate check box. If the X-MIND trium is a PAN kinematic right (ie control panel right) – CEPH left: If the X-MIND trium is a PAN kinematic right (ie control panel right) – CEPH right: Service manual •...
  • Page 77 ENGLISH If the X-MIND trium is a PAN kinematic left (ie control panel left) – CEPH left: If the X-MIND trium is a PAN kinematic left (ie control panel left) – CEPH right: Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 78 ENGLISH h. In case in the setting above you have modified something, click on SET button. Consequently on the X-MIND trium control panel the red LED will be ON. i. To make effective the modification turn OFF X-MIND trium. j. End X-MIND driver SERVICE.

  • Page 79: Set External Light Modality

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. o SET EXTERNAL LIGHT MODALITY PROCEDURE f.
  • Page 80 Depending on the desired modality of external light, flag or unflag the “Light always ON” check box. Above field FLAGGED: the external light is always ON when X-MIND trium is ON. Above field NOT FLAGGED: the external light is ON only during X-ray exposure.

  • Page 81: Set Country Customizations Of X-Mind Trium

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 82 (Pan and CEPH) do not have any white stripes on top and bottom parts. c. In case in the setting above you have modified something, click on SET button. Consequently on the X-MIND trium control panel the red LED will be ON: d. To make effective the modification turn OFF X-MIND trium.
  • Page 83 In case in the setting above you have modified something, click on SET button. Consequently on the X-MIND trium control panel the red LED will be ON: d. To make effective the modification turn OFF X-MIND trium. e. End X-MIND driver SERVICE.
  • Page 84 FOV 11x8 available. g. In case in the setting above you have modified something, click on SET button. Consequently on the X-MIND trium control panel the red LED will be ON: h. To make effective the modification turn OFF X-MIND trium.

  • Page 85: Set Serial Number Of X-Mind Trium

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). Click on SERVICE tab and enter the required password: rdtech. o SET SERIAL NUMBER OF X-MIND trium ON MAIN BOARD f.
  • Page 86 ENGLISH g. Take note of the serial number of X-MIND trium from label on the equipment. h. From the list of units installed on the WorkStation select the correct serial number: i. If not present in the list, edit the appropriate field with the serial number in the format XT01029C;...
  • Page 87 ENGLISH j. Click on SET button. Consequently on the X-MIND trium control panel the red LED will be ON. k. To make effective the modification turn OFF X-MIND trium. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...

  • Page 88: Firmware Update

    ENGLISH 11.8. FIRMWARE UPDATE  INTRODUCTION In this paragraph you can find instructions to update the Firmware (FW) of X-MIND trium electronic boards. These instructions are applicable to all X-MIND trium models. Perform this upgrade when:  You install an upgrade of AIS software package and FW upgrade is proposed automatically ...
  • Page 89 When the GREEN round icon stops blinking and becomes a flag, the upgrade is finished. k. To make effective the modification turn OFF X-MIND trium and leave it OFF at least: 2 minutes after Inverter board FW upgrade 30 seconds after other boards FW upgrade l.

  • Page 90: Calibrations

    Image detector (Pan – Ceph – CBCT)  Pan kinematic (all X-MIND trium models). The CBCT geometric calibration (CBCT X-MIND trium models only) is carried out by using the ”WHCalibration” software module. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...

  • Page 91: U-Arm Potentiometer Calibration

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 92 When movement is completed and U-arm is in the zero position (tubehead at the left looking at X-MIND trium from the front) click on arrow button of INF position field. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 93 Click on GOTO SUP button. j. When movement is completed and U-arm is at the 180° position (tubehead at the right looking at X-MIND trium from the front) click on arrow button of SUP position field. k. Click on SET button.

  • Page 94: Column Potentiometer Calibration

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 95 Click on Calibration tab and then click on Column potentiometer tab. g. Move column to 500 mm from BOTTOM position as per the following picture: h. Click on arrow button of INF position field. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 95/200...
  • Page 96 Click on arrow button of SUP position field. k. Click on SET button. l. To make effective the modification turn OFF X-MIND trium. m. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 96/200...

  • Page 97: Limitation Of X-Mind Trium Maximum Height

     INTRODUCTION In this paragraph you can find instructions to limit the X-MIND trium maximum height in order to install the equipment in a room less higher than the prescribed 2.4m. These instructions are applicable to all X-MIND trium models.
  • Page 98 Click on the button with the desired room height. h. Click on SET button. i. To make effective the modification turn OFF X-MIND trium. j. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 98/200...

  • Page 99: Ceph Nasion Potentiometer Calibration

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 100 Move the NASION of CEPH craniostat to INF position (toward the center of craniostat). h. Click on arrow button of INF position field. i. Move the NASION of CEPH craniostat to SUP position (toward the external part of craniostat). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 100/200...
  • Page 101 Click on arrow button of SUP position field. k. Click on SET button. l. To make effective the modification turn OFF X-MIND trium. m. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 101/200...

  • Page 102: U-Arm Encoder Calibration

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating) e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 103 When movement is completed and U-arm is in the zero position click on arrow button, then on SET button. j. To make effective the modification turn OFF X-MIND trium. k. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 103/200...

  • Page 104: Rx Tube Calibration

    Turn OFF then ON X-MIND trium. c. Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. o RX TUBE CALIBRATION f.
  • Page 105  It can take up to 2 minutes: DO NOT INTERRUPT the procedure i. To make effective the modification turn OFF X-MIND trium. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 105/200...

  • Page 106: Motorized Collimator Calibration

    Perform this calibration when:  You handle or replace the whole motorized collimator group  You handle or replace one or more of the optoswitches of all X-MIND trium mechanical axes  You handle or replace one sensor ...
  • Page 107 Select the type of exam for which you desire to align the X-ray beam (PAN, CBCT or CEPH). h. Follow instruction on top of window: click on RESET button. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 107/200...
  • Page 108 In the following example the X-ray beam must be shifted to the right: k. Click on button Set Suggested value. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 108/200...
  • Page 109 H axis (horizontal movement of the lead aperture mask)  V_SUP axis (vertical movement of the lead superior limiter)  V_INF axis (vertical movement of the lead inferior limiter) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 109/200...
  • Page 110  Panoramic collimator not ok: X-ray beam must be shifted to the left real dimension image zoomed image  Panoramic collimator ok real dimension image zoomed image Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 110/200...
  • Page 111  Ceph collimator not ok: X-ray beam must be shifted to the left real dimension image zoomed image  Ceph collimator ok real dimension image zoomed image Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 111/200...
  • Page 112  CBCT collimator not ok: X-ray beam must be shifted to the left real dimension image zoomed image (blemish raw can be ignored)  CBCT collimator ok real dimension image zoomed image (blemish raw can be ignored) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 112/200...
  • Page 113 Note: In case a Ceph image detector is used in panoramic, the frames acquired will show a reduced vertical dimension (the vertical dimension of the panoramic X-ray beam is smaller than the dimension of the Ceph image detector). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 113/200...

  • Page 114: Fixed Collimator Calibration

    Perform this calibration when:  You handle or replace the whole fixed collimator group  You handle or replace one or more of the optoswitches of all X-MIND trium mechanical axes  In some cases of collimator failures, depending on troubleshooting diagnostic messages.
  • Page 115 Click on Calib. Collimator tab. g. Select the PAN exam for which you desire to align X-ray beam. h. Follow instruction on top of window: click on RESET button. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 115/200...
  • Page 116 X-ray beam must be shifted to the right: k. Adjust the collimator manually in the desired direction and repeat steps from h to j till the X-ray beam covers correctly the image detector. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 116/200...
  • Page 117 The picture below shows how to adjust the translation of the fixed collimator:  unlock the screws (a) to move the lead aperture horizontally  unlock the screws (b) to move the lead aperture vertically. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 117/200...

  • Page 118: Image Detector Calibration

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 119 Remove all patient positioning aim devices from PAN/CBCT position. h. Only for CEPH models: place CEPH craniostat in AP position, rotate CEPH nasion in horizontal position and open at their maximum the ear rests. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 119/200...
  • Page 120 CEPH position. j. Select the image detector that you desire to calibrate (PAN, CBCT or CEPH). k. Follow instruction on top of window: click on RESET button. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 120/200...
  • Page 121 (the vertical dimension of the panoramic X-ray beam is smaller than the dimension of the Ceph image detector). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 121/200...
  • Page 122 SerialNumber >_O2.dgi o Gain: calib_SN<CBCT SerialNumber>_G2.dgi o Blemish: calib_SN<CBCT SerialNumber>_B2.csv  Calibration for CBCT Extended view exams with CBCT image detector related files: o Offset: calib_SN<CBCT SerialNumber >_O2_E.dgi Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 122/200...
  • Page 123 Ceph frames with artifacts: ear rests not opened at the maximum (zoomed image) Ceph frames with artifacts: ear rests not opened at the maximum (real dimension image) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 123/200...

  • Page 124: Pan Kinematic Calibration

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 125 Click on Calib. Kinematic tab. g. Place the PAN geometric calibration phantom into the bite block holder h. Follow instruction on top of window: click on RESET button. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 125/200...
  • Page 126 On the obtained PAN image position the markers XL, XR and C, right clicking on the image desired point: XL, XR and C markers must be positioned on the central ball as indicated above. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 126/200...
  • Page 127 F has to be positioned on the central vertical line, not necessarily in correspondance of a ball, as in the example above. l. Click on Set Suggested value button. m. Click on SET button. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 127/200...
  • Page 128 3 parameters are OK: in the example below simmetry is OK, center and focus are NOT OK. o. To make effective the modification turn OFF X-MIND trium. p. End X-MIND driver SERVICE. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 128/200...

  • Page 129: Cbct Calibration

    WHCalibration software module. The calibration calculates the parameters that describe the spatial configuration of the scanning apparatus. These instructions are applicable to the CBCT X-MIND trium models only. Perform this calibration when:  At first X-MIND trium installation ...
  • Page 130 ENGLISH b. Turn ON the X-MIND trium. c. Install the geometric calibration tray in the bite block holder. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 130/200...
  • Page 131 Turn ON the Work Station and complete the OS boot. Double click on the WHCalibration icon on the Desktop to start the software module. The WHCalibration interface will appear and a red led in the X-MIND trium state section will indicate that the X-MIND trium is not connected yet.
  • Page 132 ENGLISH g. Wait until the led in the X-MIND trium state section turns to blue indicating that the X-MIND trium is properly connected. h. Set the radio button in the Calibration type section to Automatic and click on START ACQ.
  • Page 133 Wait until the reset is completed as indicated by the green led in the X-MIND trium state section. k. Arm the X-MIND trium by pushing the START EXAM key on the control panel. Wait until the X-MIND trium is ready to scan as indicated by the yellow led in the X-MIND trium state section.
  • Page 134 Release the EXPOSURE SWITCH. p. Wait until the geometric calibration for the full view mode and the cooling down are completed. The process will take 40-60 seconds. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 134/200...
  • Page 135 Reset the X-MIND trium by pushing the RESET key on the control panel. s. Wait until the reset is completed as indicated by the green led in the X-MIND trium state section. t. Arm the X-MIND trium by pushing the START EXAM key on the control panel.
  • Page 136 ENGLISH u. Wait until the X-MIND trium is ready to scan as indicated by the yellow led in the X-MIND trium state section. v. Perform the scan of the calibration phantom by pressing the EXPOSURE SWITCH on the X-MIND trium remote control.
  • Page 137 Calibration ERROR!” will be displayed in the Calibration state section; in this case, repeat the entire procedure. z. When the calibration for the extended view mode is completed click on OK in the Information Window. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 137/200...
  • Page 138 A message box advises the operator in case the acquisition is terminated before acquiring all the waited projections. The operator might need to repeat the entire calibration procedure. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 138/200...

  • Page 139: Adjustments

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat d. Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). e. Click on SERVICE tab and enter the required password: rdtech. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E...
  • Page 140 Wait until the movement of the U-arm is completed. i. Turn on the lasers from the X-MIND trium control panel. The lasers will stay on for 10 minutes: if longer time is required, turn off and then on again the lasers, so that the countdown will restart.

  • Page 141: Adjustment Of Mid-Sagittal Pan Laser

    During the adjustment procedure, avoid to expose the eyes directly to the laser beam. To adjust the mid-sagittal pan laser projector located in the Patient Arm, proceed as follows: Make sure that the X-MIND trium is in the reset position (PAN). Insert the laser phantom (a) into the bite block holder (b).
  • Page 142 4 screws (e). When removing the handling cover, disconnect the 2 wires from the safety switch (f); when reconnect the wires, polarity of the connection is not significant. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 142/200...
  • Page 143 After the adjustment, when fixing the Allen screws (h), be sure that the laser beam is not moving. After the installation of the handling cover, verify that the laser beam is still visible on the laser phantom. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 143/200...

  • Page 144: Adjustment Of Axial Laser

    During the adjustment procedure, avoid to expose the eyes directly to the laser beam. To adjust the axial laser projector located in the Tubehead assembly, proceed as follows: Make sure that the X-MIND trium is in the reset position (CBCT). Insert the laser phantom (a) into the bite block holder (b).
  • Page 145 After the adjustment, when fixing the Allen screws (g), be sure that the laser beam is not moving. After the installation of the frontal Tubehead cover, verify that the laser beam is still visible on the laser phantom. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 145/200...

  • Page 146: Adjustment Of Coronal/Canine Laser

    During the adjustment procedure, avoid to expose the eyes directly to the laser beam. To adjust the coronal/canine laser projector located in the Tubehead assembly, proceed as follows: Make sure that the X-MIND trium is in the reset position (PAN). Insert the laser phantom (a) into the bite block holder (b).
  • Page 147 X-MIND trium Pan model X-MIND trium Pan-CBCT-Ceph models After the installation of the frontal Tubehead cover, verify that the laser beam is still visible on the laser phantom. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 147/200...

  • Page 148: Adjustment Of Multi-Line Frankfurt Laser

    To adjust the Multi-line Frankfurt laser projector located in the Tubehead assembly, proceed as follows: Make sure that the X-MIND trium is in the reset position (PAN). Insert the laser phantom (a) into the bite block holder (b). c. Switch on the laser by pressing the LASER key on the control panel and verify that the CENTRAL LINE of the multi-line Frankfurt light beam is horizontal and that it is aligned with the groove (c) of the phantom and the central dot is in the center (c1) as indicated on the phantom.
  • Page 149 X-MIND trium Pan model X-MIND trium Pan-CBCT-Ceph models After the installation of the frontal Tubehead cover, verify that the laser beam is still visible on the laser phantom. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 149/200...

  • Page 150: Adjustment Of Cbct Mid-Sagittal Laser

    During the adjustment procedure, avoid to expose the eyes directly to the laser beam. To adjust the CBCT mid-sagittal laser located in the U-arm, proceed as follows: Make sure that the X-MIND trium is in the reset position (CBCT). Insert the laser phantom (a) into the bite block holder (b).
  • Page 151 5. PAN/CBCT image detector carriage front cover by means of 2 screws. 6. PAN/CBCT image detector carriage rear cover by means of 4 screws. 7. U-arm cover top by means of 2 screws. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 151/200...
  • Page 152 (g) to rotate the laser projector in the desired position. After the adjustment, when fixing the Allen screws (g), be sure that the laser beam is not moving. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 152/200...
  • Page 153 ENGLISH After the installation of the U-arm bottom cover, verify that the laser beam is still visible on the laser phantom. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 153/200...

  • Page 154: Coronal Laser Offset

    Start XMdriver Show double clicking on the file: C:\AISSoftware\XMdriver\XMdriverShow.bat Verify that SERVICE tab has green flag (WorkStation and X-MIND trium are communicating). Click on SERVICE tab and enter the required password: rdtech. k. Click on “CBCT coronal laser”...
  • Page 155 1 minute o. Make scan with same parameters as the first p. The result should be as the picture below. If not repeat procedure from point “e” Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 155/200...

  • Page 156: Adjustment Of Ceph Patient Ear Rests

    Rotate the ceph craniostat in the LL position. s. Set the ear rests in the middle opening position acting on the knob (b). t. Make an exposure with 60kV – 4mA. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 156/200...
  • Page 157 If adjustments are necessary, adjust the position of the external ear rest (the one far away from the sensor) in the desired direction by loosing the screws (c). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 157/200...

  • Page 158: Quality Check

    Depending on local and national requirements, a Quality Check has to be done using the Quality Check phantoms supplied, as explained in the XMt quality assessment manual. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 158/200...

  • Page 159: Preventive Maintenance

    PLEASE NOTE This Preventive Maintenance Checklist must be carried out:  At least each year after installation of all CBCT models of X-MIND trium This Preventive Maintenance Checklist is suggested to be carried out:  At least each year after installation of all CBCT models of X-MIND trium Instructions and checklist available on the “XMt Installation manual EN”...

  • Page 160: Calibrations Required After Parts Replacement

    + Verification of all laser alignment.  Calibrations: + Verification of all laser alignment. X axis optoswitch o Collimator (Ceph only) o Pan kinematics o CBCT geometry Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 160/200...
  • Page 161 + Verification of collimator Motorized collimator calibration. motors: axes H, V_SUP, V_INF  Calibration: H axis optoswitch (collimator) o Collimator  Calibration: V_SUP axis optoswitch (collimator) o Collimator Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 161/200...
  • Page 162 + Install the calibration files supplied by factory in the Work Station.  None CEPH image detector + Install the calibration files supplied by factory in the Work Station. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 162/200...

  • Page 163: Replacement Procedures

    4. Tubehead rear cover by means of 6 screws. 5. Metallic electronic boards protection cover by means of 6 screws. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 163/200...
  • Page 164 CBCT board and the relevant ground connections  disconnect the connectors J14 and J8 from the Inverter board)  cut the 2 cable retainers (a) on the Tubehead Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 164/200...
  • Page 165 2 cable retainers (a) on the close to the Inverter board  remove the motorized collimator (a) with all the cables by unscrewing the 2 screws (b) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 165/200...
  • Page 166 Finally, it is necessary to perform the following calibrations and adjustment:  Adjustment:  Calibrations: o Verification of all laser alignment o RX tube o Collimator Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 166/200...

  • Page 167: Inverter Board Replacement

    5. Metallic electronic boards protection cover by means of 6 screws. c. Disconnect all the connectors from the Inverter board. d. Remove 4 fixation screws (a) then remove the Inverter (b) with the metallic protection cover. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 167/200...
  • Page 168 To do this, it is necessary to access to the Inverter board by removing the metallic protection cover (a) fixed with the 4 screws (b). g. Finally, it is necessary to perform the following calibration and adjustment: Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 168/200...
  • Page 169 ENGLISH  Calibration:  Adjustment: o RX tube o None Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 169/200...

  • Page 170: Aux Cbct Board Replacement

    5. Metallic electronic boards protection cover by means of 6 screws. c. Disconnect all the connectors from the Aux CBCT board. d. Remove the 6 fixation screws (a) and then remove the Aux CBCT board. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 170/200...
  • Page 171 Proceed backwards for the mounting of the new Aux CBCT board. e. Verify that the setting of all jumpers on the new Aux CBCT board is the same as the old one. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 171/200...
  • Page 172 2. Top cover right by means of 3 screws. 3. Front cover by means of 2 screws. 4. Head cover left by means of 5 screws. 5. Head cover right by means of 5 screws. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 172/200...
  • Page 173  Settings:  Calibration & Adjustment: o IP address (if before replacement o None a value different from default was used) o Serial number of X-MIND trium Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 173/200...

  • Page 174: Main Board Replacement

    Turn OFF the X-MIND trium. Remove the top cover (a) of the Ceph craniostat by unscrewing the 4 screws (b). Disconnect all the connectors from the Aux Ceph board (a). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 174/200...
  • Page 175 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 175/200...
  • Page 176 Verify that the setting of all jumpers on the new AUX Ceph board is the same as the old one. SETTING DESCRIPTION Trigger Ceph image detector Closed CAN termination Closed Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 176/200...

  • Page 177: Pan Sensor Board Replacement

    Verify that the setting of the jumper on the new Pan Sensor board is the same as the old one. SETTING DESCRIPTION Trigger PAN image detector Closed Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 177/200...

  • Page 178: Power Board Replacement

    Dangerous 385VDC voltage is present on this board. Dangerous mains voltage (100 – 240 VAC) is present on this board even when the mains switch is off: disconnect X-MIND trium from the mains supply before accessing to this board. To replace the Power board proceed as follows: Turn OFF the X-MIND trium.
  • Page 179 Take note of the polarity of the mains connection cables: Line to connector K39, Neutral to K17 and PE to K40. Remove the Power board with the heatsink by unscrewing the 4 screws (a). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 179/200...
  • Page 180 SIZE RATING DESCRIPTION 100 – 240 VAC input 6.3 X 32 T 10A – 250V for power supply 200V-240V T 15A – 250V for power supply 100V-200V Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 180/200...

  • Page 181: Column Board Replacement

    Remove the lower cover (a) by means of 4 screws. c. Remove the metallic protection cover (a) by means of 4 screws and disconnect the ground cable (b). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 181/200...
  • Page 182 Verify that the setting of the jumpers on the new Column board is the same as the old one. SETTING DESCRIPTION X208 pin 2-3 CAN termination Closed Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 182/200...

  • Page 183: Upgrade Procedures

    Turn ON the X-MIND trium. For all CBCT models: Calibrate U-arm encoder. For all CBCT models: align axial laser and CBCT mid-sagittal laser. For all models: align Frankfurt laser. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 183/200...

  • Page 184: Upgrade From Ceph Ready To Ceph

    4mA and verify that the ear rings are one inside the other: if not, adjust mechanically the fixation of the ear rest bars (as per instructions in the paragraph ADJUSTMENT OF CEPH PATIENT EAR RESTS of this manual). Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 184/200...

  • Page 185: Upgrade From 3D Ready To 3D

    MONITOR 24 INCHES DELL P2417H 3.98.00923 DONGLE KEY TRIUM (LICENCE SW RECONSTR) (fixed to rear part of WorkStation) GEOMETRIC PHANTOM FOR CBCT 2.19.02175 TRIUM CALIBRATION PHANTOM 2.75.02176 TRIUM CALIBRATION PHANTOM SUPPORT Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 185/200...
  • Page 186 ENGLISH Quick guide for upgrade CASE 1 – The X-Mind trium has already been installed in the field and used with a customer PC (2D PC) as PAN only or PAN/CEPH only unit: 2D PC External drive 3D workstation (part of 3D upgrade) AIS backup manager ->...
  • Page 187 ENGLISH Detailed procedure for upgrade a. On the 2D PC, if previously used in the field with X-Mind trium as PAN or PAN-CEPH only: Backup patient database and images to an external hard disc or USB key: AIS backup manager -> Tools -> Backup Select destination folder on an external hard disc or USB key ->...
  • Page 188 Else, if the trium has not yet been used in the field, restore FACTORY trium configuration: a. Connect the USB key from X-Mind trium box to the 3D workstation part of upgrade b. Run TriumConfig_Installer_v1.4.0-1, double clicking on the setup file c.
  • Page 189 ENGLISH e. Proceed with license agreement, then click on ‘Next’ Click on ‘Install’ to start the installation g. Click on ‘Finish’ to complete the installation. Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 189/200...
  • Page 190  Connect on the REAR of panel the cable 4 - P4047_CAVO-GBIT-ROTANTECBCT- CBCTSENSOR  Connect on the panel the cable 8 - P4079_CAVO-5VISO-AUXCBCT-CBCTSENSOR  Fix frontal cover of translating cassette (remind the two screws on the bottom) Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 190/200...
  • Page 191 Check that the calibration files of the CBCT panel from are present in the folder: C:\AISSoftware\XMdriver\XM\config of the 3D workstation iii. Set appropriate model of the X-Mind trium as PAN-CBCT or PAN-CEPH-CBCT a. Follow instructions of paragraph 11.3 SET MODEL SETUP Adjust X-Ray collimation on CBCT sensor a.

  • Page 192: Cabling Diagrams

    ENGLISH 19. CABLING DIAGRAMS Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 192/200...
  • Page 193 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 193/200...
  • Page 194 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 194/200...
  • Page 195 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 195/200...
  • Page 196 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 196/200...
  • Page 197 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 197/200...
  • Page 198 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 198/200...
  • Page 199 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 199/200...
  • Page 200 ENGLISH Service manual • X-Mind trium • (13) • 01/2018 • NTR0EN030E pag. 200/200...

Table of Contents
