  • Page 1 User Manual Newtron P5 XS B.LED...
  • Page 2 This document is an English translation of the original French version. Reference J62150 version V11 and drawing number NBADFR030K...

  • Page 3: Table Of Contents

    Contents 1 Documentation 1.1 Associated documentation 1.2 Electronic documentation 2 Required information 2.1 Indication for use 2.2 Operating principle 2.3 Using accessories not supplied by the manufacturer 2.4 Connecting and disconnecting accessories during use 2.5 Repairing or modifying the medical device 2.6 Warranty 2.7 Latest document update 2.8 Date of first CE marking...
  • Page 4 10.1 Not working 10.2 No spray 10.3 The power is not as expected 10.4 Ultrasounds not working 10.5 Water leakage 11 Technical specifications of the medical device 11.1 Identification 11.2 Generator 11.3 Length of cords 11.4 Irrigation 11.5 Footswitch 11.6 Environmental characteristics 11.7 Environmental restrictions 11.8 Main performance characteristics 12 Regulations and standards...

  • Page 5: Documentation

    Keep the original documentation for your medical device and its accessories for future reference. When loaning out or selling the medical device, the documentation must be provided with it. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 3/38...
  • Page 6 Page 4/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 7: Required Information

    2.3 Using accessories not supplied by the manufacturer The handpiece is designed to operate with SATELEC, a company of Acteon group dental tips and files. The use of tips or files made by other manufacturers will damage the handpiece, break tips and files and void the warranty.

  • Page 8: Warranty

    The screws marked A, B and C must not be unscrewed by the user under any circumstances as this may void the warranty for the medical device. 2.7 Latest document update 01/2023 2.8 Date of first CE marking 2013 Page 6/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 9: Unpacking The Medical Device

    A Newtron P5 XS B.LED [J62100] Quick Start guide A Newtron P5 XS B.LED [J62101] Quick Clean guide Tips and wrenches depending on selected options A power cord User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 7/38...
  • Page 10 Page 8/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 11: Connect The Medical Device

    2. Connect the mains cord to the control unit's mains connector. 3. Connect the power lead to the mains socket. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 9/38...
  • Page 12 Page 10/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 13: Installing The Medical Device

    To prevent self-locking of the tip or the file, the latter must be removed and sterilised after each use. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 11/38...
  • Page 14 The torque wrenches must be replaced every year. Page 12/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 15: Dispensing A Treatment

    10. Check the irrigation parameters depending on the tip chosen. 11. After water drainage, check that the spray works correctly. Your medical device is now ready to use. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 13/38...
  • Page 16 Page 14/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 17: Medical Device Description

    The purge function can be stopped at any time by pressing the control pedal again. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 15/38...

  • Page 18: Overview Of The Pedal

    Each tip must be used in accordance with the settings defined in the ultrasonic generator irrigation and power settings table [J58000]. Page 16/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 19: Disinfection And Sterilising

    Never apply sprays directly to the medical device to clean it. Always spray the product onto a wipe, then clean the medical device. To prepare for cleaning, remove the various parts of the Newtron P5 XS B.LED as shown here. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 17/38...

  • Page 20: Cleaning, Disinfecting And Sterilising Accessories

    8.2 Cleaning, disinfecting and sterilising accessories Refer to the cleaning, disinfection and sterilisation instructions for accessories listed in the chapter Associated documentation page 3. Page 18/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 21: Monitoring And Routine Maintenance

    4. Insert the tip of a flathead screwdriver into the notch on top of the fuse holder to release it. 5. Remove the used fuses. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 19/38...

  • Page 22: Replacing The Irrigation Cassette

    8. Connect the mains cord to the connector. 9. Connect the mains cord to the electrical network. 9.2.2 Replacing the irrigation cassette Page 20/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 23 User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 21/38...
  • Page 24 Page 22/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 25 User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 23/38...
  • Page 26 Page 24/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...

  • Page 27: Identifying Incorrect Operation

    Replace the handpiece seal using the purpose-provided Faulty handpiece seal kit. 10.4 Ultrasounds not working Symptoms: the tip does not vibrate. User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 25/38...
  • Page 28 Replace the irrigation cassette using the purpose-designed Worn irrigation cassette kit as detailed in the chapter Replacing the irrigation cassette page 20 Page 26/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 29 30 mm Depth 105 mm Weight 220 g Ingress protection rating IPX1 11.6 Environmental characteristics Ambient operating temperature +10°C to +30°C User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 27/38...
  • Page 30 Ultrasonic vibrations of the tip or file fitted to the end of the conventional dental ultrasonic handpiece. Vibration frequency ≥ 28 kHz. Tip amplitude ≤ 200 µm. Page 28/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 31 Consult the User Manual The accompanying documentation is available in electronic format Pressure limit Temperature limit Humidity limit Packaging unit User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 29/38...
  • Page 32 Washer-disinfector for thermal disinfection Ultrasonic bath Type BF part in contact Alternating current Intensity Purge Peristaltic pump Electromagnetic interference CE marking CE marking Page 30/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 33 Use a lint-free cloth for cleaning Use an ultrasonic tank for cleaning. Use a swab for cleaning Use deionised or osmosis-purified water for cleaning User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 31/38...
  • Page 34 RUSSIA Tel. +612 9669 477 307 Mob. +7 926 233 1695 Fax. +612/96692204 Tel. +7 495 150 1323 info.au@acteongroup.com info.ru@acteongroup.com Page 32/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 35 Mount Laurel, NJ 08054 - USA Mobile: +57 312 377 8209 Tel. +1 856 222 9988 info.latam@acteongroup.com Fax. +1 856 222 4726 info.us@acteongroup.com User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 33/38...
  • Page 36 247 Wasfi Al Tal str. 401 AMMAN - JORDAN Tel. +962 6 553 4401 Fax. +962 6 553 7833 info.me@acteongroup.com Page 34/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 37 When your medical device has reached the end of its service life, contact your nearest dental equipment dealer, or the Acteon head office or one of the company branches to find out how to proceed. The relevant contact details are given in the chapter Branch addresses page 32.
  • Page 38 29 electronic 3 electronic user instructions 3 endodontics 5 Quick Clean 3 European directive 29 Quick Start 3 Page 36/38 - User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K...
  • Page 39 27 tip 3, 5, 25-26 ultrasonic vibrations 5 update 6 User Manual 3 Vibration frequency 28 water leakage 26 User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K - Page 37/38...
  • Page 40 User Manual | Newtron P5 XS B.LED | J62151 | V11 | (13) | 01/2023 | NBADEN030K SATELEC A Company of the ACTEON Group 17 av. Gustave Eiffel ZI du Phare 33700 MERIGNAC FRANCE Tel. +33 (0) 556 34 06 07 Fax.
