  • Page 1 User’s manual...

  • Page 3: Table Of Contents

    ENGLISH I – DESCRIPTION ..........6 II – INSTALLATION/STARTUP ......8 III – ROUTINE OPERATION ........ 8 IV – CONFIGURATION ........9 V - INTERLOCKS ..........9 VI - ACCESSORIES .......... 9 VII - TROUBLESHOOTING GUIDE ......9 VIII – SYMBOLS AND ABBREVIATIONS ....11 User’s Manual Mini LED ORTHO 2 ●...
  • Page 4 Light guide (2) Handpiece (1) Handpiece holder (9) Battery (8) Charging base (11) AC power adapter (12) (Not shown) 4 ● User’s Manual Mini LED ORTHO 2 ● J05221 ● V1 ● (13) ● 09/2013 ● N005EN010A...
  • Page 5 ON/OFF button (3) Two-color LED Error Indicator Light (4) LCD screen (5) Alert Mode Button (6) Timing Configuration Button (7) Power verification window (10) User’s Manual Mini LED ORTHO 2 ● J05221 ● V1 ● (13) ● 09/2013 ● N005EN010A ● 5...

  • Page 6: I - Description

    This is the user’s manual for your Mini LED™ ORTHO 2 • Display of the battery charge level status (battery device. being most charged when all of the pictogram’s round This document must be used together with the general symbols are displayed and the least charged when all user’s manual for SATELEC curing lamps.

  • Page 7: User's Manual Mini Led Ortho 2 ● J05221 ● V1 ● (13) ● 09/2013 ● N005En010A

    when the handpiece is in standby mode. Dimensions: Ø24 x 201 mm Charging base Operation: The charging base is used to recharge the battery and Continuous operation also includes a translucent handpiece holder (Fig. 1-9) Protection: and a power level verification window (Fig. 2-10). The translucent handpiece holder holds the unit in the Category: Type B...

  • Page 8: Installation/Startup

    shipment. Charge it fully prior to using it each time. Storage: 0% to 100% condensation included 2.3 e xPosure times available II – INSTALLATION/STARTUP Mini LED™ ORTHO 2 offers 4 exposure times, selected by pushing the right button (Fig. 2–7): 2.1 o 4 seconds;...

  • Page 9: Configuration

    taken out of standby mode by simply pressing one of sounds twice. the three buttons (which will not activate that function You then have about 500 seconds remaining before when coming out of standby mode). the unit becomes completely discharged. It is then recommended, if possible, to charge the battery for IV –...
  • Page 10 Symptom Possible causes Solutions Battery completely discharged Recharge battery No operation (LCD screen off) Battery defective Return to SATELEC after-sales department Mini LED™ defective Return to SATELEC after-sales department No operation Mini LED™ defective Return to SATELEC after-sales department (LCD screen on) Check cleanliness of LEDs, clean with dry air jet and / LED defective and / or dirty or return to SATELEC after-sales department...

  • Page 11: Symbols And Abbreviations

    ACTEON GROUP on request all the information they need for repair of the parts of the curing light that ACTEON has identified as repairable. User’s Manual Mini LED ORTHO 2 ● J05221 ● V1 ● (13) ● 09/2013 ● N005EN010A ● 11...
  • Page 12 J05221 ● V1 ● (13) ● 09/2013 ● N005EN010A 17 av. Gustave Eiffel • BP 30216 • 33708 MERIGNAC cedex • FRANCE Tel + 33 (0) 556 34 06 07 • Fax + 33 (0) 556 34 92 92 E-mail : satelec@acteongroup.com • www.acteongroup.com...
