TROUBLESHOOTING GUIDE

for 2022 UL 325 Compliant Gate Operators

NOTE: This guide does not include BLDC Gate Operators, HDSL24UL, HDSW24UL,

INSL24UL, and IHSL24UL.

LA500UL

LA400UL

LA412UL

CSW24UL

CSL24UL

RSL12UL

RSW12UL

CSW200UL

SL3000UL

SL585UL

SL595UL

LiftMaster

300 Windsor Drive

Oak Brook, IL 60523

EXTERNAL SAFETY

DEVICES REQUIRED. SEE

SAFETY SECTION FOR UL325

ENTRAPMENT PROTECTION

REQUIREMENTS IN YOUR

OPERATOR MANUAL.

THESE PRODUCTS

MUST BE INSTALLED AND

SERVICED IN ACCORDANCE

WITH THE OPERATOR MANUAL

BY A TRAINED GATE

SYSTEMS TECHNICIAN

ONLY.

Need help?

Do you have a question about the LA500UL and is the answer not in the manual?

Questions and answers

Summary of Contents for Chamberlain LA500UL

Page 1 TROUBLESHOOTING GUIDE for 2022 UL 325 Compliant Gate Operators NOTE: This guide does not include BLDC Gate Operators, HDSL24UL, HDSW24UL, INSL24UL, and IHSL24UL. LA500UL EXTERNAL SAFETY EXTERNAL SAFETY DEVICES REQUIRED. SEE DEVICES REQUIRED. SEE SAFETY SECTION FOR UL325 SAFETY SECTION FOR UL325...
Page 2 MODELS SL585UL AND SL595UL (THREE PHASE) ......... 22 UL COMPLIANT GATE OPERATORS ..............2 MODEL LA412UL ....................23 MODEL LA400UL ....................24 BASIC TROUBLESHOOTING MODEL LA500UL ....................25 MULTI-METERS....................3 MODELS CSL24UL AND CSW24U ..............26 TRANSFORMERS ....................4 MODELS RSL12UL AND RSW12U ..............27 RELAYS........................
Page 3 BEFORE YOU BEGIN UL COMPLIANT GATE OPERATORS The UL standard requires gate operators to monitor for the presence of external entrapment devices and any fault conditions. LiftMaster has not only updated their line of gate operators to meet the new UL 325 standard, they have also taken the opportunity to add a common user interface and common feature sets across the line to increase performance, safety and accessibility.
Page 4 BASIC TROUBLESHOOTING MULTI-METERS The image is an example of a generic multimeter. LiftMaster currently has no intended affiliations with this multi-meter manufacturer. This is not an endorsement for this particular meter model. When shopping for a meter, look for a meter able to fit in a shirt pocket or clip on a belt.
Page 5 The output rating has nothing to do with the required amount of electricity to make the accessory function. TYPE OF TRANSFORMERS MODELS Plug-in Transformer LA400UL, RSL12UL, RSW12UL Toroid Transformer LA500UL, CSL24UL, CSW24UL, HD OPERATORS Block Transformer CSW200UL, SL3000UL, SL585UL, SL595UL...
Page 6 BASIC TROUBLESHOOTING RELAYS EXPANSION BOARD RELAYS In gate operators, relays are commonly used to control operator functions or activate/deactivate ancillary devices such as heaters or lights. When electricity is applied to a relay coil, it energizes a magnetic field that will close a Normally Open switch or open a Normally Closed switch. A relay typically has prongs labeled COM , NO, NC, and two prongs to power the relay coil.
Page 7 BASIC TROUBLESHOOTING To protect against fire and electrocution: • DISCONNECT power (AC or solar and battery) BEFORE installing or servicing operator. CAPACITOR (FOR AC OPERATORS) SYMPTOM: A bad capacitor will cause a motor to hum when trying to run, or stall while it is running. CHECK THE CAPACITOR: Disconnect ALL power from operator.
Page 8 BASIC TROUBLESHOOTING To protect against fire and electrocution: • DISCONNECT power (AC or solar and battery) BEFORE installing or servicing operator. BRUSHED DC MOTORS SYMPTOM: The motor will not run. CHECK THE MOTOR: Disconnect ALL power from operator. Disconnect the gate from the operator. 12V MOTOR 24V MOTOR DIAGNOSTICS...
Page 9 BASIC TROUBLESHOOTING To protect against fire and electrocution: • DISCONNECT power (AC or solar and battery) BEFORE installing or servicing operator. AC MOTORS SYMPTOM: The motor will not run. CHECK THE MOTOR: Disconnect ALL power from operator. Disconnect the gate from the operator. Unplug the motor harness from the board and measure the resistance of the motor.
Page 10 BASIC TROUBLESHOOTING ERASE MEMORY ERASE ALL REMOTE CONTROLS 1. Press and release the LEARN button (operator will beep and green XMITTER LED will light). 2. Press and hold the LEARN button again until the green XMITTER LED flashes and then release the button (approximately 6 seconds). All remote control codes are now erased.
Page 11 BASIC TROUBLESHOOTING PROGRAMMING LIMITS WITH BUTTONS AND REMOTES For dual gate applications, the limits must be set for each operator. The gate MUST be attached to the operator before setting the limits and force. Ensure the gate is closed. 1. Press and release the SET OPEN and SET CLOSE buttons simultaneously to enter limit setting mode. 2.
Page 12 DIAGNOSTIC CODES To retrieve logic board diagnostic history, the operator must be activated. • Replace ONLY with fuse of same type and rating. For continued protection against fire: DIAGNOSTIC CODES OPEN, CLOSE, & STOP BUTTONS TO VIEW THE CODES DIAGNOSTICS DISPLAY The codes will show on the diagnostic display.
Page 13 DIAGNOSTIC CODES Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear. When servicing of the operator is complete, erase the code history by pressing the STOP button until the display flashes “Er” then “CL” (about 6 seconds).
Page 14 DIAGNOSTIC CODES Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear. When servicing of the operator is complete, erase the code history by pressing the STOP button until the display flashes “Er” then “CL” (about 6 seconds).
Page 15 DIAGNOSTIC CODES Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear. When servicing of the operator is complete, erase the code history by pressing the STOP button until the display flashes “Er” then “CL” (about 6 seconds).
Page 16 DIAGNOSTIC CODES Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear. When servicing of the operator is complete, erase the code history by pressing the STOP button until the display flashes “Er” then “CL” (about 6 seconds).
Page 17 DIAGNOSTIC CODES Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear. When servicing of the operator is complete, erase the code history by pressing the STOP button until the display flashes “Er” then “CL” (about 6 seconds).
Page 18 SOLAR SOLAR TROUBLESHOOTING SYMPTOM The operator alarm will beep three times with a command and the BATT LOW LED will be on when the solar panel is not charging the battery. SOLUTIONS • Check that the correct number of solar panels are connected to the operator. 12V operators require one 10W 12V panel up to a maximum of three 10W 12V panels three solar panels wired in parallel.
Page 19 SOLAR 24V APPLICATIONS Disconnect all power (AC, solar, battery) to the operator before servicing. NOTE: 10W 12V solar panels are illustrated in the image below. In normal operation, the voltage across the diode should measure 0.7 VDC. 33AH BATTERIES To “BATT DC POWER” input on control board ITEMS NEEDED FOR 24V APPLICATIONS...
Page 20 SOLAR 12V APPLICATIONS Disconnect all power (AC, solar, battery) to the operator before servicing. NOTE: 10W 12V solar panels are illustrated in the image below. ONE 7AH BATTERY ITEMS NEEDED FOR 12V APPLICATIONS To “BATT DC POWER” input on control board J15 Plug In normal operation, the voltage across the diode should measure 0.7 VDC.
Page 21 POWER MODELS CSW200UL AND SL3000UL Follow the steps in order, from the buttom up. MODEL CSW200U MODEL SL3000U POWER BOARD (located behind control board) CONTROL BOARD BIPART DELAY AC POWER SWITCH OPEN OPEN LEFT RIGHT CONTROL BOARD HANDING JUNCTION BOX AC POWER SWITCH JUNCTION BOX MOTOR DRIVE...
Page 22 POWER MODELS SL585UL AND SL595UL (SINGLE PHASE) Follow the steps in order, from the buttom up. CONTROL BOARD MODEL SL595UL MODEL SL585UL BIPART CONTROL BOARD POWER BOARD DELAY CONTROL BOARD POWER BOARD OPEN OPEN LEFT RIGHT HANDING AC POWER SWITCH JUNCTION JUNCTION BOX MOTOR DRIVE...
Page 23 POWER MODELS SL585UL AND SL595UL (THREE PHASE) Follow the steps in order, from the buttom up. CONTROL BOARD MODEL SL595U MODEL SL585U BIPART CONTROL BOARD POWER BOARD DELAY CONTROL BOARD POWER BOARD OPEN OPEN RIGHT LEFT HANDING AC POWER SWITCH JUNCTION JUNCTION BOX Check the transformer and...
Page 24 POWER MODEL LA412UL SYMPTOM: Operator does not have power. CONTROL BOX CONTROL BOARD DIAGNOSTICS Check the solar panels.* Check the control board.* CONTROL BOARD Check the voltage coming from Try replacing the fuse. the solar panels with the harness If that does not work, replace connected to the board.
Page 25 POWER MODEL LA400UL SYMPTOM: Operator does not have power. OUTLET HOUSING CONTROL BOX CONTROL BOARD DIAGNOSTICS CONTROL BOARD Check the control board.* Try replacing the fuse. If that does not work, replace Incoming Power DIAGNOSTICS DIAGNOSTICS the control board. (Back of Outlet Housing) Outlet Outlet Check the transformer.*...
Page 26 POWER MODEL LA500UL SYMPTOM: Operator does not have power. CONTROL BOX CONTROL BOARD DIAGNOSTICS TRANSFORMER BRIDGE RECTIFIER Incoming Power AC POWER SWITCH CONTROL BOARD Check the control board. Try replacing the fuse on the control board. If that does not Check the transformer.*...
Page 27 POWER MODELS CSL24UL AND CSW24UL SYMPTOM: Operator does not have power. MODEL CSL24U MODEL CSW24U CONTROL BOARD CONTROL BOARD OUTLET HOUSING OUTLET HOUSING BATTERIES BATTERIES TRANSFORMER and BRIDGE RECTIFIER located on chassis, behind the electrical box. DIAGNOSTICS TRANSFORMER and BRIDGE RECTIFIER located on chassis, behind the electrical box.
Page 28 POWER MODELS RSL12UL AND RSW12UL SYMPTOM: Operator does not have power. Transformer DIAGNOSTICS (Back of Outlet Housing) DIAGNOSTICS Check the control board.* Try replacing the fuse on Outlet the control board. If that does not work, replace the control board. CONTROL BOARD OUTLET HOUSING Outlet...
Page 29 ® FREQUENTLY ASKED QUESTIONS What do I need to activate the gate operator using MyQ ® a. Router b. Internet connection c. Internet Gateway d. Internet Gateway serial number (located on the bottom of the Internet Gateway) e. MyQ-Enabled Gate Operator What is an Internet Gateway? The Internet Gateway (828LM), is a 900 MHz Internet Protocol device for monitoring and controlling MyQ devices (e.g.
Page 30 ® If the Internet Gateway is successfully connected to the MyQ server (green LED on MyQ Gateway is illuminated and solid), the MyQ app can monitor ® and control a MyQ device from any location. All MyQ-Enabled devices must be on the MyQ account and be within transmitting capability of the Internet Gateway.
Page 31 ® TROUBLESHOOTING MyQ ® If issues are experienced when adding an Internet Gateway, a LiftMaster Gate Operator or light control to a MyQ account, please review the ® troubleshooting topics below. CONNECTION ISSUES PROBLEM If the green LED on the Internet Gateway is not illuminated or blinking, the Internet Gateway is not connected to the Internet. SOLUTION There are a few different reasons an Internet Gateway will not successfully connect to the Internet: •...
Page 32 ® ACCOUNT ISSUES ® Unable to add more than one MyQ device to a MyQ account: • Prior to adding MyQ devices, an account must be established. An account can be created by downloading the MyQ app from a smartphone or tablet app store.
Page 33 ® ACCOUNT ISSUES ® PROBLEM The MyQ-Enabled Gate Operator will not respond to the app. SOLUTION • Confirm the green LED on the Internet Gateway is illuminated and solid. If the green LED is not illuminated or blinking, see Connection Issues section.
Page 34 ® ERROR CODES ® Below are potential error codes that may be encountered when working with the Internet Gateway, MyQ app, MyQ website, or your PC or smartphone. ® GENERAL ERROR CODES ERROR CODE MESSAGE ISSUE AND RESOLUTION Unable to remove device. •...
Page 35 ® ERROR CODES ® Below are potential error codes that may be encountered when working with the Internet Gateway, MyQ app, MyQ website, or your PC or smartphone. ® GENERAL ERROR CODES ERROR CODE MESSAGE ISSUE AND RESOLUTION The device* is currently in •...
Page 36 ® INCOMPATIBLE ROUTER AND SWITCH INCOMPATIBLE ROUTER When installing an Internet Gateway, issues have been identified with the following routers/modems: MANUFACTURER MODEL Belkin F5D8236-4 (Only works on LAN ports 1 & 3) ® D-Link DIR-665 ® Hauwei Router/Modem Echolife HG520C ®...
