Off-grid Inverter

SUN-3.6K-OG01LP1-EU-AM2

SUN-5K-OG01LP1-EU-AM2

SUN-6K-OG01LP1-EU-AM2

User Manual

Need help?

Do you have a question about the SUN-3.6K-OG01LP1-EU-AM2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Deye SUN-3.6K-OG01LP1-EU-AM2

Page 1 Off-grid Inverter SUN-3.6K-OG01LP1-EU-AM2 SUN-5K-OG01LP1-EU-AM2 SUN-6K-OG01LP1-EU-AM2 User Manual...
Page 2 Contents 1. Safety Introductions 01-02 ……………………………………………… 2. Product instructions 02-06 ……………………………………………… 2.1 Product Overview 2.2 Product Size 2.3 Product Features 2.4 Basic System Architecture 3. Installation 06-24 …………………………………………………………… 3.1 Parts list 3.2 Product handling requirements 3.3 Mounting instructions 3.4 Battery connection 3.5 Grid connection and backup load connection 3.6 PV Connection 3.7 Earth Connection(mandatory)
Page 3 Documents must be stored carefully and be available at all times. Contents may be periodically updated or revised due to product development. The information in this manual is subject to change without notice. The latest manual can be acquired via service@deye.com.cn 1. Safety Introductions Labels description...
Page 4 · This chapter contains important safety and operating instructions. Read and keep this manual for future reference. · Before using the inverter, please read the instructions and warning signs of the battery and corresponding sections in the instruction manual. · Do not disassemble the inverter. If you need maintenance or repair, take it to a professional service center.
Page 5 2.1 Product Overview 1: LCD display 7: BMS 485/CAN port 13: PV input 2: Function Buttons 8: Function port 14: Power on/oﬀ button 3: Battery input connectors 9: Grid 15: DC Switch (optional)* *Note: This component is optional, 4: Meter Port 10: GeneratorLoad please conﬁrm whether you need it 5: Modbus Port...
Page 6 2.2 Product Size 350.00 mm 330.00 mm 306.00 mm Inverter Size 175.77 mm - 04 - PvPower Tel: +27 10 449 9745 Address: Unit C, 16 Liebenberg street,Alrode, 1451 w w w . p v p o w e r . c o . z a...
Page 7 2.3 Product Features - Self-consumption. - Auto restart while AC is recovering. - Programmable multiple operation modes: On grid, oﬀ grid and UPS. - Conﬁgurable battery charging current based on applications by LCD setting. - Compatible with voltage power or generator power. - Overload/over temperature/short circuit protection.
Page 8 3. Installation 3.1 Parts List Check the equipment before installation. Please make sure nothing is damaged in the package. You should have received the items in the following package: Stainless steel Stainless steel mounting Inverter Wall mounting hanger anti-collision bolt M6*60 screws M4*12 x10 User manual...
Page 9 3.2 Product handling requirements Lift the inverter out of the packing box and transport it to designated installation location. transport CAUTION: Improper handling may cause personal injury! • Arrange an appropriate number of personnel to carry the inverter according to its weight, and installation personnel should wear protective equipment such as anti-impact shoes and gloves.
Page 10 Please AVOID direct sunlight, rain exposure, snow laying up during installation and operation. Before connecting all wires, please take oﬀ the metal cover by removing screws as shown below: Installations Tools Installation tools can refer to the following recommended ones. Also, use other auxiliary tools on site.
Page 11 Considering the following points before selecting where to install: · Please select a vertical wall with load-bearing capacity for installation, suitable for installation on concrete or other non-ﬂammable surfaces,installation is shown below. · Install this inverter at eye level in order to allow the LCD display to be read at all times. ·...
Page 12 5. Carry the inverter and holding it,align the hole of the hinge with the expansion bolts and screw the nuts of expansion bolts. 6. Fasten the nuts of expansion bolts to ﬁnish the mounting. ① ② ③ ④ Aperture: 8mm Hole depth: 62-70mm - 10 - PvPower...
Page 13 3.4 Battery connection For safe operation and compliance, a separate DC over-current protector or disconnect device is required between the battery and the inverter. In some applications, switching devices may not be required but over-current protectors are still required. Refer to the typical amperage in the table below for the required fuse or circuit breaker size.
Page 14 3.4.1 Function port deﬁnition ON DP 1 2 3 ATS Switch Parallel Inverter Switch G-start: 1,2 G-valve: 3,4 TEMP: 5,6 CT: 7,8 Meter Modbus 1 2 3 4 5 6 7 8 L ATS240V parallel_1 parallel_2 BMS 485/ Meter: For energy meter communication. Modbus: Reserved.
Page 15 3.4.2 Temperature sensor connection for lead-acid battery Inverter Temp. sensor - 13 - PvPower Address: Unit C, 16 Liebenberg street,Alrode, 1451 Tel: +27 10 449 9745 w w w . p v p o w e r . c o . z a...
Page 16 3.5 Grid connection and backup load connection · Before connecting to the grid, a separate AC breaker must be installed between the inverter and the grid, and also between the backup load and the inverter. This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current.
Page 17 LOAD GRID LOAD GRID - 15 - PvPower Address: Unit C, 16 Liebenberg street,Alrode, 1451 Tel: +27 10 449 9745 w w w . p v p o w e r . c o . z a...
Page 18 Be sure that AC power source is disconnected before attempting to wire it to the unit. 3. Then, insert AC output wires according to polarities indicated on the terminal block and tighten terminal. Be sure to connect corresponding N wires and PE wires to related terminals as well. 4.
Page 19 3.6.1 PV Module Selection: When selecting proper PV modules, please be sure to consider below parameters: 1) Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of inverter. 2) Open circuit Voltage (Voc) of PV modules should be higher than min. start voltage. 3) The PV modules used to connected to this inverter shall be Class A rating certiﬁed according to lEC 61730.
Page 20 Safety Hint: Please use approved DC cable for PV system. The steps to assemble the DC connectors are listed as follows: a)Strip oﬀ the DC wire about 7mm, disassemble the connector cap nut (see picture 3.3). �mm �mm Pic 3.3 Disassemble the connector cap nut b) Crimping metal terminals with crimping pliers as shown in picture 3.4.
Page 21 d) Finally insert the DC connector into the positive and negative input of the inverter, shown as picture 3.6. Pic 3.6 DC input connection Warning: Sunlight shines on the panel will generate voltage, high voltage in series may cause danger to life. Therefore, before connecting the DC input line, the solar panel needs to be blocked by the opaque material and the DC switch should be 'OFF', otherwise, the high voltage of the inverter may lead to life- threatening conditions.
Page 22 3.7 Earth Connection(mandatory) Ground cable shall be connected to ground plate on grid side, this prevents electric shock if the original protective conductor fails. Earth connection (Copper wires) Model Wire Size Cable(mm ) Torque value(max) 3.6/5/6kW 8AWG 1.2Nm Earth connection (Copper wires) (Bypass) Model Wire Size Cable(mm )
Page 23 3.9 Wiring System for Inverter This diagram is an example for grid systems without special requirements on electrical wiring connection. Note: The load PE line and earthing bar must be grounded properly and DC Breaker eﬀectively. Otherwise the back-up function may be abnormal when the grid fails. AC Breaker Load Battery...
Page 24 Remotely control signal line ① DC Breaker Generator Battery pack ① DC Breaker for battery SUN-3.6K-OG01LP1-EU-AM2: 120A DC breaker SUN-5K-OG01LP1-EU-AM2: 150A DC breaker Backup Load SUN-6K-OG01LP1-EU-AM2: 200A DC breaker ② AC Breaker for gen port SUN-3.6K-OG01LP1-EU-AM2: 40A AC breaker SUN-5K-OG01LP1-EU-AM2: 40A AC breaker SUN-6K-OG01LP1-EU-AM2: 40A AC breaker ③...
Page 25 BMS 485/ Ground Inverter Inverter ④ No.2 ① DC (slave) Breaker ⑤ ①②③ DC Breaker for battery SUN-3.6K-OG01LP1-EU-AM2: ② DC 120A DC breaker Breaker SUN-5K-OG01LP1-EU-AM2: ⑥ 150A DC breaker SUN-6K-OG01LP1-EU-AM2: 200A DC breaker ④⑥⑧ AC Breaker for grid port SUN-3.6K-OG01LP1-EU-AM2: ⑦...
Page 26 3.12 Three phase Parallel Inverter ①②③ DC Breaker for battery SUN-3.6K-OG01LP1-EU-AM2: 120A DC breaker SUN-5K-OG01LP1-EU-AM2: 150A DC breaker SUN-6K-OG01LP1-EU-AM2: 200A DC breaker ⑤ AC Breaker for grid port SUN-3.6K-OG01LP1-EU-AM2: 40A AC breaker SUN-5K-OG01LP1-EU-AM2: 40A AC breaker SUN-6K-OG01LP1-EU-AM2: 40A AC breaker ④...
Page 27 4. OPERATION 4.1 Power ON/OFF Once the unit has been properly installed and the batteries are connected well, simply press On/Oﬀ button(located on the left side of the case) to turn on the unit.When system without battery connected, but connect with either PV or grid, and ON/OFF button is switched oﬀ, LCD will still light up(Display will show OFF), In this condition, when switch on ON/OFF button and select NO battery, system can still work.
Page 28 5. LCD Display Icons 5.1 Main Screen The LCD is a touchscreen, below screen shows the overall information of the inverter. 2025-01-21 11:24:32 Tue 0.00 0.00 0.00/0.0V 0.00 1. The icon at the center of the screen indicates whether the system is under normal operation or not, displaying “ON”...
Page 29 5.1.1 LCD operation ﬂow chart Solar Graph Grid Grid Graph Information Main Screen Home Load Load Graph Battery BMS Graph Basic Setup Battery Setup Grid Setup Setting Gen PORT USE Work Mode Advanced Function - 27 - PvPower Address: Unit C, 16 Liebenberg street,Alrode, 1451 Tel: +27 10 449 9745 w w w .
Page 30 5.2 Solar Power Curve This is Solar Panel detail page. Power: Current solar panel generation power. Power Today 0.0 kWh Today/Total: Today's and total generation energy. 0.00 kW Voltage,Curren,Power of each MPPT at current time. Total 0.0 kWh PV1-V PV2-V PV1-I 0.0 A PV2-I...
Page 31 Battery This is Battery detail page. Battery V: The battery voltage uploaded by BMS. Charge I: The charging current requested by BMS. BMS: Discharge I: The discharging current requested by Battery V 0.0 V BMS. Charge I 0.0 A Charge V: The charging voltage requested by BMS. SOC: The SOC of battery uploaded by BMS.
Page 32 5.3 Setting Menu Setting This is Setting page, including six items: Basic Setup, Battery Setup, Grid Setup, Gen PORT USE, Work Mode, Advanced Function. Basic Setup Battery Setup Grid Setup Setting Swipe up and down on the screen to switch options. Gen PORT USE Work Mode Advanced Function...
Page 33 5.4 Basic Setup Menu Basic Setup This is Basic Setup page. Time: To set the local day and time for the inverter. Display: To control the operating status of the 2025/01/21 Time buzzer and LCD screen. 11:32:13 Factory Reset: Reset all parameters of the inverter. Beep-On Display Auto Dim-On...
Page 34 Factory Reset Click the “Factory Reset” option on“Basic Setup” page, the LCD screen will turn to this page, an you can press the “Enter” button to enter the verify page or press the “Esc” button to back to the previous page. Confirm Factory Reset? Factory Reset Click “OK”...
Page 35 5.5 Battery Setup Menu Battery Setup This is Battery Setup page. Batt Set1 Batt Set2 Batt Set3 Batt Set1 Activate battery: This feature will help recover a battery that is over discharged by slowly charging from the solar array or grid. Activate Battery Mode Batt V...
Page 36 Parameters Batt Capacity: The total capacity of battery connected to this system, it can be used to calculated the SOC of battery bank under the "Use AGM %" mode. Max A Charge/Discharge: Max battery charging/ Batt Capacity discharging current. For AGM and Flooded, we recommend Ah battery size x 20%= Charge/Discharge amps.
Page 37 Batt Set3 When the “Batt V” or “Batt %” mode is selected, the content on the “Batt Set3” page is shown as the ﬁgure on the left. Float V 0.0 V 0.0V Shutdown Three stage charging strategy for lead-acid and imcompatible lithium battery.
Page 38 5.6 Grid Setup Menu Grid Setup Mode: General Standard, UL1741 & IEEE1547, CPUC RULE21SRD-UL-1741, CEI 0-21, EN50549_CZ, Australia_A, Australia_B, Australia_C, Mode AS4777_NewZealand, VDE4105, OVE_Directive_R25, General Standard EN50549_CZ_PPDS_L16A, NRS097, G98/G99, G98/G99_NI, ESB Networks(Ireland), C10/11. Frequency 50 Hz Please follow the local grid code and then choose the corresponding grid standard.
Page 39 INV Output Voltage To set the rated output voltage of the inverter. 230V 220V 240V 200V 5.7 Gen PORT USE Setup Menu GEN port is a multifunctional port, but you can only Gen PORT USE choose one of the following two functions at a time (Generator Input, SmartLoad Output).
Page 40 5.8 Work Mode Setup Menu Work Mode Work Mode Energy pattern Zero Export To Load Batt First Load First Zero Export To CT Grid Peak Shaving Power Zero-export Power Max Solar Power Zero Export To Load: The AC output power will only supply the backup load and smart load(if any).
Page 41 5.9 Advanced Function Setup Menu BMS_Err_Stop: When it is active, if the battery BMS Advanced Function failed to communicate with inverter, the inverter will stop working and report fault. BMS_Err_Stop Backup Delay: When the grid cuts oﬀ, the inverter will output power after this set time. Backup Delay CT Ratio: The ratio of CT rated primary current to rated secondary current.
Page 42 Advanced Function Export power limter: It is used to setup the maximum output power allowed to ﬂow to grid. Import power limiter: when it is active, the import Export power limiter Import power limiter power from grid will be limited. its priority is lower then “grid peak shaving”...
Page 43 6. Mode Mode I: Zero export to Load AC cable DC cable Backup Load < Solar < Battery Grid Mode II: Zero export to CT AC cable DC cable Backup Load < Solar Battery On-Grid Home Load < Grid Mode III: Oﬀ-grid AC cable DC cable Backup Load...
Page 44 Mode V: On-grid with generator AC cable DC cable Backup Load < Solar Battery Generator Grid < The 1st priority power of the system is always the PV power, then 2nd and 3rd priority power will be the battery bank or grid according to the settings. The last power backup will be the Generator (if any).
Page 45 Error code Description Solutions 1. When inverter is in Split phase(120/240Vac) or three-phase GFDI _Relay_Failure system (120/208Vac) system, the backup load port N line needs to connect ground; 2. If the fault still exists, please contact us for help. 1. When the grid type and frequency changed it will report F13; 2.
Page 46 Error code Description Solutions 1. Check the backup load connected, make sure it is in allowed power range; ACOvercurrent fault 2. If the fault still exists, please contact us for help. No Utility 1. Please confirm grid is lost or not; No AC grid 2.
Page 47 Under the guidance of our company, customers return our products so that our company can provide service of maintenance or replacement of products of the same value. Customers need to pay the necessary freight and other related costs. Any replacement or repair of the product will cover the remaining warranty period of the product.
Page 48 9. Datasheet SUN-3.6K- SUN-5K- SUN-6K- Model OG01LP1-EU-AM2 OG01LP1-EU-AM2 OG01LP1-EU-AM2 Battery Input Data Battery Type Lead-acid or Lithium-ion Battery Voltage Range(V) 40-60 Max. Charging Current(A) Max. Discharging Current(A) Charging Strategy for Li-Ion Battery Self-adaption to BMS Number of Battery Input PV String Input Data Max.
Page 49 Equipment Protection DC Polarity Reverse Connection Protection AC Output Overcurrent Protection AC Output Overvoltage Protection AC Output Short Circuit Protection Thermal Protection DC Terminal Insulation Impedance Monitoring DC Component Monitoring Ground Fault Current Monitoring Arc fault circuit interrupter (AFCI) Optional Power Network Monitoring Earth Fault Detection DC Input Switch...
Page 50 10. Appendix I Deﬁnition of RJ45 Port Pin for BMS BMS 485/CAN Port BMS 485/CAN Pin BMS-485_B 1 2 3 4 5 6 7 8 BMS-485_A BMS-GND_485 CAN-H CAN-L BMS-GND_485 BMS-485_A BMS-485_B Deﬁnition of RJ45 Port Pin for Meter Meter Port Meter Pin Meter-485-B 1 2 3 4 5 6 7 8...
Page 51 Add : 16 Liebenberg Street Alrode Tel : 010 449 9745 www.pvpower.co.za...
