- Page 1 ENGLISH uror Electronic Deadbolt with Keypad Read this manual carefully before installing and operating! Important Use the QR code below for the most up to date instructions: Tools Needed for Lock Installation: • Phillips Screwdriver...
-
Page 2: Installation Overview
Installation Overview Package Includes: 1 - Exterior Faceplate 1 - Strike Plate 2 - 5/16” Screws 1 - Interior Faceplate 1 - Mounting Plate 2 - 1” Screws 1 - User Guide 1 - Latch 4 - 3/4” Screws 2 - Keys 1 - 1 3/8”... - Page 3 Install Enclosed Latch and Strike Plate. Do not over-tighten latch screws. NOTE: Do not extend Cylindrical Cover past 2-3/4” (70mm). 2-3/8” position 2-3/4” position TO CONVERT FROM 2-3/8” (60mm) BACKSET TO 2-3/4” (70mm) BACKSET: 1. Hold latch with numbers facing forward and thumb pressing on the bolt. 2.
- Page 4 Install Exterior Assembly Check that the Rubber Gasket is secured on the Exterior Assembly. Insert the Exterior Assembly onto the door with the tailpiece going through the Deadbolt VERTICAL POSITION. Latch Set in the Make Route the Control Wire through the door UNDER the Deadbolt Latch Set. sure the door is shut, lock and unlock using the key, ensure that the latch is operating smoothly and is aligned properly without scraping the strike plate.
-
Page 5: Install Interior Assembly
Install Interior Assembly Carefully insert control wire into the wire connector Work with the door open NOTE: Make sure the connector dots line up with the dots on the controle wire... - Page 6 Install Interior Assembly NOTE: Make sure the Turn Knob is in the correct position. Be careful not to pinch the control wire when assembling. Turn Knob Test the lock Lock and unlock using the thumb turn knob, make sure the latch is opening and closing easily.
- Page 7 Install Batteries and Cover This Electronic lock requires (4) High Quality AA Alkaline batteries. When all 4 batteries are installed in the correct position, you should hear 2 beeps and the keypad will illuminate. The Lock motor will engage and do a series of locking and unlocking motions in order to automatically determine your door “Handing”...
-
Page 8: Testing Operation
Testing Operation... - Page 9 Preparing Door Tools Needed for Door Preparation (if there is no knob hole): NOTE: Skip this step if your door comes with pre-drilled holes. 2 1/8” Hole Saw • Drill • 2 1/8” Hole Saw • 1” Hole Saw • 3/4” Chisel 1”...
-
Page 10: Programming Instructions
Programming Instructions Read this manual carefully before Programming and operating! Complete all the programming steps in the programming mode within 5 seconds Do not press keypad until keypad stops illuminating... - Page 11 Creating Administrator Code Touch screen to wake up lock Input Admin code Press unlock (default 123456) Press Press unlock Input 6 digit code, Press unlock Repeat the 6 digit code, Press Tru-Bolt® logo lights green confirming success unlock 6 Digit Admin Code...
- Page 12 Touch screen to wake up lock Input New Admin Code Press unlock Press 1 Input user number Input new 4-8 digit Press unlock between 02-50, Press user code, Press unlock unlock Repeat 4-8 digit Tru-Bolt® logo lights green confirming success user code, Press unlock...
- Page 13 Unlocking Door with User Code Touch screen to wake up lock Enter User Code Press unlock PROGRAMMING RECORD Date Created My Codes: Programming Code (6 digits) User Code 02 (4-8 digits) User Code 03 (4-8 digits) User Code 04 (4-8 digits) User Code 05 (4-8 digits) User Code 06...
- Page 14 Deleting a User Code Touch screen to wake up lock Press unlock Input Your Admin Code Input existing user # Press Press unlock between 02-50 Press unlock Repeat the User # Tru-Bolt® logo lights green confirming success Press unlock...
- Page 15 Deleting All User Codes Touch screen to wake up lock Input Your Admin Code Press unlock Press 3 Press unlock Reenter Admin code Tru-Bolt® logo lights green Press unlock confirming success...
-
Page 16: Additional Programming Functions
Logo light illuminates green. ® TEMPORARILY DISABLE: While in Auto-Lock mode, unlock door using , Immediately turn the locking knob back to the unlock position. Hear 1 beep and Tru-Bolt logo light illuminates green. ® The Auto-Lock mode is now disabled. RESTORE:... - Page 17 1. Remove one battery for 10 seconds. 2. Reinsert the battery and wait for a long and short beep 3. Press lock button 3 times within 3 seconds. 4. The lock will beep and the Tru-Bolt logo light illuminates green. ® Low Battery Warning Beeps and LED flashes red 7 times.
-
Page 18: Troubleshooting
How to Operate Your New Lock To Lock your lock - press the lock button. To Unlock your lock - enter your user code (not the Admin Code) and press unlock. Troubleshooting Issue Solution Knob or vertical tailpiece is installed in incorrect position. Interior Knob will not •... - Page 19 In no event shall Tru-Bolt® be liable for any special, incidental or consequential damages. If this product[s] is...
