Wifi Setup
Setting up the
Setting up the
DocuPrint CM115 w
printer on a wireless
DocuPrint CM115 w
network
printer on a wireless
network
Before you begin
Ensure you have the name of your
wireless network (SSID), wireless
network password, security and
encryption types.
To find the name and type of
security encryption of your wireless
network on your computer (example
Windows 7):
a) Go to the Start Menu. Select
Control Panel and click on
Network and Sharing Centre.
b) Click on Manage Wireless
Networks. Double click on your
preferred wireless network. Note
the SSID. Click on the security tab.
Note the security and encryption
types.
Before you begin
Ensure you have the name of your
wireless network (SSID), wireless
network password, security and
encryption types.
To find the name and type of
security encryption of your wireless
network on your computer (example
Windows 7):
a) Go to the Start Menu. Select
Control Panel and click on
Network and Sharing Centre.
b) Click on Manage Wireless
Networks. Double click on your
preferred wireless network. Note
the SSID. Click on the security tab.
Note the security and encryption
types.
Wifi Setup
DocuPrint CM115 w
1
WPS-PBC
(WPS Button)
Note: WPS-PBC (WPS Button), WPS-PBC (Operator Panel)
and WPS-PIN is only available when the wireless access
point or router supports WPS-PBC. Please refer to the
manual provided with the router.
Before starting WPS-PBC, confirm the position of the WPS
button on the wireless access point or router. Please refer to
the manual supplied with the router for more information.
Press the small green Energy Saver button to wake up
1
the printer.
Press and hold the WPS button on the printer for three
2
(3) seconds.
Confirm that the Wi-Fi LED starts to blink slowly and press
WPS Button on WPS Router appears on the LCD panel.
3
Start the WPS operation on the wireless access point
or router within two (2) minutes. When WPS is successful,
the
(Wi-Fi) LED lights up. The wireless connection
is established and setup for wireless is complete.
2
WPS-PBC
(Operator Panel Menu)
At the Operator Panel:
Press the small green Energy Saver button to wake up
1
the printer.
Press the System button.
2
OK
DocuP
Connecting to
the Wireless
Network
Job Stat
System
