- Page 1 NEMESIS™ DISPLAY INSTALLATION GUIDE *988-12790-001*...
-
Page 2: Parts Included
Parts included A. Display unit D. 6x Corner caps B. Sun cover E. Mounting screws C. Gasket F. Cable clips Accessories (sold separately) A. Power and Ethernet cable B. NMEA 2000® drop cable with 90° connector... - Page 3 The unit can be mounted in portrait orientation or landscape Mounting orientation. In landscape orientation the B&G logo will be in the bottom left corner and in portrait orientation the logo The unit can be mounted in portrait orientation or landscape will be in the top left corner.
- Page 4 C. Nemesis™ hub F. Power and Ethernet connector with connectors at both ends (sold separately) NMEA 2000® Connect the Nemesis™ display to your vessels NMEA 2000® network for transfer of data to the displays. Example ¼ Note: Not all cables and necessary acessories are illustrated in the example.
-
Page 5: Technical Specification
Technical specification 9” unit 12” unit Display Resolution 1280x720 1280x800 Brightness 1300 nits 1500 nits Touch screen Full touch screen (multi-touch) Viewing angles 80° top/bottom, 80° left/right Electrical Supply voltage 12/24 V DC (10 - 31.2 V DC min - max) Power consumption - Max 13 W 19 W... -
Page 6: Compliance Statement
Compliance statement Declarations The relevant declarations of conformity are available at: • www.bandg.com. Europe Navico declares under our sole responsibility that the product conforms with the requirements of: • CE under RED Directive 2014/53/EU. United States of America Navico declare under our sole responsibility that the product conforms with the requirements of: •...
